Schematic and parts book for Maytag U5756900 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Popular Supplies
| # | Part image | Description | SKU | Price |
| 1 | Not Available | UPPER HANDLE-ABE | 39466069 | Not Available |
| 2 | Not Available | SCREW | 21447236 | Not Available |
| 3 |  | Screw, :( Holds Nozzle - Base Upright Extractors Part Number: 21447072 for Hoover | 21447072 | $0.91Read more |
| 4 | Not Available | TOOL DOOR-WT BGLS | 37257254 | Not Available |
| 4 | Not Available | Tool Door-WTBGL | 37257263 | Not Available |
| 5 | Not Available | LID LATCH CAM-ABR | 38562007 | Not Available |
| 6 | Not Available | SCREW-SELF TAPPING | 21447242 | Not Available |
| 7 | Not Available | LATCH SLEEVE-ABE | 36155013 | Not Available |
| 8 | Not Available | TOOL HOLDER W/THT-ABE | 36433146 | Not Available |
| 8 | Not Available | Tool Holder-WTBGL | 36433149 | Not Available |
| 9 | Not Available | SWITCH-WT-.025 TERM | 28161067 | Not Available |
| 10 | Not Available | CORD WRAP | 3944201P | Not Available |
| 11 | Not Available | SWITCH ROD SUPPORT-ABE | 36923004 | Not Available |
| 12 | Not Available | SCREW-SV 3.125" | 21447246 | Not Available |
| 13 | Not Available | DIRT CUP LID-ABE | 37249042 | Not Available |
| 14 | Not Available | PRE-FILTER CART-ABR | 36426063 | Not Available |
| 15 |  | Hepa Filter Hoover Dirt Cup Model For: hoover | 40140201 | $14.30Add to cart Special order: ships in 2 to 4 weeks |
| 16 | No Image | COVER, WIRE CHANNEL WIND-TUNNEL BAGLESS UPRTS Part Number: 37258121 for Hoover | 37258121 | $9.13Read more |
| 17 | Not Available | SCREW-SELF TAPPING | 21447242 | Not Available |
| 18 | Not Available | WAND/HOSE HOLDER-UPPER-ABE | 36433148 | Not Available |
| 19 | Not Available | INLET SEAL-AG | 38783027 | Not Available |
| 20 | Not Available | DIRT CUP HSG-WT BGLS | 42259027 | Not Available |
| 21 | Not Available | FINAL FILTER PK | 40110006 | Not Available |
| 22 | Not Available | FINAL FILTER DOOR-AFX | 37257289 | Not Available |
| 23 | Not Available | MUFFLER FOAM | 34172013 | Not Available |
| 24 | Not Available | Latch Cover Shroud | 42262091 | Not Available |
| 24 | No Image | COVER, DIRT CUP LATCH U5725 Part Number: 37258166 for Hoover | 37258166 | $10.00Read more |
| 24 | Not Available | Latch Cover Shroud | 37258049 | Not Available |
| 24 | Not Available | Latch Cover Shroud | 37258144 | Not Available |
| 24 | Not Available | LATCH COVER SHROUD | 37258158 | Not Available |
| 25 | Not Available | CAM SLOT CAP-AFB | 37258159 | Not Available |
| 25 | Not Available | Cam Slot Cap-AG | 37258139 | Not Available |
| 25 | Not Available | Cam Slot Cap-WT BGLS | 37258126 | Not Available |
| 25 | Not Available | CAM SLOT CAP-AEF | 37258167 | Not Available |
| 25 | Not Available | CAM SLOT CAP-ACX | 37258175 | Not Available |
| 26 | Not Available | Latch Cover-ACX | 38567046 | Not Available |
| 26 | Not Available | Latch Cover-WT Bgls | 38567029 | Not Available |
| 26 | Not Available | Latch Cover-AG | 38567031 | Not Available |
| 26 | No Image | COVER, LATCH U5720-990 Part Number: 38567030 for Hoover | 38567030 | $11.92Read more |
| 27 | Not Available | MUFFLER COVER-ABE | 37259016 | Not Available |
| 28 | Not Available | SCREW-SELF TAPPING | 21447242 | Not Available |
| 29 | Not Available | WIRE CHANNEL FOAM | 34131009 | Not Available |
| 30 |  | Wire Opening Plug For: hoover | 34131019 | $1.89Add to cart Special order: ships in 2 to 4 weeks |
| 31 | Not Available | SCREW-SELF TAPPING | 21447242 | Not Available |
| 32 | Not Available | SECONDARY FILTER | 38762008 | Not Available |
| 33 | | Screw, :( Holds Nozzle - Base Upright Extractors Part Number: 21447072 for Hoover | 21447072 | $0.91Read more |
| 34 | Not Available | LAMP | 27313101 | Not Available |
| 35 | Not Available | WIRING HARNESS | 47173023 | Not Available |
| 36 | Not Available | MOTOR ASSEM COMP. | 43576188 | Not Available |
| 36 | Not Available | MOTOR BRUSH | 41311017 | Not Available |
| 37 | Not Available | MOTOR MOUNT-SMALL | 36322030 | Not Available |
| 38 | Not Available | SCREW-SELF TAPPING | 21447242 | Not Available |
| 39 | Not Available | SEC FILTER RETAINER | 43615088 | Not Available |
| 40 | Not Available | EDF COVER-AFB | 37944017 | Not Available |
| 40 | Not Available | Cover-WT BGLS | 37944014EDF | Not Available |
| 40 | Not Available | Cover-AEA-WTBGL | 37944015EDF | Not Available |
| 40 | Not Available | Cover-AG-U576190 | 37944016EDF | Not Available |
| 40 | Not Available | Cover-ACX-U57569 | 37944020EDF | Not Available |
| 41 |  | Lens-Cp For: hoover | 39383107 | $4.36Add to cart Special order: ships in 2 to 4 weeks |
| 42 | Not Available | SCREW-SELF-TAPPING | 21447228 | Not Available |
| 43 | Not Available | MOTOR COVER-WT BGLS | 37196160 | Not Available |
| 44 | Not Available | SCREW-SELF TAPPING-F | 21447230 | Not Available |
| 45 | Not Available | DIRT CUP-WT BAGLESS-SERVICE | 38775077 | Not Available |
| 46 | Not Available | HANDLE-DIRT CUP-ABE | 39457018 | Not Available |
| 47 | Not Available | SCREW | 21447043 | Not Available |
| 48 | Not Available | DIRT CUP HDL-AEF-U57 | 39457041 | Not Available |
| 48 | Not Available | Dirt Cup Hdl-Outer | 39457020 | Not Available |
| 48 | Not Available | DIRT CUP HDL COVER | 39457033 | Not Available |
| 49 | Not Available | WAND HOLDER-LOWER-ABE | 36433147 | Not Available |
| 50 | Not Available | SCREW-SELF TAPPING | 21447242 | Not Available |
| 51 | Not Available | Hood-ACX-U5756-900 | 37253406 | Not Available |
| 51 | Not Available | DELUXE HOOD 15" - AG | 37253390 | Not Available |
| 51 | Not Available | Hood Asm-AEA-WTBGL 37253370 | 37253345 | Not Available |
| 51 | Not Available | Hood-AEC-WT BGLS | 37253346 | Not Available |
| 51 | Not Available | Hood-u5757-900 | 37253357 | Not Available |
| 51 | Not Available | Hood-AG-U5761-900 37253390 | 37253356 | Not Available |
| 51 | Not Available | Hood-Deluxe-15 in. | 37253370 | Not Available |
| 51 | No Image | HOOD, W/GRAPHICS U5755 Part Number: 37253371 for Hoover | 37253371 | $38.67Read more |
| 51 | Not Available | HOOD-AFB | 37253385 | Not Available |
| 52 | | Screw, :( Holds Nozzle - Base Upright Extractors Part Number: 21447072 for Hoover | 21447072 | $0.91Read more |
| 53 | Not Available | VALVE ASSEMBLY | 43516010 | Not Available |
| 54 | Not Available | TRUNNION COVER-ABE | 36131094 | Not Available |
| 55 | Not Available | NOZZLE ADJ LEVER & CAM KIT | 40309004 | Not Available |
| 56 | Not Available | HANDLE RELEASE LEVER | 38458043 | Not Available |
| 57 | Not Available | REAR AXLE-AAX-U5433- 32434007 | 32434008 | Not Available |
| 58 | Not Available | REAR WHEEL | 38522077 | Not Available |
| 60 | Not Available | SCREW-SELF-TAPPING | 21447228 | Not Available |
| 61 | Not Available | NOZZLE ADJ LEVER & CAM KIT | 40309004 | Not Available |
| 62 | Not Available | TORSION SPRING | 38355010 | Not Available |
| 63 | Not Available | FRONT WHEEL ASSEMBLY 43248064 | 43248057 | Not Available |
| 64 | Not Available | RIB SHOES | 013261AY | Not Available |
| 65 | Not Available | BMT PLATEl /DUCT COVER | 40309034 | Not Available |
| 66 | Not Available | BELT | 38528033 | Not Available |
| 67 | Not Available | AGITATOR-15-SERVICE | 48414115 | Not Available |
| 68 | Not Available | BMT PLATE/DUCT COVER | 40309034 | Not Available |
| 69 | Not Available | SCREW | 21447121 | Not Available |
| 70 | Not Available | MOTOR MOUNT-LRG 36322037 | 36322035 | Not Available |
| 71 | Not Available | HOSE-WT BGLS | 43491051 | Not Available |
| 71 | Not Available | O Ring | 25156520 | Not Available |
| 72 | Not Available | THERMAL PROTECTOR-WT | 28382093 | Not Available |
| 73 | Not Available | CORD-35' | 46383331 | Not Available |
| 74 | Not Available | CORD PROTECTOR-WTBGL | 36215028 | Not Available |
| 75 | Not Available | HOSE CLAMP-WT BAGLES | 36171035 | Not Available |
| 76 | Not Available | MAIN BODY-WT BGLS | 37242128 | Not Available |
| 77 | Not Available | Litter Picker-WT BGL | 39511008 | Not Available |
| 78 |  | Lead Wire - White 12 Amp For: hoover | 49811079 | $1.96Read more |
| 78 | Not Available | Torsion Spring-U5750 | 38358002 | Not Available |
| 78 | Not Available | SCREW-S2095/97/99 | 21447203 | Not Available |
| 78 | Not Available | Muffler Cover-Rear | 37255015 | Not Available |
| 90 | Not Available | FLOOR BRUSH ASSM-AG- | 43414142 | Not Available |
| 90 | Not Available | DUSTING BRUSH-ABR-U5 43414174 | 43414162 | Not Available |
| 90 | Not Available | HOSE-DLX-20'-ST-WTBL | 43434043 | Not Available |
| 90 | Not Available | CREVICE TOOL-ABR | 38617027 | Not Available |
| 90 | Not Available | CREVICE TOOL-ABR | 38617029 | Not Available |
| 90 | Not Available | EXTENSION TUBE-AG | 38634078 | Not Available |
| 90 | Not Available | TURBINE HAND TOOL(4) | 40200013 | Not Available |
| 90 | Not Available | FURNITURE NOZZLE | 3861401E | Not Available |
