Schematic and parts book for Hoover U5723900, U5723-900 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Popular Supplies
| # | Part image | Description | SKU | Price |
| 1 | Not Available | UPPER HANDLE | 39466069 | Not Available |
| 2 | Not Available | SCREW | 21447236 | Not Available |
| 3 |  | Screw, :( Holds Nozzle - Base Upright Extractors Part Number: 21447072 for Hoover | 21447072 | $0.91Read more |
| 4 | Not Available | Tool Door-WTBGL | 37257263 | Not Available |
| 5 | Not Available | Lid Latch/Cam -u66309 | 38562007 | Not Available |
| 6 | Not Available | SCREW-SELF TAPPING | 21447242 | Not Available |
| 7 | Not Available | LATCH SLEEVE-ABE | 36155013 | Not Available |
| 8 | Not Available | Tool Holder-WTBGL | 36433149 | Not Available |
| 9 | Not Available | SWITCH-WT-.025 TERM | 28161067 | Not Available |
| 10 | Not Available | CORD WRAP | 3944201P | Not Available |
| 11 | Not Available | SWITCH ROD SUPPORT-ABE | 36923004 | Not Available |
| 12 | Not Available | SCREW-SV 3.125" | 21447246 | Not Available |
| 13 | Not Available | DIRT CUP LID-ABE-U57 | 37249042 | Not Available |
| 14 | Not Available | PRE-FILTER CART-ABR | 36426063 | Not Available |
| 15 |  | Hepa Filter Hoover Dirt Cup Model For: hoover | 40140201 | $14.30Add to cart Special order: ships in 2 to 4 weeks |
| 16 | No Image | COVER, WIRE CHANNEL WIND-TUNNEL BAGLESS UPRTS Part Number: 37258121 for Hoover | 37258121 | $9.13Read more |
| 17 | Not Available | SCREW-SELF TAPPING | 21447242 | Not Available |
| 18 | Not Available | WAND/HOSE HOLDER-UPPER-ABE | 36433148 | Not Available |
| 19 | Not Available | INLET SEAL-AG | 38783027 | Not Available |
| 20 | Not Available | DIRT CUP HSG-WT BGLS | 42259027 | Not Available |
| 21 | Not Available | FINAL FILTER PK (12) | 40110006 | Not Available |
| 22 | Not Available | FIN FILTER DOOR-AFX | 37257289 | Not Available |
| 23 | Not Available | MUFFLER FOAM | 34172013 | Not Available |
| 24 | Not Available | LATCH COVER SHROUD | 37258180 | Not Available |
| 25 | Not Available | CAM SLOT CAP-ADR | 37258179 | Not Available |
| 26 | Not Available | LATCH COVER-ADR | 38567033 | Not Available |
| 27 | Not Available | MUFFLE COVER-ABE | 37259016 | Not Available |
| 28 | Not Available | SCREW-SELF TAPPING | 21447242 | Not Available |
| 29 | Not Available | WIRE CHANNEL FOAM | 34131009 | Not Available |
| 30 |  | Wire Opening Plug For: hoover | 34131019 | $1.89Add to cart Special order: ships in 2 to 4 weeks |
| 31 | Not Available | SCREW-SELF TAPPING | 21447242 | Not Available |
| 32 | Not Available | SECONDARY FILTER | 38762008 | Not Available |
| 33 | | Screw, :( Holds Nozzle - Base Upright Extractors Part Number: 21447072 for Hoover | 21447072 | $0.91Read more |
| 34 | Not Available | LAMP | 27313101 | Not Available |
| 35 | Not Available | WIRING HARNESS-U5433 | 47173016 | Not Available |
| 36 | Not Available | MOTOR ASSEM COMP. | 43576188 | Not Available |
| 37 | Not Available | MOTOR MOUNT-SMALL | 36322030 | Not Available |
| 38 | Not Available | SCREW-SELF TAPPING | 21447242 | Not Available |
| 39 | Not Available | SEC FILTER RETAINER | 43615088 | Not Available |
| 40 | Not Available | EDF COVER-ADR | 37944021 | Not Available |
| 41 |  | Lens-Cp For: hoover | 39383107 | $4.36Add to cart Special order: ships in 2 to 4 weeks |
| 42 | Not Available | SCREW-SELF-TAPPING | 21447228 | Not Available |
| 43 | Not Available | MOTOR COVER-WT BGLS | 37196160 | Not Available |
| 44 | Not Available | SCREW-SELF TAPPING-F | 21447230 | Not Available |
| 45 | Not Available | DIRT CUP-WT BAGLESS | 38775077 | Not Available |
| 46 | Not Available | HANDLE-DIRT CUP-ABE | 39457018 | Not Available |
| 47 | Not Available | SCREW | 21447043 | Not Available |
| 48 | Not Available | DIRT CUP HDL-AEF-U57 | 39457041 | Not Available |
| 49 | Not Available | WAND HOLDER-LOWER-ABE | 36433147 | Not Available |
| 50 | Not Available | SCREW-SELF TAPPING | 21447242 | Not Available |
| 51 | Not Available | HOOD-ADR | 37253409 | Not Available |
| 52 | | Screw, :( Holds Nozzle - Base Upright Extractors Part Number: 21447072 for Hoover | 21447072 | $0.91Read more |
| 53 | Not Available | VALVE ASSEMBLY | 43516010 | Not Available |
| 54 | Not Available | TRUNNION COVER-ABE | 36131094 | Not Available |
| 55 | Not Available | NOZZLE ADJUST LEVER | 40309004 | Not Available |
| 56 | Not Available | HANDLE RELEASE LEVER | 38458043 | Not Available |
| 57 | Not Available | REAR AXLE-AAX-U5433- | 32434008 | Not Available |
| 58 | Not Available | REAR WHEEL | 38522077 | Not Available |
| 59 | Not Available | LOCK RING | 160017 | Not Available |
| 60 | Not Available | SCREW-SELF-TAPPING | 21447228 | Not Available |
| 61 | Not Available | NOZZLE ADJUST LEVER | 40309004 | Not Available |
| 62 | Not Available | TORSION SPRING | 38355010 | Not Available |
| 63 | Not Available | FRONT WHEEL ASSEMBLY | 43248057 | Not Available |
| 64 | Not Available | RIB SHOES | 013261AY | Not Available |
| 65 | Not Available | BOTTOM PLATE/DUCT CO | 40309026 | Not Available |
| 66 | Not Available | BELT | 38528033 | Not Available |
| 67 | Not Available | AGITATOR-15-SERVICE | 48414115 | Not Available |
| 68 | Not Available | BOTTOM PLATE/DUCT CO | 40309026 | Not Available |
| 69 | Not Available | SCREW | 21447121 | Not Available |
| 70 | Not Available | MOTOR MOUNT-LRG | 36322035 | Not Available |
| 71 | Not Available | O Ring | 25156520 | Not Available |
| 71 | Not Available | HOSE-WT BGLS | 43491051 | Not Available |
| 72 | Not Available | THERMAL PROTECTOR-WT | 28382093 | Not Available |
| 73 | Not Available | CORD-35' | 46383331 | Not Available |
| 74 | Not Available | CORD PROTECTOR-WTBGL | 36215028 | Not Available |
| 75 | Not Available | HOSE CLAMP-WT BAGLES | 36171035 | Not Available |
| 76 | Not Available | MAIN BODY-WT BGLS | 37242128 | Not Available |
| 77 | Not Available | Litter Picker-WT BGL | 39511008 | Not Available |
| 80 | Not Available | EXTENSION TUBE-AG | 38634078 | Not Available |
| 80 |  | Lead Wire - White 12 Amp For: hoover | 49811079 | $1.96Read more |
| 80 | Not Available | CREVICE TOOL-ABR | 38617027 | Not Available |
| 80 | Not Available | FURNITURE NOZZLE | 3861401E | Not Available |
| 80 | Not Available | Owner Manual-WTBGLS | 56511B39 | Not Available |
| 80 | Not Available | SCREW-S2095/97/99 | 21447203 | Not Available |
| 80 | Not Available | HOSE-DLX-20'-ST-WTBL | 43434043 | Not Available |
| 80 | Not Available | DIRT DUCT ASM-WT BL | 43486010 | Not Available |
| 80 | Not Available | Muffler Cover-Rear | 37255015 | Not Available |
| 80 | Not Available | DUSTING BRUSH-ABR-U5 | 43414162 | Not Available |
