Schematic and parts book for Hoover U5164900, U5164-900 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Popular Supplies
| # | Part image | Description | SKU | Price |
| 1 | No Image | HOOD, U5163 U5167 U5162 Part Number: 37253A12 for Hoover | 37253A12 | $25.45Read more |
| 1 | Not Available | HOOD-AFS-U5162-900 | 37253A13 | Not Available |
| 1 | Not Available | HOOD-ACU-U5163 | 37253A10 | Not Available |
| 2 | Not Available | NAMEPLATE-U5161 | 51351010 | Not Available |
| 3 | Not Available | LOWER DUCT | 38646085 | Not Available |
| 4 |  | HOUSING, BRUSHROLL U5162-900,U5163-900,FOLD-AWAY Part Number: 37243040 for Hoover | 37243040 | $6.32Read more |
| 5 | Not Available | AGITATOR | 48414127 | Not Available |
| 6 |  | Debris Door Spring / Hoover U5162-900 Upright For: hoover | 38335026 | $1.83Add to cart Special order: ships in 2 to 4 weeks |
| 7 |  | Cover, Black Plastic Trunnion C1660-900/UH40155 Part Number: 36131118 for Hoover | 36131118 | $1.44Add to cart Special order: ships in 2 to 4 weeks |
| 8 | Not Available | MAIN BODY | 37242137 | Not Available |
| 9 | Not Available | HANDLE RELEASE LEVER | 38458069 | Not Available |
| 10 | Not Available | RIB SHOES | 013261AY | Not Available |
| 11 |  | Wheel, Rear U5161/U5262 Part Number: 38522086 for Hoover | 38522086 | $4.62Read more |
| 11 | Not Available | HOOD-AGA-U5164 | 37253A36 | Not Available |
| 12 | Not Available | WHEEL HUB | 37912016 | Not Available |
| 13 | Not Available | DEBRIS DOOR | 37257300 | Not Available |
| 14 | Not Available | NOZ HEIGH T ADJ CAM 38562 022 | 38562020 | Not Available |
| 15 | Not Available | AG BELT-1 2AMP BULK | 38528040 | Not Available |
| 16 | Not Available | FRONT WHEELASSEM 90001005 | 43248062 | Not Available |
| 17 | Not Available | ROPE SEAL GASKET | 38781076 | Not Available |
| 18 | Not Available | ATTACHMENT CORD | 46383348 | Not Available |
| 19 | Not Available | FINAL FILTER RETAINER | 36426061 | Not Available |
| 20 | Not Available | BULB ACCESS DOOR | 37248005 | Not Available |
| 21 | Not Available | DIRT CUP CARRY HDL | 39457045 | Not Available |
| 22 | Not Available | DIRT CUP LID W/SEAL | 37249037 | Not Available |
| 23 |  | Hoover 40130050 Allergen Wide-Path Foldaway Uprights Cartridge Filter | 40130050 | $14.29Read more |
| 23 |  | Compatible alternatef924 Hepa Filter Hoover Upright Foldaway Turbopower 3100 u5163 More Product Details | 38-2307-04 | $15.93Add to cart |
| 23 |  | Compatible alternateFilter-Hoover Foldaway U5163 Hepa Cartridge - Replac For: envirocare More Product Details | F924 | $15.93Add to cart Special order: ships in 2 to 4 weeks |
| 24 | Not Available | FILTER SUPPORT | 36426065 | Not Available |
| 25 | Not Available | DIRT CUP-SERVICE | 38775098 | Not Available |
| 26 | Not Available | UPPER HANDLE ASSEMBLY | 39453001 | Not Available |
| 27 | Not Available | FRT HSING-AG-U5167 | 37254221 | Not Available |
| 27 | Not Available | FRONT HOUSING - AGA - U5164-90 | 37254234 | Not Available |
| 27 | Not Available | FRT HSING-AFS-U5162 | 37254223 | Not Available |
| 27 | Not Available | FRT HSING-ACU-U5163 | 37254220 | Not Available |
| 28 | Not Available | FINAL FILTER | 38766008 | Not Available |
| 29 | Not Available | INLET SEAL | 38785019 | Not Available |
| 30 | No Image | COVER, HANDLE RETAINER U5161900 Part Number: 37258161 for Hoover | 37258161 | $6.95Read more |
| 31 | Not Available | PIVOT LATCH LEVER | 36151033 | Not Available |
| 32 | Not Available | PIVOT LATCH SPRING | 38355016 | Not Available |
| 33 | Not Available | PLUG | 34131010 | Not Available |
| 34 | Not Available | DUCT SEAL | 38783032 | Not Available |
| 35 |  | Wire Opening Plug For: hoover | 34131019 | $1.89Add to cart Special order: ships in 2 to 4 weeks |
| 36 |  | Motor Mount (Large) Hoover U5469 Windtunnel For: hoover | 36322037 | $4.36Add to cart Special order: ships in 2 to 4 weeks |
| 37 | Not Available | MOTOR ASSEM COMP. | 43576188 | Not Available |
| 38 | Not Available | MOTOR MOUNT-SMALL | 36322030 | Not Available |
| 39 | Not Available | FURNITURE NOZZLE | 3861401E | Not Available |
| 40 | Not Available | CORD WRAP | 3944201P | Not Available |
| 41 | Not Available | TOOL HLDR UPPER | 36433182 | Not Available |
| 42 | Not Available | DUSTING BRUSH ASSEM- | 43414174 | Not Available |
| 43 | Not Available | EXTENSION TUBE-14 IN | 38634091 | Not Available |
| 44 | Not Available | SWITCH-WT-.025 TERM | 28161067 | Not Available |
| 45 | Not Available | THERMAL PROTECTOR | 28382094 | Not Available |
| 46 | Not Available | REAR HOUSING | 37255035 | Not Available |
| 47 | Not Available | TOOL HLDR LOWER | 36433181 | Not Available |
| 48 | Not Available | CORD PROTECTOR-WTBGL | 36215028 | Not Available |
| 49 | Not Available | CREVICE T OOL-ABR | 38617029 | Not Available |
| 50 | Not Available | DIRT FINDI ;r LENS | 39383118 | Not Available |
| 51 |  | Hose Assemble Hoover U5161 Fold-Away For: hoover | 43431224 | $23.16Read more |
| 52 | Not Available | SCREW-SELF TAPPING | 21447242 | Not Available |
| 53 |  | Screw, :( Holds Nozzle - Base Upright Extractors Part Number: 21447072 for Hoover | 21447072 | $0.91Read more |
| 54 |  | Hoover Screw | 21447269 | $1.11Add to cart Special order: ships in 2 to 4 weeks |
| 55 | Not Available | SCREW | 017001FW | Not Available |
| 56 | Not Available | WIRING HARNESS-U5161 | 47173040 | Not Available |
| 57 | Not Available | BULB | 27313107 | Not Available |
| 58 | Not Available | OWNER MANUAL-U5167 | 56511B84 | Not Available |
| 58 | Not Available | WIRE CONNECTOR | 27618508 | Not Available |
| 58 | | Hoover Screw | 21447269 | $1.11Add to cart Special order: ships in 2 to 4 weeks |
| 58 | Not Available | OWNER MANUAL | 56511B72 | Not Available |
| 58 | Not Available | LEAD WIRE-WHITE-U516 | 49811120 | Not Available |
| 58 | Not Available | EXTRA HOSE ASM COMP | 43434042 | Not Available |
| 58 | Not Available | LEAD WIRE-PURPLE-U51 | 49811117 | Not Available |
