Schematic and parts book for Hoover U5156900, U5156-900 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Popular Supplies
| # | Part image | Description | SKU | Price |
| 1 | Not Available | UPPER HANDLE | 39466065 | Not Available |
| 1 | Not Available | STD HOOD-15"-AGF | 92001037 | Not Available |
| 2 | Not Available | CORD WRAP | 3944201P | Not Available |
| 2 | Not Available | HOSE DOOR ASSEM-SERVICE | 43431005 | Not Available |
| 3 | Not Available | CABLE TIE | 27479307 | Not Available |
| 3 | Not Available | HANDLE RELEASE LEVER | 38458043 | Not Available |
| 4 | Not Available | WIRE CONNECTOR | 27618508 | Not Available |
| 4 | Not Available | NOZZLE ADJ LEVER & CAM KIT | 40309004 | Not Available |
| 5 | No Image | SPRING, DIRT CUP LATCH Part Number: 38355015 for Hoover | 38355015 | $1.96Read more |
| 5 |  | Screw, :( Holds Nozzle - Base Upright Extractors Part Number: 21447072 for Hoover | 21447072 | $0.91Read more |
| 6 | Not Available | SWITCH-WT-.025 TERM | 28161067 | Not Available |
| 6 | Not Available | TRUNNION COVER-ABE | 36131094 | Not Available |
| 7 | Not Available | SCREW | 21447041 | Not Available |
| 7 |  | Hose Clamp Hoover U5421-9Rm Upright For: hoover | 36171044 | $1.89Add to cart Special order: ships in 2 to 4 weeks |
| 8 | Not Available | UPPER HOUSING | 37259003 | Not Available |
| 8 | Not Available | LOCK RING | 160017 | Not Available |
| 9 | Not Available | HANDLE HARDWARE ASSEM | 40201149 | Not Available |
| 9 | Not Available | REAR WHEEL | 38522077 | Not Available |
| 10 | Not Available | STRAIN RELIEF | 27482230 | Not Available |
| 10 | Not Available | REAR AXLE | 32434012 | Not Available |
| 11 | Not Available | CORD-35'-WT | 46383334 | Not Available |
| 11 | Not Available | MAIN BODY W/GUARD-15 IN-ABE | 92001038 | Not Available |
| 12 | Not Available | HOSE CONNECTOR GASKET | 31178017 | Not Available |
| 12 | Not Available | SCREW-SELF-TAPPING | 21447228 | Not Available |
| 13 | Not Available | DIRT DUCT | 38641005 | Not Available |
| 13 | Not Available | NOZZLE ADJ LEVER & CAM KIT | 40309004 | Not Available |
| 14 | Not Available | HOSE ASSEM COMP | 43434248 | Not Available |
| 14 | Not Available | TORSION SPRING | 38355010 | Not Available |
| 15 | Not Available | SCREW-SELF TAPPING | 21447242 | Not Available |
| 15 | Not Available | FRONT WHEEL SUPPORT-CP | 36432027 | Not Available |
| 15 | Not Available | FRONT WHEEL ASSEM COMPLETE | 92001026 | Not Available |
| 16 | Not Available | TOOL/HOSE HOLDER | 36433112 | Not Available |
| 16 |  | Wheel Shaft Hoover Upright For: hoover | 32541007 | $7.10Add to cart Special order: ships in 2 to 4 weeks |
| 17 |  | Screw-Hoover Windtunnel Cord Retainer For: hoover | 23149002 | $0.96Add to cart Special order: ships in 2 to 4 weeks |
| 17 | Not Available | FRONT WHEEL-AG | 38521009 | Not Available |
| 18 | Not Available | HOSE DOOR ASSEM-SERVICE | 43431005 | Not Available |
| 18 | Not Available | BELT | 38528033 | Not Available |
| 19 | Not Available | WIRE OPENING SEAL | 34311004 | Not Available |
| 19 | Not Available | BOTTOM PLATE/DUCT CO | 40309026 | Not Available |
| 20 | Not Available | FURNITURE NOZZLE | 3861401E | Not Available |
| 20 |  | Seal-Agitator Pulley-Hoover U5445 For: hoover | 38781053 | $1.44Add to cart |
| 21 | Not Available | CREVICE TOOL-ABR | 38617027 | Not Available |
| 21 | Not Available | AGITATOR-15-SERVICE | 48414116 | Not Available |
| 22 | Not Available | DUSTING BRUSH ASSEMBLY-ABR | 92001017 | Not Available |
| 22 | Not Available | BOTTOM PLATE/DUCT CO | 40309026 | Not Available |
| 23 | Not Available | EXTENSION TUBE-AG | 38634078 | Not Available |
| 23 | Not Available | FURNITURE GUARD FILLER | 36235088 | Not Available |
| 24 | Not Available | MOTOR MOUNT-LRG | 36322035 | Not Available |
| 24 | Not Available | SCREW | 21447121 | Not Available |
| 25 | Not Available | MOTOR ASSEM COMP. | 43576188 | Not Available |
| 25 | Not Available | MOTOR BRUSH | 41311017 | Not Available |
| 25 | Not Available | FAN ASSEMBLY | 90001206 | Not Available |
| 25 | Not Available | FURNITURE NOZZLE | 3861401E | Not Available |
| 25 | Not Available | CREVICE TOOL-ABR | 38617027 | Not Available |
| 25 | Not Available | DUSTING BRUSH ASSEMBLY-ABR | 92001017 | Not Available |
| 26 | Not Available | THERMOL PROTECTOR | 28382086 | Not Available |
| 26 | Not Available | TOC LABEL-WINDTUNNEL | 51873001 | Not Available |
| 27 | Not Available | SCREW-SELF TAPPING-F | 21447230 | Not Available |
| 28 | Not Available | MOTOR COVER-ABE | 37196158 | Not Available |
| 29 | Not Available | SCREW-SELF-TAPPING | 21447228 | Not Available |
| 30 |  | Lens-Cp For: hoover | 39383107 | $4.36Add to cart Special order: ships in 2 to 4 weeks |
| 31 | Not Available | ROPE SEAL | 38781061 | Not Available |
| 32 |  | Cover-Abe For: hoover | 37944010 | $1.95Add to cart Special order: ships in 2 to 4 weeks |
| 33 | | Screw, :( Holds Nozzle - Base Upright Extractors Part Number: 21447072 for Hoover | 21447072 | $0.91Read more |
| 34 | Not Available | WIRING HARNESS | 47173023 | Not Available |
| 35 | Not Available | LAMP | 27313101 | Not Available |
| 36 |  | Wire Opening Plug For: hoover | 34131019 | $1.89Add to cart Special order: ships in 2 to 4 weeks |
| 37 | Not Available | MOTOR MOUNT-SMALL | 36322030 | Not Available |
| 38 |  | Secondary Filter for Hoover Windtunnel | 38765019 | $5.42Read more |
| 39 | Not Available | SEC FILTER RETAINER | 36426066 | Not Available |
| 40 | Not Available | HANDLE HARDWARE ASSEM | 40201149 | Not Available |
| 41 | Not Available | FILTER HOLDER-STD | 36426060 | Not Available |
| 42 | Not Available | FINAL FILTER | 38766008 | Not Available |
| 43 | Not Available | INTAKE SEAL | 38784089 | Not Available |
| 44 | Not Available | LATCH-DIRT CUP | 36151032 | Not Available |
| 45 | Not Available | PRE-FILTER SCREEN | 36426053 | Not Available |
| 46 | Not Available | LOWER WAND HOLDER | 36433116 | Not Available |
| 47 | Not Available | UPPER WAND HOLDER | 36433117 | Not Available |
| 48 | Not Available | FILTER SUPPORT W/OVERMOLD | 36426056 | Not Available |
| 49 | Not Available | DIRT CUP LID-AGF | 37249053 | Not Available |
| 50 | Not Available | LATCH ACTUATOR | 38421104 | Not Available |
| 51 | Not Available | DIRT CUP | 91001054 | Not Available |
| 52 |  | Hoover HEPA Filter for Widepath PowerMax Turbo Power | 40110008 | $14.29Read more |
| 53 | Not Available | EXHAUST SEAL-DIRT CUP | 38784084 | Not Available |
| 56 | Not Available | OWNER MANUAL | 56511B49 | Not Available |
