Schematic and parts book for Hoover CP50005 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Popular Supplies
| # | Part image | Description | SKU | Price |
| 1 | Not Available | UPPER HANDLE ASSEMBLY | 39466140 | Not Available |
| 2 | Not Available | CORD WRAP | 39442043 | Not Available |
| 3 | Not Available | HANDLE HARDWARE ASSEMBLY SCREWS 3-15/16" | 40201149 | Not Available |
| 4 | Not Available | HEX NUT | 21641558 | Not Available |
| 6 | Not Available | SWITCH - ONE BLACK LEAD / ONE YELLOW LEAD | 28161074 | Not Available |
| 7 | Not Available | CABLE TIE | 27479307 | Not Available |
| 8 | Not Available | UPPER WAND HOLDER | 36433117 | Not Available |
| 9 | Not Available | LOWER WAND HOLDER | 36433116 | Not Available |
| 10 | Not Available | LOWER CORD WRAP - BLACK | 39441016 | Not Available |
| 11 | Not Available | LOWER CORD WRAP SCREW | 21447236 | Not Available |
| 12 | Not Available | DIRT DUCT | 38641005 | Not Available |
| 14 | Not Available | SCREW - SELF TAPPING | 21447242 | Not Available |
| 15 |  | Screw-Hoover Windtunnel Cord Retainer For: hoover | 23149002 | $0.96Add to cart Special order: ships in 2 to 4 weeks |
| 16 | Not Available | WIRE OPENING SEAL | 34311004 | Not Available |
| 17 | Not Available | HOSE TUBE EXTENTION DOOR ASMBLY | 43457024 | Not Available |
| 18 | Not Available | LOWER HOSE / INLET DOOR ASSEMBLY | 43431005 | Not Available |
| 19 | Not Available | HOSE DOOR - BLACK | 37911082 | Not Available |
| 20 |  | Hose Door Bracket-Pr For: hoover | 36438002 | $2.46Add to cart Special order: ships in 2 to 4 weeks |
| 21 | Not Available | POWER CORD PIGTAIL - 1/4 TERMINAL | 46583188 | Not Available |
| 22 | Not Available | STRAIN RELIEF | 27482231 | Not Available |
| 22 | Not Available | CORD PROTECTOR | 66655430 | Not Available |
| 23 | Not Available | EXTENSION POWER CORD - 50' BLACK | 730727003 | Not Available |
| 24 | Not Available | HOSE CONNECTOR GASKET | 31178017 | Not Available |
| 25 | Not Available | FINAL / EXHAUST FILTER | 38766008 | Not Available |
| 26 | Not Available | FILTER HOLDER | 36426060 | Not Available |
| 27 |  | Secondary Filter for Hoover Windtunnel | 38765019 | $5.42Read more |
| 28 |  | Frame, :( Filter WindTunnel Upright Part Number: 36426034 for Hoover | 36426034 | $2.46Add to cart Special order: ships in 2 to 4 weeks |
| 29 | Not Available | MOTOR ASSEMBLY - 8 AMP | 27212071 | Not Available |
| 29 | Not Available | MOTOR BRUSH | 41311017 | Not Available |
| 30 | Not Available | THERMAL PROTECTOR | 780236001 | Not Available |
| 31 | Not Available | WIRE CONNECTOR | 27618106 | Not Available |
| 32 |  | Motor Mount (Large) Hoover U5469 Windtunnel For: hoover | 36322037 | $4.36Add to cart Special order: ships in 2 to 4 weeks |
| 33 | Not Available | MOTOR MOUNT - SMALL | 36322030 | Not Available |
| 34 | Not Available | FOAM MOTOR MUFFLER | 39411001 | Not Available |
| 35 | Not Available | MOTOR COVER | 37196159 | Not Available |
| 36 |  | Wire Opening Plug For: hoover | 34131019 | $1.89Add to cart Special order: ships in 2 to 4 weeks |
| 37 | Not Available | SCREW - SELF TAPPING | 21447230 | Not Available |
| 38 | Not Available | BAG DOOR - RED GASKETS / BAG INDICATOR NOT INCLUDED - ORDER NUMBERS 39 40 AND 41 | 525543001 | Not Available |
| 39 | Not Available | BAG DOOR GASKET - 34.5" | 38781054 | Not Available |
| 40 | Not Available | BAG DOOR GASKET - BOTTOM | 34123050 | Not Available |
| 41 | Not Available | BAG INDICATOR | 51151010 | Not Available |
| 42 | Not Available | TYPE Y HEPA PAPER BAG | 902419002 | Not Available |
| 43 | Not Available | HOOD / NOZZLE COVER - 13" RED | 525542001 | Not Available |
| 43 | Not Available | HANDLE RELEASE LEVER | 51873001 | Not Available |
| 44 | Not Available | NOZZLE BASE - 13" DARK CHARCOAL GRAY | 525544001 | Not Available |
| 45 | Not Available | HANDLE RELEASE LEVER | 38458043 | Not Available |
| 46 | Not Available | TRUNNION COVER - BLACK | 36131094 | Not Available |
| 47 |  | Hose Clamp Hoover U5421-9Rm Upright For: hoover | 36171044 | $1.89Add to cart Special order: ships in 2 to 4 weeks |
| 48 |  | Screw, :( Holds Nozzle - Base Upright Extractors Part Number: 21447072 for Hoover | 21447072 | $0.91Read more |
| 49 | Not Available | REAR WHEEL - DARK CHARCOAL GRAY | 43244009 | Not Available |
| 50 | Not Available | REAR AXLE | 32434007 | Not Available |
| 51 | Not Available | LOCK RING | 160017 | Not Available |
| 52 | Not Available | SCREW - SELF TAPPING | 21447228 | Not Available |
| 53 | Not Available | NOZZLE ADJUSTMENT LEVER - BLACK | 38421087 | Not Available |
| 54 | Not Available | NOZZLE ADJUSTMENT CAM - CHARCOAL | 38563007 | Not Available |
| 55 | Not Available | FRONT WHEEL ASSEMBLY | 43248066 | Not Available |
| 55 | Not Available | FRONT WHEEL | 38521009 | Not Available |
| 56 | Not Available | FRONT WHEEL SUPPORT - ONLY ORDER 43248064 | 36432027 | Not Available |
| 57 | Not Available | TORSION SPRING | 38355010 | Not Available |
| 58 |  | Wheel Shaft Hoover Upright For: hoover | 32541007 | $7.10Add to cart Special order: ships in 2 to 4 weeks |
| 58 | Not Available | WHEEL RETAINER | 36131056 | Not Available |
| 59 | Not Available | DUCT ASSEMBLY - 13" | 40309025 | Not Available |
| 60 | Not Available | BOTTOM PLATE / NOZZLE GUARD - 13" | 42246141 | Not Available |
| 61 |  | Seal-Agitator Pulley-Hoover U5445 For: hoover | 38781053 | $1.44Add to cart |
| 62 | Not Available | RIB SHOE | 013261AY | Not Available |
| 63 | Not Available | LITTER PICKER - IMPERIAL RED | 39511004 | Not Available |
| 64 | Not Available | SCREW - BOTTOM PLATE | 21447121 | Not Available |
| 65 | Not Available | AGITATOR ASSEMBLY - 13" WOODEN | 303996001 | Not Available |
| 66 | Not Available | BELT - DAYTON | 563118001 | Not Available |
| 67 |  | Cover-Abe For: hoover | 37944010 | $1.95Add to cart Special order: ships in 2 to 4 weeks |
| 68 | | Cover-Abe For: hoover | 37944010 | $1.95Add to cart Special order: ships in 2 to 4 weeks |
| 69 | Not Available | HOSE ASSEMBLY COMPLETE - 8' | 304102001 | Not Available |
| 70 | Not Available | FURNITURE NOZZLE - black | 38614045 | Not Available |
| 71 | Not Available | CREVICE TOOL - LONG SHADOW GRAY | 522305001 | Not Available |
| 72 | Not Available | DUSTING BRUSH - BLACK | 523109001 | Not Available |
| 73 | Not Available | EXTENSION TUBE - BLACK | 38634078 | Not Available |
