Schematic and parts list for: Hoover Model: CH50400
This is a list of parts and a diagram and schematic for: Hoover Model: CH50400
Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Parts for: HushTone Lite
Popular Supplies
| # | Part image | Description | SKU | Price |
| 1 | Not Available | Hoover Body Screw - 4 X 16Mm | 660294006 | Not Available |
| 2 | Not Available | Hoover Screw - 3 X 12Mm | 660203062 | Not Available |
| 3 | Not Available | Hoover Handle Assembly - Hi / Low Switch | 440004373 | Not Available |
| 4 | Not Available | Hoover Handle Screw - 4 X 18Mm | 660165010 | Not Available |
| 5 | Not Available | Hoover Upper Handle Tube Assembly | 440004374 | Not Available |
| 6 |  | HANDLE, Part Number: 517961001 for Hoover | 517961001 | $3.94Read more |
| 7 | Not Available | Hoover Lower Handle Tube Assembly | 2063001 | Not Available |
| 8 | Not Available | Hoover Sealing O-Ring - Lower Handle Tube | 562188001 | Not Available |
| 9 | Not Available | Hoover Retaining Collar - Lower Handle Tube | 517963001 | Not Available |
| 10 | Not Available | Hoover Outer Cloth Bag Assembly - Orange/ Black | 440004375 | Not Available |
| 11 |  | Cord Hook, Gray Lower Cable Winder DC40/DC41/DC65 Part Number: 920590-01 for Dyson | 92059001 | $15.86Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 12 |  | Paper Bag, :( HEPA Type Q Bulk Part Number: 302982002 for Hoover | 302982002 | $9.80Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 12 | Not Available | Hoover Type Q Bag - Allergen Inner Disposable Bag / 10 Pack | AH10021 | Not Available |
| 12 | Not Available | Hoover Type Q Bag - Hepa Inner Disposable Bag / 25 Pack | AH10178PC | Not Available |
| 13 |  | Motor, 5 Amp CH50400 Part Number: 440004376 for Hoover | 440004376 | $161.08Read more |
| 14 | Not Available | Hoover Bracket - Housing | 517947001 | Not Available |
| 15 | Not Available | Hoover Body Screw - #8 X 16Mm | 660021002 | Not Available |
| 16 | Not Available | Hoover Motor Seal | 517944001 | Not Available |
| 17 | Not Available | Hoover Motor Clamp - Right | 517942001 | Not Available |
| 18 | Not Available | Hoover Motor Clamp - Left | 517941001 | Not Available |
| 19 | Not Available | Hoover Dirt Passage Duct Assembly | 2065001 | Not Available |
| 20 | Not Available | Hoover Nozzle Base Assembly | 440004377 | Not Available |
| 21 | Not Available | Hoover Rear Wheel Assembly | 2071001 | Not Available |
| 22 | Not Available | Hoover Hubcap Assembly - Orange | 440004378 | Not Available |
| 23 | Not Available | Hoover Rear Wheel Shaft | 620859001 | Not Available |
| 24 | Not Available | Hoover E-Clip | 691040002 | Not Available |
| 25 | Not Available | Hoover Handle Stopper | 517935001 | Not Available |
| 26 | Not Available | Hoover Cord Grommet | 440004379 | Not Available |
| 27 | No Image | SPRING, HANDLE RELEASE Part Number: 690394001 for Hoover | 690394001 | $0.27Read more |
| 28 | Not Available | Hoover Main Pcb Assembly | 440003634 | Not Available |
| 29 | Not Available | Hoover Screw - Pcb | 660202016 | Not Available |
| 30 | Not Available | Hoover Silicon Washer - Pcb | 561690001 | Not Available |
| 31 | Not Available | Hoover Nozzle Guard With Scatter Guard Wiper Assembly | 440004380 | Not Available |
| 32 | Not Available | Hoover Scatter Guard Wiper Assembly | 440004385 | Not Available |
| 33 | Not Available | Hoover Edge Cleaning Bristle Assembly | 2067001 | Not Available |
| 34 | Not Available | Hoover Screw - Nozzle Guard / 7 Pack 3 X 10Mm | 1080011 | Not Available |
| 35 | Not Available | Hoover Frontwheel Assembly | 440004381 | Not Available |
| 36 | Not Available | Hoover Frontwheel Shaft | 620858001 | Not Available |
| 37 | Not Available | Hoover Screw - 4 X 16Mm Nozzle Guard | 660212060 | Not Available |
| 38 | Not Available | Hoover Brush Roll Assembly | 301428009 | Not Available |
| 39 |  | Hoover 562200001 Vacuum Beater Bar | 562200001 | $18.00Read more |
| 40 | Not Available | Hoover Nozzle Cover Assembly | 440004382 | Not Available |
| 41 | Not Available | Hoover Pig Tail Power Cord - Orange | 440004383 | Not Available |
| 42 | Not Available | Hoover Extension Cord - 35' 18 Awg Orange | 440004384 | Not Available |
