Schematic and parts book for Sanyo 150, 180 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| XX | Not Available | Carbon Brush Ass'y 69 SA-73438 Selector Lever 180 | 63025 | Not Available |
| 1 | Not Available | Dust Box Cover 150 Green | 6630005446 | Not Available |
| 1 | Not Available | Dust Box Cover 180 Silver | 6630004913 | Not Available |
| 2 | No Image | Hose Assembly Truckmount with Combo Tool 5ft | 77022 | $777.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3 |  | Axle, For Power Nozzle 2-102/2-101 Part Number: 70065 for Compact | 70065 | $2.32Read more |
| 4 | Not Available | Switch | 34025 | Not Available |
| 5 | Not Available | Upper Case 150 Green | 6630005453 | Not Available |
| 5 | Not Available | Upper Case 180 Silver | 6630004937 | Not Available |
| 6 | Not Available | Fuse | 18073 | Not Available |
| 7 | Not Available | Wire Connector | SS-3270 | Not Available |
| 8 | Not Available | Screw (4X17) | 77024 | Not Available |
| 9 | Not Available | Power Cord 20' | 30020 | Not Available |
| 10 | Not Available | Paper Bag 10 Pk | 1411 | Not Available |
| 10 |  | Paper Bag, Transformax Type P11 Micro 10 Pk | SAR-1411 | Original price was: $9.89.$8.80Current price is: $8.80.Read more |
| 11 | Not Available | Dust Box Packing | 76027 | Not Available |
| 12 | No Image | Motor, 24V, 2200 Rpm, .75Hp | 75085 | $1,867.99Read more |
| 13 | Not Available | Air Inlet Packing | NLA | Not Available |
| 14 | Not Available | Secondary Filter | 18008 | Not Available |
| 15 | Not Available | Front Motor Cushion | 76003 | Not Available |
| 16 | Not Available | Motor Complete Incl. 69-96 180 | 60040 | Not Available |
| 17 | Not Available | Lead Wire (Red) | 36055 | Not Available |
| 18 | Not Available | Lead Wire (Black) | 36057 | Not Available |
| 19 | Not Available | Rear Motor Cushion | 62015 | Not Available |
| 20 | Not Available | Motor Base | 6630005064 | Not Available |
| 21 | Not Available | Outlet Filter | 18024 | Not Available |
| 22 | Not Available | Air Spreader 180 | 6630005088 | Not Available |
| 23 | Not Available | Lower Case | 6630005095 | Not Available |
| 24 | Not Available | Name Plate 150 | 6630005460 | Not Available |
| 24 | Not Available | Name Plate 180 | 6630005101 | Not Available |
| 25 | Not Available | Indicator Filter | 18072 | Not Available |
| 26 | Not Available | Caution Label | 6630005125 | Not Available |
| 36 | Not Available | Floor Nozzle Ass'y Incl. 37-47 150 | 55017 | Not Available |
| 37 | No Image | COVER, NOZZLE TRANSFORMAX 150 Part Number: 6630005545 for Sanyo | 6630005545 | $13.11Read more |
| 38 | Not Available | Lock Ring 150 Green | 6630005491 | Not Available |
| 39 | Not Available | Elbow 150 | 55104 | Not Available |
| 40 | Not Available | Elbow Set Piece 150 | 55106 | Not Available |
| 41 | Not Available | Pivot 150 | 55108 | Not Available |
| 42 | Not Available | Rear Wheel 150 | 71030 | Not Available |
| 43 | Not Available | Nozzle Base 150 | 55122 | Not Available |
| 44 | Not Available | Front Axle 150 | 71033 | Not Available |
| 45 | Not Available | Front Wheel 150 | 71023 | Not Available |
| 46 | Not Available | Screw (4X16) 150 | 77025 | Not Available |
| 47 | Not Available | Bristle Strip 150 | 55162 | Not Available |
| 51 | Not Available | Hose Ass'y | 40012 | Not Available |
| 52 | Not Available | Hose Clip | 45010 | Not Available |
| 53 | Not Available | Lock Ring 150 Green | 6630005477 | Not Available |
| 53 | Not Available | Lock Ring 180 Silver | 6630005156 | Not Available |
| 54 | Not Available | Grip | 45020 | Not Available |
| 55 | Not Available | Upper Wand Ass'y Incl. 56-58 150 | 50030 | Not Available |
| 55 | Not Available | Upper Wand Ass'y Incl. 56-58 180 | 6630005170 | Not Available |
| 56 | Not Available | Lock Ring 150 Green | 6630005491 | Not Available |
| 56 | Not Available | Lock Ring 180 Silver | 6630005187 | Not Available |
| 57 | Not Available | Upper Wand | 50011 | Not Available |
| 58 | Not Available | Cord Hook | 70502 | Not Available |
| 59 | Not Available | Crevice Tool | 54012 | Not Available |
| 60 | No Image | WAND, LOWER SC-150 Part Number: 6630005507 for Sanyo | 6630005507 | $24.35Read more |
| 60 | No Image | WAND, LOWER COMPLETE TRANSFORMAX 180 Part Number: 6630005224 for Sanyo | 6630005224 | $9.82Read more |
| 61 | Not Available | Lock Ring 150 Green | 6630005491 | Not Available |
| 61 | Not Available | Lock Ring 180 Silver | 6630005187 | Not Available |
| 62 | Not Available | Pipe Cover | 45030 | Not Available |
| 63 | Not Available | Button | 45034 | Not Available |
| 64 | Not Available | Spring | 77297 | Not Available |
| 65 | Not Available | Lower Wand | 6630005262 | Not Available |
| 66 | Not Available | Upholstery Tool 180 | 52000 | Not Available |
| 67 | Not Available | Slide On Brush 180 | 52006 | Not Available |
| 68 | No Image | TURBO NOZZLE, COMPLETE 180 Part Number: 6630005286 for Sanyo | 6630005286 | $92.58Read more |
| 69 | Not Available | Selector Lever 180 | 73438 | Not Available |
| 70 | Not Available | Air Spreader 180 | 73439 | Not Available |
| 71 | No Image | COVER, NOZZLE 180 TRANSFORMAX Part Number: 6630005316 for Sanyo | 6630005316 | $33.75Read more |
| 72 | Not Available | Caution Label 180 | 6630005323 | Not Available |
| 73 | Not Available | Lock Ring 180 Silver | 6630005187 | Not Available |
| 74 | Not Available | Elbow 180 | 55104 | Not Available |
| 75 | Not Available | Elbow Set Piece 180 | 55106 | Not Available |
| 76 | Not Available | Pivot 180 | 55108 | Not Available |
| 77 | Not Available | E Ring 180 Silver | 6630001455 | Not Available |
| 78 | Not Available | Turbo Fan 180 | 72100 | Not Available |
| 79 | Not Available | Turbo Fan Shaft 180 | 72105 | Not Available |
| 80 | Not Available | U Ring 180 | 77205 | Not Available |
| 81 | Not Available | Washer 180 | 77165 | Not Available |
| 82 | Not Available | Washer 180 | 77167 | Not Available |
| 83 | Not Available | Sleeve Ass'y 180 | 72200 | Not Available |
| 84 | Not Available | Washer 180 | 6630001394 | Not Available |
| 85 | Not Available | Pulley 180 | 72210 | Not Available |
| 86 | Not Available | E Ring 180 | 77212 | Not Available |
| 87 | Not Available | Geared Belt 180 | 10015 | Not Available |
| 88 | Not Available | Bearing 180 | 20598 | Not Available |
| 89 | Not Available | Washer 180 | 77172 | Not Available |
| 90 | Not Available | Brushroll 180 | 20018 | Not Available |
| 91 | Not Available | Rear Wheel 180 | 71030 | Not Available |
| 92 | Not Available | Leaf Spring 180 | 77192 | Not Available |
| 93 | Not Available | Nozzle Base 180 | 55124 | Not Available |
| 94 | Not Available | Front Axle 180 | 71035 | Not Available |
| 95 | Not Available | Front Wheel 180 | 71034 | Not Available |
| 96 | Not Available | Screw (4X20) 180 | 77245 | Not Available |
