Schematic and parts book for Royal RY9000 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| XX | Not Available | Attachment Kit | M307 | Not Available |
| 1 | Not Available | Power switch | 912040 | Not Available |
| 2 | Not Available | Rectifier Ass’y | 912175 | Not Available |
| 3 | Not Available | Brushroll Micro switch | 912495 | Not Available |
| 4 | Not Available | Nozzle Guard | UA0012 | Not Available |
| 5 | Not Available | Roller | UA0015 | Not Available |
| 6 | Not Available | Belt Geared | UA0025 | Not Available |
| 7 | Not Available | Bag Chamber Top Ass’y | UA0073 | Not Available |
| 8 | Not Available | Bag Chamber Ass’y | UA0075 | Not Available |
| 9 | Not Available | Upper Handle Ass’y | UA0085 | Not Available |
| 10 | Not Available | Upper Cord Hook | UA0089 | Not Available |
| 11 | Not Available | Paper Bag Type U Microfresh | 920075 | Not Available |
| 11 | Not Available | paper Bag Type U Microlined DVc 3 pk | ROR-1491 | Not Available |
| 11 | Not Available | paper Bag Type U Microlined DVc 10 pk | ROR-1491-10 | Not Available |
| 12 | Not Available | Pivot Ring | UA0109 | Not Available |
| 13 | Not Available | Pivot Clamp | UA0110 | Not Available |
| 14 | Not Available | Lower Cord Hook | UA0111 | Not Available |
| 15 | Not Available | Lower Cord Hook spring | UA0112 | Not Available |
| 16 | Not Available | Brushroll shut Off switch | UA0206 | Not Available |
| 17 | Not Available | socket Ass’y | UA0207 | Not Available |
| 18 | Not Available | Light Blub | NLA | Not Available |
| 19 | Not Available | socket Clip | UA0065 | Not Available |
| 20 | Not Available | Power Cord | UA0211 | Not Available |
| 21 | Not Available | internal Cord | UA0212 | Not Available |
| 22 | Not Available | Brushroll Ass’y | UA0340 | Not Available |
| 23 | Not Available | Right Bristle strip | UA0348 | Not Available |
| 24 | Not Available | Left Bristle strip | UA0349 | Not Available |
| 25 | Not Available | HePA Filter Ass’y | UA0130 | Not Available |
| 26 | Not Available | Lower Hose Ass’y | UA0158 | Not Available |
| 27 | Not Available | Blower Motor Ass’y | UA0200 | Not Available |
| 28 | Not Available | Brush Motor Ass’y | UA0430 | Not Available |
| 29 | Not Available | Wheel Retainer | 710102 | Not Available |
| 30 | Not Available | Nozzle Base | UA0010 | Not Available |
| 31 | Not Available | Circuit Breaker And Brush Motor | UA0210 | Not Available |
| 32 | Not Available | Lower Handle Tube | UA0121 | Not Available |
| 33 | Not Available | Lower dirt Tube Gasket | UA0098 | Not Available |
| 34 | Not Available | Hose Accessory door | UA0130 | Not Available |
| 35 | Not Available | Bag Chamber Filter | UA0074 | Not Available |
| 36 | Not Available | Height Adjustment Pedal | UA0029 | Not Available |
| 37 | Not Available | Threshold stop | UA0155 | Not Available |
| 38 | Not Available | Base Gasket | UA0165 | Not Available |
| 39 | Not Available | Rear Motor Housing | UA0066 | Not Available |
| 40 | Not Available | Hdight Adjustment Bracket | UA0023 | Not Available |
| 41 | Not Available | Height Adjustment Housing | UA0050 | Not Available |
| 42 | Not Available | Head Light Lens | UA0064 | Not Available |
| 43 | Not Available | Upper dirt Tube Gasket | UA0084 | Not Available |
| 44 | Not Available | Hose W/Plastic Wand Assembly | UA0186 | Not Available |
