Schematic and parts book for Royal RY8000 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Popular Supplies
| # | Part image | Description | SKU | Price |
| 1 | Not Available | SCREW | R0250100 | Not Available |
| 2 |  | Screw, Combo Head O86900 Part Number: 1720430000 for Royal | 1720430000 | $0.26Read more |
| 3 | Not Available | SWITCH | 1120303000 | Not Available |
| 4 | Not Available | STYLE 9 BELT / 2 PACK | 3990220044 | Not Available |
| 5 | Not Available | BELT GUIDE CLIP | 1720380000 | Not Available |
| 6 | Not Available | CASTER PAL NUT | 1863054000 | Not Available |
| 7 | No Image | PEDAL, HANDLE RELEASE 089900 Part Number: 1990205B00 for Royal | 1990205B00 | $3.17Read more |
| 8 | Not Available | BUMPER | 2990115B00 | Not Available |
| 9 | Not Available | MOTOR COVER | 2864095600 | Not Available |
| 10 | Not Available | MOTOR AIR DUCT | 1863109600 | Not Available |
| 11 | Not Available | MOTOR DUCT SEAL | 1863112600 | Not Available |
| 12 | Not Available | NEON LAMP | 1863168000 | Not Available |
| 13 | Not Available | STRAIN RELIEF | 1863130600 | Not Available |
| 14 | Not Available | BACK PANEL ASSEMBLY | 2863598600 | Not Available |
| 15 | No Image | COVER, SWITCH RY6000 Part Number: 1863295600 for Royal | 1863295600 | $1.82Read more |
| 16 | No Image | PIPE, TUBE NOZZLE 086300 086310 086400 086410 Part Number: 1863335600 for Royal | 1863335600 | $3.52Read more |
| 17 | Not Available | HOSE INLET RETAINER | 1863337600 | Not Available |
| 18 | Not Available | HANDLE ASSEMBLY w/ GRIP | 2990020000 | Not Available |
| 19 | Not Available | TOOL CADDY ASSEMBLY | 2863175600 | Not Available |
| 20 | Not Available | CORD HOOK | 1920015B00 | Not Available |
| 21 | Not Available | CREVICE TOOL | 1920035600 | Not Available |
| 22 | Not Available | PIVOT CLAMP | 1920140000 | Not Available |
| 23 | Not Available | POWERCORD 32 FT | 1990081600 | Not Available |
| 24 | No Image | MOTOR, SWIVEL GLIDE 086540 Part Number: 2630865000 for Royal | 2630865000 | $61.88Read more |
| 25 | Not Available | TELESCOPIC WAND | 2863360600 | Not Available |
| 26 | Not Available | QUAD BRUSH ROLL ASSY SILVER | 2990056000 | Not Available |
| 27 | Not Available | NOZZLE BASE ASSEMBLY | 2990114600 | Not Available |
| 28 | Not Available | CASTER | 2912370600 | Not Available |
| 29 | Not Available | CENTER SUPPORT ASSEMBLY | 2980247600 | Not Available |
| 30 | No Image | COVER, NOZZLE 09800 PLUM Part Number: 2990100L00 for Royal | 2990100L00 | $10.86Read more |
| 31 | Not Available | FRONT PANEL ASSEMBLY | 2865142AP0 | Not Available |
| 32 | Not Available | FILTER SUPPORT | 1863420600 | Not Available |
| 33 | Not Available | BAG CHAMBER FILTER microfresh | 1863118000 | Not Available |
| 34 | Not Available | FRONT PANEL EXHAUST FILTER | 3865132044 | Not Available |
| 35 | Not Available | MECHANICAL FBI | 2864300000 | Not Available |
| 36 | Not Available | MOTOR GROMMET | 1863105600 | Not Available |
| 37 |  | Paper Bag, Type U Ultra MVP Micro Fresh 3 Pk Part Number: 3920750001 for Royal | 3920750001 | $15.36Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 37 | Not Available | TYPE U MICROFRESH BAGS 7 PACK | 3115016000 | Not Available |
| 38 | Not Available | STRETCH HOSE ASSEMBLY | 2864172600 | Not Available |
| 39 |  | MACHINE END, HOSE 086300 086310 086400 086410 Part Number: 1863411600 for Royal | 1863411600 | $1.10Read more |
| 40 | Not Available | LOWER HOSE ASSEMBLY | 2990230Q00 | Not Available |
| 41 | Not Available | DIRT PASSAGE COVER | 1990246600 | Not Available |
| 42 | Not Available | BRACKET SHOULDER SCREW | 1990258000 | Not Available |
| 43 | Not Available | IDLER PULLEY ASSEMBLY | 2990280000 | Not Available |
| 44 | Not Available | BRUSHROLL SHUT OFF LEVER | 1990186000 | Not Available |
| 45 | Not Available | BRUSHROLL SHUTOFF SHAFT | 1990211600 | Not Available |
| 46 | Not Available | BRUSHROLL SHUT OFF KNOB | 1990181B00 | Not Available |
| 47 | Not Available | BRUSHROLL SHUTOFF WASHER | 1990188B00 | Not Available |
| 48 | Not Available | ROLLER LIFTER ASSEMBLY | 2990198600 | Not Available |
| 49 | Not Available | CHROME NOZZLE GUARD ASSEMBLY | 2865141000 | Not Available |
| 50 | Not Available | BELT SEAL | 1990225000 | Not Available |
| 51 | Not Available | TOOL CLIP | 1690360600 | Not Available |
| 52 | Not Available | 2 IN 1 TOOL | 2920215600 | Not Available |
| 53 | Not Available | HANDLE RELEASE STOP | 1864500600 | Not Available |
| 54 | Not Available | BRACKET SCREW | 1990248000 | Not Available |
| 55 | Not Available | WASHER | 1990249000 | Not Available |
| 56 | Not Available | FRONT FILTER COVER ASSEMBLY | 2865140000 | Not Available |
| 57 | Not Available | FRONT PANEL EXHAUST GASKET | 1865177000 | Not Available |
| 58 | Not Available | LENS | 1864225000 | Not Available |
| 59 | Not Available | SOCKET ASSEMBLY & DIODE | 1863221000 | Not Available |
| 60 | Not Available | BULB WEDGE BASE #906 | 1920906000 | Not Available |
| 61 | Not Available | HANDLE GRIP SOFT | 1990022B00 | Not Available |
| 62 | Not Available | FRONT PANEL LATCH | 1863147600 | Not Available |
| 63 | Not Available | GRIP SWITCH COVER (right & left) | 1990023AP0 | Not Available |
