Schematic and parts book for Royal ry7400 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| ** | Not Available | ATTACHMENT TOOL KIT | M308 | Not Available |
| 1 | Not Available | UPPER HANDLE ASSEMBLY | PD0740 | Not Available |
| 2 | Not Available | SWITCH | PD0425 | Not Available |
| 3 | Not Available | BACK PANEL | PD0030B | Not Available |
| 4 | Not Available | BELT ACTUATOR PEDAL | PD0320 | Not Available |
| 5 | Not Available | FILTER COVER | PD0070 | Not Available |
| 6 | Not Available | FILTER FRAME ASSEMBLY | PD0075 | Not Available |
| 7 | Not Available | FRONT PANEL ASSEMBLY | PD0040 | Not Available |
| 8 | Not Available | LENS | PD0130 | Not Available |
| 9 | Not Available | BAG CHAMBER FILTER | PD0265 | Not Available |
| 10 | Not Available | FRONT PANEL GASKET | PD0175 | Not Available |
| 11 | Not Available | UPPER CORD HOOK | PD0435 | Not Available |
| 12 | Not Available | HOSE CONNECTOR | PD0190 | Not Available |
| 13 | Not Available | LOWER CORD HOOK | PD0450 | Not Available |
| 14 | Not Available | TOOL CLIPS | PD0080 | Not Available |
| 15 | Not Available | LOWER HOSE | PD0195 | Not Available |
| 16 | Not Available | HANDLE RELEASE PEDAL | PD0325 | Not Available |
| 17 | Not Available | BELT ACTUATOR LEVER | PD0315 | Not Available |
| 18 | Not Available | LOWER DIRT TUBE | PD0140 | Not Available |
| 19 | Not Available | BRUSH ROLL ASSEMBLY | PD0210 | Not Available |
| 21 | Not Available | FRONT ROLLER | PD0145 | Not Available |
| 22 | Not Available | NOZZLE RELEASE SCREW | PD0025 | Not Available |
| 23 | Not Available | HANDLE RELEASE PIN | PD0330 | Not Available |
| 24 | Not Available | REAR WHEEL AXLE | PD0085 | Not Available |
| 25 | Not Available | FRONT ROLLER AXLE | PD0020 | Not Available |
| 26 | Not Available | FRONT PANEL SPRING | PD0281 | Not Available |
| 27 | Not Available | HANDLE RELEASE SPRING | PD0335 | Not Available |
| 28 | Not Available | FBI LAMP | PD0185 | Not Available |
| 29 | Not Available | DUSTING BRUSH | PD0170 | Not Available |
| 30 | Not Available | CREVICE TOOL | PD0160 | Not Available |
| 31 | Not Available | UPHOLSTERY TOOL | PD0165 | Not Available |
| 32 | Not Available | TELESCOPIC WAND ASSEMBLY | PD0152 | Not Available |
| 33 | Not Available | STYLE 14 BELT | PD0340 | Not Available |
| 34 | Not Available | TYPE U BAG / ROYALAIRE - 7 PACK | 115016 | Not Available |
| 35 | Not Available | NOZZLE COVER ASSEMBLY | PD0110 | Not Available |
| 36 | Not Available | HOSE ASSEMBLY | PD0246 | Not Available |
| 37 | Not Available | HOSE ADAPTOR COVER | PD0010 | Not Available |
| 38 | Not Available | HOSE ADAPTOR VALVE | PD0030 | Not Available |
