Schematic and parts book for Royal RY7050 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Popular Supplies
| # | Part image | Description | SKU | Price |
| 1 | Not Available | SCREW | 1250100000 | Not Available |
| 2 |  | Screw, Combo Head O86900 Part Number: 1720430000 for Royal | 1720430000 | $0.26Read more |
| 3 | Not Available | SWITCH | 1120303000 | Not Available |
| 4 |  | Belt, Dirt Devil Upright Style 4/5 2 Pk Part Number: 3720310001 for Royal | 3720310001 | $12.96Add to cart Special order: ships in 2 to 4 weeks |
| 4 |  | Compatible alternateBelt, dirt devil 4/5 royal 4 & 5 Fantom Fury Regina Housekeeper Plus More Product Details | ROR-1010 | $6.00Add to cart |
| 4 |  | Compatible alternateRoyal dirt devil Belt 2pk type 4/5, 4 and 5 DVC OEM 720310P 1720410001 More Product Details | ROR-1025 | $6.00Add to cart |
| 5 | Not Available | BELT GUIDE CLIP | 1720380000 | Not Available |
| 6 | Not Available | CASTER PAL NUT | 1863054000 | Not Available |
| 7 | Not Available | HANDLE RELEASE PEDAL | 1863060B00 | Not Available |
| 8 | No Image | BUMPER, SWIVEL GLIDE 086350 Part Number: 1865088B00 for Royal | 1865088B00 | $13.54Read more |
| 9 | Not Available | MOTOR COVER | 2864095600 | Not Available |
| 10 | Not Available | MOTOR AIR DUCT | 1863109600 | Not Available |
| 11 | Not Available | MOTOR DUCT SEAL | 1863112600 | Not Available |
| 12 | Not Available | NEON LAMP | 1863168000 | Not Available |
| 13 | Not Available | STRAIN RELIEF | 1863130600 | Not Available |
| 14 | Not Available | HANDLE RELEASE PEDAL SPRING | 1690350000 | Not Available |
| 15 | No Image | COVER, SWITCH RY6000 Part Number: 1863295600 for Royal | 1863295600 | $1.82Read more |
| 16 | Not Available | NOZZLE COVER FELT | 1863307700 | Not Available |
| 17 | Not Available | BELT COVER FELT | 1863308000 | Not Available |
| 18 | No Image | PIPE, TUBE NOZZLE 086300 086310 086400 086410 Part Number: 1863335600 for Royal | 1863335600 | $3.52Read more |
| 19 | Not Available | HOSE INLET RETAINER | 1863337600 | Not Available |
| 20 | Not Available | CORD HOOK | 1920015B00 | Not Available |
| 21 | Not Available | CREVICE TOOL | 1920035600 | Not Available |
| 22 | Not Available | PIVOT CLAMP | 1920140000 | Not Available |
| 23 | Not Available | POWERCORD 32 FT | 1990081600 | Not Available |
| 24 |  | Motor Assy-Royal 086300/086400 Swivel-Glide D/D For: dirt devil | 2630172000 | $106.17Read more |
| 25 | Not Available | TELESCOPIC WAND | 2863360600 | Not Available |
| 26 | Not Available | BRUSH ROLL ASSY SILVER QUAD | 2990055000 | Not Available |
| 27 | Not Available | NOZZLE BASE ASSEMBLY | 2863544600 | Not Available |
| 28 | Not Available | CASTER | 2912370600 | Not Available |
| 29 | Not Available | HEIGHT ADJUSTMENT ASSEMBLY | 2863040000 | Not Available |
| 30 | Not Available | NOZZLE COVER ASSEMBLY | 2863569AP0 | Not Available |
| 31 | Not Available | LOWER HOSE ASSEMBLY | 2863087Q00 | Not Available |
| 32 | Not Available | BACK PANEL ASSEMBLY | 2863598600 | Not Available |
| 33 | Not Available | TOOL CADDY ASSEMBLY | 2863175600 | Not Available |
| 34 | Not Available | HANDLE ASSEMBLY | 2990020000 | Not Available |
| 35 | Not Available | HOSE ASSEMBLY STRETCH | 2864172600 | Not Available |
| 36 |  | Paper Bag, Royal Style U Ultra 89200 3 Pk Part Number: 3920047001 for Royal | 3920047001 | $6.99Add to cart Special order: ships in 2 to 4 weeks |
| 36 | Not Available | TYPE U MICROFRESH BAGS 7 PACK | 3115016000 | Not Available |
| 37 | Not Available | FRONT PANEL ASSEMBLY | 2865143AP0 | Not Available |
| 38 | Not Available | 2 in 1 FLOOR TOOL ASSEMBLY | 2920215600 | Not Available |
| 39 |  | MACHINE END, HOSE 086300 086310 086400 086410 Part Number: 1863411600 for Royal | 1863411600 | $1.10Read more |
| 40 | Not Available | MOTOR GROMMET | 1863105600 | Not Available |
| 41 | Not Available | MICROFRESH FILTER BAG CHAMBER | 1863118000 | Not Available |
| 42 | Not Available | FRONT PANEL FILTER ASSEMBLY | 3865132044 | Not Available |
| 43 | Not Available | TOOL CLIP | 1690360600 | Not Available |
| 44 | Not Available | LENS | 1864225000 | Not Available |
| 45 | Not Available | BULB WEDGE BASE #906 | 1920906000 | Not Available |
| 46 | Not Available | SOCKET ASSEMBLY w/DIODE | 1863221000 | Not Available |
| 47 | Not Available | FILTER SUPPORT | 1863420600 | Not Available |
| 48 | Not Available | MECHANICAL FBI | 2864300000 | Not Available |
| 49 | Not Available | FRONT PANEL EXHAUST GASKET | 1865177000 | Not Available |
| 50 |  | COVER, EXHT FILTER SWIVEL GLIDE 086500/086505 Part Number: 2865137600 for Royal | 2865137600 | $5.61Read more |
| 51 | Not Available | HANDLE GRIP SOFT | 1990022B00 | Not Available |
| 52 | Not Available | HANDLE LATCH FRONT PANEL | 1863147600 | Not Available |
| 53 | Not Available | GRIP SWITCH COVER (right & left) | 1990023AP0 | Not Available |
