Schematic and parts book for powr-flite PFX1080CW Cover Shot. Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | No Image | NUT, No 10-24 KEP ZINC | 7BF003 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 2 |  | Washer Plain no 10 ID SS | 17850 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3 | No Image | Screw TFT B PanHd Zn No.10 16x1/2 | 19565 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 4 | No Image | Motor,Extractor,120,VAC,Ametek,3 STG,ETL | X1038 | $195.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 5 | No Image | Gasket, Flat Airwatt Motor 5/8in Neoprene Blend | X9740 | $13.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 6 | No Image | Rod, 10/24 5.5 All Thread Stud 18-8 SS | 72000A | $7.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 7 | No Image | Spacer, Vac Motor (98190) | 30070 | $12.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 8 | No Image | NUT, No 10-24 KEP ZINC | 7BF003 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 9 | No Image | Solution Hose 1500 P.S.I. | X9315 | $0.00Read more |
| 10 | No Image | Clamp 1/4 Worm Gear SS Hex Slot Phil SAE Size 4 | 7DL003 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 11 |  | Elbow, Nylon 90 Deg 3/8 NPT X 3/8 Hose Barb | PX15 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 12 |  | Clamp 2.5 Worm Gear SS Hex Slot Size 32 | PX215 | $8.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 13 |  | Cuff, Hose End 1.5 to 2 Wire Reinforced | HJ7 | $23.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 14 |  | Screw 1/4 20x3/4 Phil PH MS SS | 7EW001 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 15 | No Image | Ferrule Hose .59 OD | PX161 | $12.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 16 | No Image | Barb Swivel 1/4H X 1/4M | X9316 | $26.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 17 | No Image | Elbow Street 1/4 90 Degree Brass | PC49 | $14.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 18 | No Image | Reducer, 3/8 To 1/4 | PC20 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 19 | No Image | Pump,Extractor,110,VAC,120psi,Aquatec | AQ120 | $302.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 20 | No Image | Screw Hex Head Cap 1/4-20x1-1/4 ZP Gr5 | X8226 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 21 |  | Plate, Heater/Pump Mid Size Extractor | X9465 | $42.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 22 | No Image | Nut KEP 1/4 - 20 Zinc | 7BF004 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 23 | No Image | Cord,Extractors,25ft,Yellow,12/3 SJTW | M1374 | $149.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 24 |  | SCREW, No 6-32X5/8 PHIL PAN MS SS | 7DW001 | $1.99Read more |
| 25 | No Image | Receptacle, Flanged Inlet Straight Blade | X9429 | $25.99Read more |
| 26 | No Image | NUT, 6-32 LOCK W/NYLON INSERT ZINC | X8257 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 27 |  | Warning Label Dryer and Spotter | X8976 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 28 |  | SCREW, 8-32X2 PHIL PAN M/S ZINC BULK | 72703A | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 29 | No Image | Cover Fan | 72702A | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 30 | No Image | Fan Cooling 120V 92MM 35 Cfm | 72700A | $101.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 31 | No Image | Nut 8-32 Lock with Nylon Insert | X8260 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 32 |  | Nut, Push 1/2 | 7GL002 | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 33 |  | Wheel 10-1/2bore Blk with Gray Tire Midsize Ext | X9063 | $53.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 34 |  | WASHER, 1/2 USS FLAT 18-8 SS | 7CM007 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 35 |  | Rear Axle, .50 Dia X 20.25 Mid Size Extractor | X9463 | $19.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 36 | No Image | 1/4 X 20 FLANGED SERRATED NUT | X9528 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 37 |  | SPACER, CASTER CFR MID SIZE | 72783A | $6.99Read more |
| 38 |  | Caster Assembly, Wheel 4 In., Grey, Extractors | X9153 | $26.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 39 | No Image | Washer 5/16 SAE Flat Zinc | X8218 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 40 |  | Screw Hex Head Cap 1/4-20x1 | X8211 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 41 | No Image | Bracket | X9022 | $0.00Read more |
| 42 | No Image | Heater, 1200 Watt (12 Ohms) | PF1200 | $1,505.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 43 | No Image | Screw No.8 5/8 Tapping Phil PH Blk Zinc | 72387A | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 44 | No Image | Cover, Heater Mid Size Extractor | X9464 | $57.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 45 | No Image | Barb 1/4 X 1/4 Male Pipe Steel | X9492 | $15.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 46 |  | Quick Disconnect .25 Female | PX6 | $33.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 47 |  | WASHER .400 ID 1.50 OD ZP | X8239 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 48 | No Image | Solution Hose 1500 P.S.I. | X9315 | $0.00Read more |
| 49 | No Image | Screw 8-32X3/8 PHMS SS | 7DM004 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 50 |  | Plate, Muffler Mid Size Extractor | X9471 | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 51 |  | FOAM, MUFFLER MID SIZE EXTRACTOR | X9470 | $5.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 52 | No Image | Detail Tool 1-1/2in SS 3.5in head 400psi | AA1621 | $347.99Read more |
| 53 |  | Quick Disconnect, Female 1/8 | 70100A | $39.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 54 | No Image | Barb Hose 1/4H 1/8 Male | PC66 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 55 | No Image | Solution Hose | X8542 | $0.00Read more |
| 56 |  | Hose 20ft THMD Gry/Blk Insider Outside w/o Cuffs | X8550 | $86.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 57 |  | Cuff, InSider Swivel With Hole TMHD RCP SHP Black | K1157 | $16.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 58 |  | Hose Guard | X9011 | $13.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 59 | No Image | Hose Ferrule 1/2" O.D. | X9317 | $0.00Read more |
| 60 |  | Barb, Hose 1/4 H - 1/4 M NPT | 7AT003 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 61 |  | Quick Disconnect, .25 Male/Male 2 Way Shut Off | PX5 | $12.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 62 |  | Plate, Medex 100 PSI | X9494 | $10.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 63 |  | Base, Mid Size Extractor 120V, Black Ral No 9017 | X1050120 | $379.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 64 | No Image | NUT, 10-32 KEP ZINC | 7BF008 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 65 |  | Housing,Extractors,Vacuum Chamber,Self Contained | X9467 | $15.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 66 |  | GASKET, VACUUM CHAMBER | X9468 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 67 |  | NUT, 10-24 NYLON INSERT LOCK 18-8 SS | 7BF030 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 68 |  | Plate, Vacuum | X9466 | $42.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 69 | No Image | SCREW 10-32 X 1 PHIL PAN M/S BLK ZINC | X8851 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 70 | No Image | LABEL GROUND SYMBOL | X9214 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 71 |  | Hose Vacuum 2 In Dia Bulk Grey See Cut Lengths | 7CZ001 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| # | Part image | Description | SKU | Price |
| 1 | No Image | SCREW No 6 X 1/2 SS PAN HEAD PHIL | X8261SS | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 2 | No Image | SCREW, 8-32X1/2 PHIL PAN SS MS 18-8 SS | 7BS002 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3 |  | Hinge, Solution Tank Lid | X9450 | $5.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 4 |  | LID SOLUTION TANK MID SIZE REV03 | X9451 | $29.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 5 | No Image | LOCKNUT, 8-32, NYLON, 18-8 SS | HDW1000 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 6 | No Image | Nut KEP 1/4 - 20 Zinc | 7BF004 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 7 | No Image | ROPE SOLID BRAID | 72660A | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 8 | No Image | End Loop, With Two Holes 16G | X9069 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 9 |  | Screw Hex HD Cap 1/4 20x1/2 SS | 19240 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 10 |  | Side Strap, Mid Size Extractor | X9475 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 11 | No Image | Washer 1/4 Flat USS Zinc | X8235 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 12 | No Image | BOLT, 1/4-20X2-1/2 HEX TAP18-8 SS | 71639A | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 13 | No Image | SCREW 10-32 X 1 PHIL PAN M/S BLK ZINC | X8851 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 14 | No Image | NUT, 10-32 KEP ZINC | 7BF008 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 15 | No Image | Drain Hose Plug Compatable With PAS37 Hose | PAS36 | $12.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 16 | No Image | Hose Drain PFX900S Cascade PFX1350 | PAS37 | $8.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 17 |  | SCREW, 10-32X1/2 PHIL PAN MS 18-8 SS | 71651A | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 18 | No Image | Clip Spring, Black | 72173A | $7.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 19 | No Image | PAD SPRING CLIP | 72669A | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 20 |  | GASKET NUT PLATE PFMA ELITE | 72175A | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 21 |  | Clip, Nut Plate Midsize Extractor | 72170A | $12.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 22 | No Image | Screw 1/4 20x1/2 Phil PH Blk 18-8 SS | 7BS003BLK | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 23 | No Image | SCREW, 1/4-20 1 1/2 MACHINE | X9359 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 24 | No Image | Strap, Front, Mid Size Extractor | X9444 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 25 | No Image | Spacer 1/2 ID X 3/4 OD X 1/4 Long | 72635A | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 26 | No Image | Nut 1/4-20 Lock Nylon Insert | X8237 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 27 | No Image | Plug, Counter Hex 1/2 | 7AF003 | $7.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 28 |  | Screw 1/4 20x1/2 Phil PH MS 18-8 SS | 7BS003 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 29 |  | Bracket, Drain Hose | X9448 | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 30 | | Elbow, Nylon 90 Deg 3/8 NPT X 3/8 Hose Barb | PX15 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 31 |  | REDUCER 1/2 TO 3/8 | PC22 | $5.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 32 | No Image | Clamp 1/4 Worm Gear SS Hex Slot Phil SAE Size 4 | 7DL003 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 33 | No Image | Clamp 1/2 Worm Gear SS Hex Slot Phil SAE Size 6 | 7DL008 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 34 | No Image | Filter,Extractor,Inline,Midsize,with housing | PX303 | $19.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 35 | No Image | Hose 300PSI Solution 3/8 ID X 1/8 Wall | PX3H | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 36 | No Image | Label, Powrflite W/O Shadow | X8401A | $5.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 37 | No Image | TANK SOLUTION MID SZ EXTRACTOR BLUE RAL NO 5005 | X1052BLUE | $327.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 38 |  | WASHER, RUBBER .29ID .688OD 1/8 80 DURO | 72667A | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 39 | No Image | WASHER M6 X 20 X 1.65 FENDER SS CIMEX | 0006000503 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 40 |  | 1/4 X 3/4-20 SCREW Part Number 17160 for Simplicity Models SCE | 17160 | $2.19Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 41 | No Image | Gasket, Strip, Tank Medex | X9483A | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | Standpipe Sub Assembly | 72628B-SUB | Not Available |
| 2 | Not Available | Defoamer Warning Label | X9003 | Not Available |
| 3 | No Image | Screw No.8 5/8 Tapping Phil PH Blk Zinc | 72387A | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 4 |  | LID, 6 Inch Clear W/Blk Ring Extractor | PX103 | $33.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 5 |  | Gasket LID 8 OD X 6.625 ID | PX103G | $11.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 6 | No Image | TANK RECOVERY MID SZ EXTRACTOR BLUE RAL NO 5005 | X1051BLUE | $459.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 7 | No Image | All Thread, 5/16-18 X 18.75 Zinc | X9452 | $14.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 8 | No Image | Label Serial Number 2X2 Plain | X8459 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 9 | No Image | Label Qualified Made In The USA 1.618 X 1.618 | X1003 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 10 |  | WASHER, ID.299 OD.622 THK.055 ZINC PLATED | X8858 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 11 | | Screw 1/4 20x1/2 Phil PH MS 18-8 SS | 7BS003 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 12 | No Image | Tank Hinge PFX900S PFX1350 | X9014 | $13.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 13 | | Screw 1/4 20x3/4 Phil PH MS SS | 7EW001 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 14 | No Image | Nut KEP 1/4 - 20 Zinc | 7BF004 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 15 | No Image | Clamp 1-1/2 Worm Gear SS Hex Slot Hd SAE Size 20 | 7DL005 | $8.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 16 |  | Hose 1-1/2 Wire-Reinforced Black | 72656A | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 17 |  | GASKET DRAIN INNER 1.330 ID 1.825 OD .25 THICK | 72679A | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 18 |  | GASKET DRAIN OUTER 1.330 ID 2.330 OD .25 THICK | 72680A | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 19 |  | Drain Fitting, 1 Pro Series With Nut | 72677A | $12.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 20 |  | Tubing, Vinyl 1 ID 1-1/4 OD Pro Series Drain | 72678A | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 21 |  | Bulkhead Plastic 1.5 NPT X 1.5 Hose Barb | PX25 | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 22 | No Image | Gasket Dump Valve .125 Thick 1.81 ID X 2.37 OD | PX14A | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 23 |  | Elbow Fitting Plastic 90 White 1.5 FPT | PX11A | $11.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 24 | No Image | Handle, Mid Size Extractor | X9453 | $35.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 25 | No Image | Washer 1/4 Flat USS Zinc | X8235 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 26 | No Image | Wheel Black 4 X 1-1/4 | X8025 | $13.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 27 | No Image | Spacer 1.625 Long .50 OD .313 ID | 72486A | $8.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 28 | Not Available | Label | X9500P | Not Available |
| 29 | No Image | NUT, 5/16-18 CAP ZP | 72148A | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 30 | | On/off Switch Part Number 32966 for Cleanmax and Simplicity Models CM-WAV,SCE | 32966 | $10.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 31 | No Image | Plug, 1/2 Inch Black Nylon | 71804A | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 32 | No Image | Light, Neon W/ Lens 120V Amber | X8102 | $15.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 33 | No Image | Switch Plate, 3-Switch 2 Light Mid-Size Extractor | X1007 | $33.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 34 |  | Gasket, Switch Plate Medex | X9484 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 35 |  | Gasket, Dump Valve .1875 Thick 1.75 ID X 2.50 OD | PX14 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 36 | No Image | Float, Cage W/Heavy Ball | PX31 | $57.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | AccessoriesExtractor1-1/2 InchDetail ToolStainless Steel3-1/2 Head400psi | AA162 | Not Available |
