Schematic and parts book for powr-flite PF82HF . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| Not Shown | No Image | Dampner End Cap (Lh) | DECLH | $0.00Read more |
| Not Shown | No Image | Dampner End Cap (Rh) | DECRH | $0.00Read more |
| 1 | No Image | Hose w/Upper/Lower Adapter PF83 TC5845A SC5845A | ER139 | $48.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 2 | No Image | Hose w/Upper/Lower Adapter PF83 TC5845A SC5845A | ER139 | $48.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3 | Not Available | Base Felt | BF | Not Available |
| 4 | No Image | Height Adjustment Knob | ER222 | $0.00Read more |
| 5 |  | VAC BASE ASSEMBLY PF82HF PF83 SC5845B SC5815B | ER224 | $104.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 6 |  | Spring Package | X1844 | $14.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 7 | No Image | WHEEL CARRIAGE | ER225 | $20.99Read more |
| 8 | No Image | FRONT AXLE PF82HF PF83 | ER226 | $8.99Read more |
| 9 | No Image | FRONT WHEEL PF82HF | ER228 | $8.99Read more |
| 10 | No Image | Belt,Vacuum,Upright,2 Pack | 09024 | $10.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 11 | Not Available | Screw | ER230 | Not Available |
| 12 | No Image | Hose w/Upper/Lower Adapter PF83 TC5845A SC5845A | ER139 | $48.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 13 |  | HANDLE SCREW PF82HF PHILLIPS HOLDS HANDLE TO UNIT | ER230A | $8.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 14 | No Image | Hood Assembly Packaged | X1845 | $0.00Read more |
| 15 | No Image | HANDLE RELEASE SPRING PF82HF PF83 | ER232 | $6.99Read more |
| 16 | Not Available | Screw | ER230 | Not Available |
| 17 |  | MOTOR CLAMP PF82HF | ER455 | $8.99Read more |
| 18 | No Image | HANDLE RELEASE PF82HF PF83 | ER235 | $9.99Read more |
| 19 |  | Eureka Rear Wheel Clip Victory | 59084 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 20 |  | VAC WHEEL REAR PF82HF PR83 MOST EUREKA UPRIGHTS | ER236 | $16.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 21 |  | AXLE BUSHING PF82HF PF83 | ER237 | $6.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 22 |  | Eureka Rear Wheel Axle Victory PF82HF | 59095 | $12.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 23 |  | Cap, Belt,Vacuum | ER215 | $8.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 24 | Not Available | Belt Cap Felt | BCF | Not Available |
| 25 |  | Brushroll Wood 15in 5BR End | 10173 | $58.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 26 | Not Available | Included w/#14 | IW#14 | Not Available |
| 27 | No Image | Belt Guard | BG | $0.00Read more |
| # | Part image | Description | SKU | Price |
| 1 | No Image | Cord,Vacuum,40ft, Gray | ER269 | $76.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 2 | No Image | ROCKER SWITCH PF82HF PF83 PF80HF SC4570 PF80HP | ER276 | $12.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3 | No Image | Wire Splice | WS | $0.00Read more |
| 4 | No Image | REAR HOUSING PF82HF PF82 | ER278 | $165.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 5 | Not Available | Included w/#6 | IW#6 | Not Available |
| 6 | No Image | Motor Vacuum 120 VAC Assembly | ER279A | $156.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 7 | Not Available | Gasket | GAS | Not Available |
| 8 | No Image | Gasket Cyclone | X1856 | $6.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 9 | Not Available | Motor Cover | ER281 | Not Available |
| 10 | Not Available | Screw | ER230 | Not Available |
| 16 |  | SWITCH COVER ASSY MFG PN 72127-1 | ER284 | $12.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 17 | Not Available | Screw | ER230 | Not Available |
| 18 | Not Available | Screw | ER230 | Not Available |
| 19 | No Image | Lower Tool Storage | ER318 | $0.00Read more |
| 20 | Not Available | Screw | ER230 | Not Available |
| 22 | Not Available | Filter Cover | ER286 | Not Available |
| 23 | Not Available | Included w/#6 | IW#6 | Not Available |
| 24 | Not Available | Motor Cover Gasket | MoCG | Not Available |
| 25 | Not Available | Motor Hub Gasket | MHG | Not Available |
| 26 |  | Thermostat 110 Degree | X1858 | $12.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 27 | No Image | SOUND FOAM PF82HF | ER263 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| # | Part image | Description | SKU | Price |
| 1a | Not Available | Left Hand Grip | LHG | Not Available |
| 1b | Not Available | Right Hand Grip | RHG | Not Available |
| 2 | No Image | HANDLE ASSY PF82HF PF83 | ER292 | $143.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3 | Not Available | Adapter Clip | ER293 | Not Available |
| 4 | Not Available | Included w/#6 | IW#6 | Not Available |
| 5 | No Image | TORSION SPRING PF82HF PF83 | ER294 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 6 | No Image | Bag,Vacuum,Cover,Assembly | ER295 | $102.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 7 | Not Available | Bag-In-Place Arm | BIPA | Not Available |
| 8 |  | Hook, Cord,Vacuum | ER251 | $9.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 9 | | HANDLE SCREW PF82HF PHILLIPS HOLDS HANDLE TO UNIT | ER230A | $8.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 10 | No Image | TORSION SPRING PF82HF PF83 | ER301 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 11 | Not Available | Paper Bag 5 Pack | 63256A-5 | Not Available |
| 13 | Not Available | Gasket | GAS | Not Available |
| 14 | Not Available | Gasket Cyclone | GASCY | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | No Image | Belt,Vacuum,Upright,2 Pack | 09024 | $10.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 2 | Not Available | Paper Bag 5 Pack | 63256A-5 | Not Available |
| 3 |  | Filter,Vacuum,HEPA,Washable,W/Cover | ER285 | $90.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 5 | | Brushroll Wood 15in 5BR End | 10173 | $58.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| # | Part image | Description | SKU | Price |
| 1 | No Image | VAC HOSE ASSY PF82HF PF83 | ER180 | $104.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 2 | No Image | HOSE ADAPTER PF82HF SC5815A | ER187 | $13.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3 | No Image | NESTING WANDS PF82HF PF83 | ER181 | $24.99Read more |
| 4 | No Image | CREVICE WAND PF82HF | ER182 | $14.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 5 | Not Available | Included w/#3 | IW#3 | Not Available |
| 6 | No Image | HOSE COUPLING PF82HF | ER279 | $19.99Read more |
| 7 | No Image | COMBINATION BRUSH PF82HF PF83 | ER186 | $17.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 8 | Not Available | Hardware Package | HWP | Not Available |
