Schematic and parts book for powr-flite PF61EC-N, pf16 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Popular Supplies
| # | Part image | Description | SKU | Price |
| 1 | Not Available | Handle Grip | B431-2300 | Not Available |
| 2 | No Image | HANDLE END CAP BLACK ULW | B4311014 | $3.99Add to cart Special order: ships in 2 to 4 weeks |
| 3 |  | Handle Tube W/Grip S10E R10E | D431-2406 | $22.99Add to cart Special order: ships in 2 to 4 weeks |
| 4 | Not Available | Screw #8-18 x 5/8" | A732-8314 | Not Available |
| 5 |  | Cord Hook Part Number B430-1205 for Simplicity and Riccar Models F3100, F3300, F3300C, S10E,F3400... | B4301205 | $4.99Add to cart |
| 6 |  | Screws #10 Handle Bolts S10E r10E | A432-0705 | $2.99Add to cart |
| 7 |  | Handle Tube Bracket S10E R10e | B431-2914E | $4.99Add to cart Special order: ships in 2 to 4 weeks |
| 8 | No Image | ULW Handle Lower Duct 2 Cord Hooks Blk | B4312114C | $18.99Add to cart Special order: ships in 2 to 4 weeks |
| 9 |  | Lower Bag Spring Part Number B211-1204 for Simplicity and Riccar Models F3100, F3300, F3300C, S10... | B2111204 | $2.99Add to cart |
| 10 | No Image | Outer Cloth Bag | B2117900 | $0.00Read more |
| 11 |  | Lower Bag Clip Commercial Print (F3300C) Part Number B211-1914F for Simplicity and Riccar Models ... | B2111914F | $5.49Add to cart |
| 12 |  | Fuller Brush Paper Bags-fuller Brush 6pk Speedy Maid | 260CFR | $22.23Add to cart Special order: ships in 2 to 4 weeks |
| 13 |  | Bag Collar Bag Holder Part Number B211-3614 for Simplicity and Riccar Models F3100, F3300, F3300C... | B2113614 | $3.99Add to cart Special order: ships in 2 to 4 weeks |
| 14 |  | Bag Collar Gasket Part Number B211-6400 for Simplicity and Riccar Models F3100, F3300, F3300C, S1... | B2116400 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 15 | Not Available | Bag Collar Ring | B211-2314 | Not Available |
| 16 |  | Hex Nut #10-32 Nylon Part Number A432-0805 for Simplicity and Maytag and Riccar Models F3100, F33... | A4320805 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 17 |  | Hinged Bag Holder Kit for Riccar Ultra Light Weight | D2113614 | $13.99Add to cart |
| # | Part image | Description | SKU | Price |
| 1 | No Image | Nozzle Label | B2064800 | $0.00Read more |
| 2 | No Image | COMM ULW NOZZLE W/O LENS W/FOOT PEDAL - NO HOT STAMP | B0173414 | $21.99Add to cart Special order: ships in 2 to 4 weeks |
| 3 | Not Available | Screw #8-18 x 5/8" | A732-8314 | Not Available |
| 4 |  | Ultralight Weight Motor Assembly for Simplicity, Riccar, and CleanMax | D1131500 | $133.99Add to cart Special order: ships in 2 to 4 weeks |
| 5 |  | E-Clip .250 Part Number A732-3000 for Simplicity and Maytag and Riccar Models BRLS, BRLD, BRLD.US... | A7323000 | $2.99Add to cart |
| 6 |  | Behind Fan Washer (TEK Motor) Part Number A733-3300 for Simplicity and Maytag and Riccar Models F... | A7333300 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 7 |  | Motor Fan ULW Xenoy Material | B123-3000 | $4.99Add to cart Special order: ships in 2 to 4 weeks |
| 8 |  | Washer (TEK Motor) Part Number A733-2200 for Simplicity and Maytag and Riccar Models F3400, F3500... | A7332200 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 9 |  | ULW Motor Seal Kit RSL ZM200 ZM400 ZM600 | C1210000 | $10.99Add to cart Special order: ships in 2 to 4 weeks |
| 10 |  | ULW UPRIGHT STOP - PLASTIC RED | B016-1230 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 11 |  | Basetray Plug Non Hall Sensor Models (F3400 F3500 F3500C F3600) Part Number B016-1914 for Simplic... | B0161914 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 12 |  | ULW Basetray Assembly with Plastic Stop RSL1-5 F3300-3700 | D016-1114 | $42.99Add to cart Special order: ships in 2 to 4 weeks |
| 12 |  | Available ReconditionedReconditioned ULW Basetray Assembly with Plastic Stop RSL1-5 F3300-3700 More Product Details | D016-1114R | $37.65Add to cart |
| 13 |  | Furniture Guard Part Number B029-0314 for Simplicity and Riccar Models F3100, F3300, F3300C, S10E... | B0290314 | $4.99Add to cart Special order: ships in 2 to 4 weeks |
| 14 |  | Base Plate Wheel Axle Vibrance, SS ULW 4000 U-912 | B0100001E | $2.99Add to cart |
| 15 |  | Base Tray Wheel 23.5mm for ULW and Freedom | B0100614 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 16 |  | Single Belt for Riccar, Simplicity, and CleanMax Lightweight Vacuums | B0140814B | $6.00Add to cart Special order: ships in 2 to 4 weeks |
| 16 |  | Compatible alternateBelt-Panasonic - Flat - Ub3/Ub7 - Mc6210 - Mc6640
Also Fits Simplicity Freedom - Replacement For:... More Product Details | 17394 | $6.00Add to cart Special order: ships in 2 to 4 weeks |
| 16 |  | Compatible alternateReplacement aftermarket belt for Simplicity Freedom And Riccar Supralite R10 and S10 bissell styl... More Product Details | 36310001 | Original price was: $6.00.$4.99Current price is: $4.99.Add to cart |
| 16 |  | Compatible alternateRubber Stretch Belt for Riccar Supralight Simplicity Freedom - 2pk More Product Details | RBS2 | $10.99Add to cart Special order: ships in 2 to 4 weeks |
| 17 | No Image | Wood Brushroll | B0122800D | $0.00Read more |
| 18 |  | Base Tray Cover ULW Black Bottom Plate for Simplicity Freedom and Riccar Supralite | B015-2014 | $5.99Add to cart Special order: ships in 2 to 4 weeks |
| 19 | Not Available | Rear Wheel Axle | B010-2800C | Not Available |
| 20 |  | Rear Wheel Black Plastic Part Number B010-1314 for Simplicity and Riccar Models F3100, F3300, F33... | B0101314 | $2.99Add to cart |
| 21 |  | Circuit Breaker 5 Amp for Riccar | A028-0114B | $4.99Add to cart Special order: ships in 2 to 4 weeks |
| 22 | No Image | LABEL PLACE FOOT HERE ULW BLACK | B2061200B | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 23 | No Image | Cord,Vacuum,50ft,Black,18/3 SJT,OEM | M1377 | $56.99Add to cart Special order: ships in 2 to 4 weeks |
| 24 |  | Strain Relief Washer Part Number B034-0100 for Simplicity and Maytag and Riccar Models BRLS, BRLD... | B0340100 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 25 |  | Combination Screw M4x12Combination Screw M4x12 Part Number A732-2500 for Simplicity and Maytag an... | A7322500 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 26 |  | Fan Duct Cover Assembly with Seal for Ultralight Weight | D1233814 | $7.99Add to cart Special order: ships in 2 to 4 weeks |
| 26 |  | Available ReconditionedReconditioned Fan Duct Cover Assembly with Seal for Ultralight Weight More Product Details | D1233814R | $7.99Add to cart |
| 27 | No Image | Fan Duct Cover | B1233814 | $0.00Read more |
| 28 | Not Available | Lower Fan Housing | B123-3614 | Not Available |
| 29 | No Image | ULW UPPER FAN HOUSING BLACK XENOY MATERIAL | B1233714 | $5.99Add to cart Special order: ships in 2 to 4 weeks |
| 30 |  | Screw #5X0.5 Hi-Lo Self Threading | A7329206 | $2.99Add to cart |
| 31 |  | Foot Switch On/Off for ULW SF1 F3300 | A0280014 | $11.99Add to cart |
| 32 |  | Foot Pedal On Off ULW S20 | B0280014 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
