Schematic and parts book for Powr-Flite PF55G . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| Not Shown | No Image | Bag,Vacuum,Paper,20 Gallon,1 Pack | 155PB | $16.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 5.1 | No Image | CONNECTOR GASKET PF53 PF55 PF57 PF54 | WD23 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 5.2 | No Image | HOSE CONNECTOR PF53 PF54, PF55 PF57 | WD24 | $10.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 5.3 |  | Hose Wet/Dry 10ft Inc WD28 Bend Connector | WD25 | $87.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 5.4 | No Image | Connector PF53 PF55 PF57 PF54 | WD26 | $6.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 5.5 | No Image | HOLDER, WAND PF53 PF55 PF57 PF54 | WD27 | $5.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 5.6 | No Image | BEND CONNECTOR PF53 PF55 PF57 PF54 | WD28 | $19.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 5.7 | No Image | Wand Wet Dry 21in SS 2 Required | WD29 | $46.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 5.8 |  | VAC TOOL CREVICE BLACK, PLASTIC PF53-57 | WD32 | $10.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 5.9 |  | VAC TOOL DUST BRUSH 1-1/2 PLASTIC, BLACK PF53-57 | WD33 | $14.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 6 |  | VAC TOOL SQUEEGEE 16 1-1/2 PLASTIC BLK PF50 SERIES | WD30A | $78.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 7 |  | FLOOR BRUSH ASSY PF53 PF54 PF55 PF57 | WD31 | $60.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| # | Part image | Description | SKU | Price |
| 1.1 |  | Cord,Wet/Dry,24 Inch,Black,14/3,Pigtail | WD66C | $11.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.2 | No Image | HANDLE, HEAD PF53 PF54 | WD20A | $6.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.4 | No Image | SCREW M5 X 20 | 3238DS08 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.5 |  | TOP HOUSING PF55, 1-Switch Hole | WD19 | $35.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.6 | No Image | Bottom Block | WD282 | $0.00Read more |
| 1.7 | No Image | SCREW MARA 350 | 3208DS07 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.8 | No Image | WIRE PLATE PF53 PF55 PF57 PF54 94232 | WD17 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.9 |  | Cord,Wet/Dry,30ft,Black,16/3 SJTW | WD66 | $124.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.11 | No Image | Cord Protector,Wet/Dry | WD34 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.13 | No Image | HOUSING, MIDDLE PF53 PF55 PF57 PF54 | WD16 | $26.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.14 | No Image | GASKET PF53 PF55 PF57 PF54 94232 | WD53 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.16 | No Image | MOTOR SEAT PF55 PF57 | WD14 | $15.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.17 | No Image | BLOCKER FOR PF57 PF58 WET/DRY VACUUM | WD248 | $5.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.18 |  | TOP BLOCK PF53 PF54 PF57 | WD83 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.19 |  | MOTOR SEAT PF55 PF57 | WD11 | $53.99Read more |
| 1.22 | No Image | ROCKER SWITCH ON/OFF PF53 PF54 PF56 | WD67 | $16.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.24 | No Image | TERMINAL BLOCK PF54 PF57 | WD207 | $5.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.25 | No Image | Capacitor,Vacuum | 3215BE01 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.30 | No Image | SPONGE P53,54,56,57 | WD56 | $6.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.31 | No Image | SCREW M4X10 | 3201DS04A | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.33 |  | Motor,Vacuum,120,VAC,Grandwill International Corp | WD15 | $213.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.34 | No Image | GASKET, VAC MOTOR PF53 PF54 LOWER GASKET | WD68 | $8.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.35 | No Image | STOPPER PLATE PF53 PF55 PF57 PF54 | WD85 | $5.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.36 | No Image | SCREW MARA 350 | 3208DS07 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.37 | No Image | Cable Tie | 5101BJ01 | $0.00Read more |
| 1.38 | No Image | SCREW | 3200DS02 | $1.50Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.41 |  | GASKET PF55 PF57 | WD210 | $8.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.42 |  | Gasket PF53 PF54 PF55 PF57 | WD150 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.43 | No Image | BASE COVER, MOTOR PF53 PF55 PF57 PF54 | WD10 | $23.99Read more |
| 1.44 | No Image | SCREW MARA 350 | 3238DS11 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.45 | No Image | FLOAT PF53 PF54 PF55 PF57 | WD9 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.46 | No Image | FLOAT CAGE PF53 PF54 PF55 PF57 | WD8 | $15.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.47 | No Image | Filter,Vacuum,Synthetic,Cartridge,Washable | WD36 | $70.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.48 | No Image | SPRING, FILTER PF53 PF54 PF55 PF57 | WD37 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.49 | No Image | HOOK, FILTER PF53 PF55 PF57 | WD35 | $6.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| # | Part image | Description | SKU | Price |
| 1 | No Image | Filter,Vacuum,Frame,15 Gal,Remove Top Ring | WD7 | $30.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 2 | No Image | Cloth Filter for PF55 PF56 PF57 | WD4 | $46.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| # | Part image | Description | SKU | Price |
| 3.1 | No Image | TANK ASSEMBLY STAINLESS STEEL PF55 PF57 94236 | WD2 | $352.99Read more |
| 3.3 | No Image | LOCK BUTTON FOR WD59 PF53 PF55 PF57 | WD60 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3.4 | No Image | TIP AND POUR FIXED PLATE PF53 PF55 PF 57 | WD51 | $7.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3.5 |  | LOCK COVER FOR WD51 PF53 PF57 PF55 | WD59 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3.12 | No Image | CLAMP ASSEMBLY PF55 PF57 PF53 PF56 | WD43 | $16.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3.13 | No Image | CLIP PIN SHORT PF54 P56 PF57 | WD129 | $1.99Read more |
| 3.14 |  | CLIP PIN LONG PF43 PF56 | WD131 | $1.99Read more |
| 3.16 | No Image | SPACER FOR HANDLE PF53 PF55 PF58 | WD77 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3.17 |  | RUBBER WASHER FOR WD77 PF53 PF55 PF57 PF54 | WD76 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3.18 | No Image | GASKET, RUBBER FOR WD45 PF53 PF55 PF57 PF54 | WD50 | $8.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3.19 | No Image | SUCTION COUPLER KIT, PF53, PF54, PF55, PF57 | WD45KIT | $24.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3.20 | No Image | SUCTION COUPLER KIT, PF53, PF54, PF55, PF57 | WD45KIT | $24.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3.21 | No Image | SUCTION COUPLER KIT, PF53, PF54, PF55, PF57 | WD45KIT | $24.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3.22 | No Image | SUCTION COUPLER KIT, PF53, PF54, PF55, PF57 | WD45KIT | $24.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3.23 |  | HOLDER PF56 PF57 PF58 | WD225 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3.24 | Not Available | Handle | WD226 | Not Available |
| # | Part image | Description | SKU | Price |
| 4 |  | DOLLY ASSY. WITH HANDLE PF55 PF57 | WD1 | $366.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 4_10 | No Image | Trolley Base | WD1158 | $0.00Read more |
| 4_11 | Not Available | Screw M4 x | 3240DS-07 | Not Available |
| 4_12 | No Image | E-RING, Wheel, Wet Dry Vacs | WD126 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 4_13 | No Image | WASHER PF56 PF57 PF58 | WD229 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 4_14 | No Image | Rear Wheel, 94236, PF55, PF57 | WD41M | $73.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 4_15 | No Image | Axle | 3238LS01 | $0.00Read more |
| 4_16 | No Image | AXLE PLATE PF55 PF 57 | WD73 | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 4_17 | Not Available | Screw M5 x | 3238DS-12 | Not Available |
| 4_18 | No Image | Caster Assembly (REPLACEMENT) PF53, PF55, PF57 | WD40M | $45.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 4_19 | Not Available | Washer | 5101DW-02 | Not Available |
| 4_2 | No Image | HOLDER PF54 PF55 PF57 | WD72 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 4_20 | Not Available | Screw M8 x | 3238DS-03 | Not Available |
| 4_3 | No Image | Screw M4 X 16 Ss | 3285DS05 | $0.00Read more |
| 4_4 | No Image | SCREW MARA 350 | 3208DS01 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 4_5 | Not Available | Screw M4 x | 3287DS-02 | Not Available |
| 4_6 | No Image | HOLDER FITS WD218 PF55 PF57 | WD217 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 4_7 | No Image | Support | 3238UU02 | $0.00Read more |
| 4_8 | No Image | SCREW, M5 X 12 | 3238DS02 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 4_9 | No Image | Cover | 3238AA44 | $0.00Read more |
