Schematic and parts book for powr-flite PF1886, pf1887 Ironside. Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | No Image | HANDLE GRIP FOR PF1886 PF1887 | MV43 | $8.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 2 | No Image | Cord,Vacuum,50ft,Black,18/3 SJT,OEM | M1377 | $56.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3 | Not Available | Cord Retainer | MV22 | Not Available |
| 4 | Not Available | Screw #8 x 1/2" | MV44 | Not Available |
| 5 | Not Available | Rivet | MV45 | Not Available |
| 6 | No Image | KOBLENZ UPRIGHT CORD HOOK PF1886 PF1887 | MV19 | $6.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 7 | Not Available | Upper Handle | MV47 | Not Available |
| 8 | Not Available | Handle Nut Spacer and Screw (Old Style) | MV17 | Not Available |
| 8A | Not Available | Handle Nut Only (New Style) | MV17A | Not Available |
| 9 | Not Available | Handle Screw (New Style) | MV16A | Not Available |
| 10 | Not Available | Lower Handle | MV48 | Not Available |
| 11 | No Image | SCREW, 6-32 X 3/8 PHPH SS | X8238 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 12 | Not Available | Wheel Height Knob | MV50 | Not Available |
| 13 | Not Available | Height Adjustment Label | 17-2486-3 | Not Available |
| 14 | Not Available | Felt | 37-0136-4 | Not Available |
| 17 | Not Available | 12" Hood (PF1886 Models) | MV62 | Not Available |
| 17A | Not Available | 16" Hood (PF1887 Models) | MV97 | Not Available |
| 18 | Not Available | Hood Spring | MV07 | Not Available |
| 19 | Not Available | Nut | 02-0037-8 | Not Available |
| 20 | Not Available | Star Washer | 04-0271-9 | Not Available |
| 21 | Not Available | Vacuum Bag Support | MV51 | Not Available |
| 22 | Not Available | Screw # 10-32 x 5/8" | MV52 | Not Available |
| 23 | No Image | BALL PF1886 PF1887 | MV53 | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 24 | Not Available | Bag Knob Spacer | MV54 | Not Available |
| 25 | Not Available | Bag Knob | MV55 | Not Available |
| 26 | Not Available | Screw #10-32 x 3/4" | MV56 | Not Available |
| 26 | Not Available | Screw #10-32 x 3/4" | MV56 | Not Available |
| 27 | No Image | SCREW, SELF TAPPING Part Number: 01-0154-3 for Koblenz | 0101543 | $0.86Read more |
| 28 | Not Available | Knob Spring | MV57 | Not Available |
| 29 |  | Bag,Vacuum,Cloth,TRIPLE V W/SLIDE and SPRING BLACK | G825B | $31.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 29A | Not Available | Blue TiTex Bag | G828 | Not Available |
| 30C | No Image | BAG GARTER SPRING SANITAIRE EUREKA REPL | W2390 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 30D | Not Available | Bag Hose Zipper | MV61 | Not Available |
| 31 | No Image | BAG PAPER VACUUM ENVIRO-CLEAN 3PK | 265PB | $5.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 32 | Not Available | Chrome Bag Slide w/Spring | W2363 | Not Available |
| 33 | Not Available | Nut | MV82 | Not Available |
| 36A | Not Available | Bag Gasket | L83 | Not Available |
| # | Part image | Description | SKU | Price |
| 2 | No Image | RIGHT AIR DUCT PF1886 PF1887 | MV70 | $26.99Read more |
| 8 | No Image | REAR WHEEL AXLE PF1886 PF1887 | MV12 | $7.99Read more |
| 15 | No Image | LEFT AIR DUCT PF1886 PF1887 | MV71 | $21.99Read more |
| 16 | Not Available | Rear Wheel | MV06 | Not Available |
| 17 | Not Available | C Washer | MV30 | Not Available |
| 18 | Not Available | Bolt | MV31 | Not Available |
| 22 | Not Available | Switch Actuator Assembly | MV46 | Not Available |
| 24 | No Image | KOBLENZ UPRIGHT HANDLE SOCKET PF1886 PF1887 | MV20 | $18.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 27 | Not Available | Handle Cam | MV32 | Not Available |
| 28 | Not Available | Cam Spring | MV33 | Not Available |
| 29 | Not Available | Cam Bolt | MV34 | Not Available |
| 30 | Not Available | C Washer | MV30 | Not Available |
| 31 | Not Available | Handle Release Pedal | MV36 | Not Available |
| 32 | Not Available | Foot Pedal Spring | MV37 | Not Available |
| 37 | No Image | KOBLENZ UPRIGHT FAN COVER ASSY PF1886 PF1887 | MV15 | $14.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 39 | Not Available | Belt | MV05 | Not Available |
| 40 | Not Available | 12" Chassis (PF1886 Models) | MV41 | Not Available |
| 40A | Not Available | 16" Chassis (PF1887 Models) | MV95 | Not Available |
| 41 | No Image | 12" Bumper (Pf1886 Models) | MV58 | $0.00Read more |
| 41A | No Image | 16" Bumper (Pf1887 Models) | MV96 | $0.00Read more |
| 42 | No Image | Front Wheel | MV38 | $0.00Read more |
| 43 | No Image | Cotter Pin | MV39 | $0.00Read more |
| 44 | No Image | Screw | MV74 | $0.00Read more |
| 45 | No Image | Axle Retainer | MV75 | $0.00Read more |
| 46 | No Image | FRONT AXLE ASSEMBLY PF1886 PF1887 | MV60 | $16.99Read more |
| 47 | No Image | Left Front Axle Spring | MV65 | $0.00Read more |
| 48 | No Image | Rivet | MV67 | $0.00Read more |
| 49 | No Image | Axle Washer | MV68 | $0.00Read more |
| 50 | No Image | Axle Bushing | MV69 | $0.00Read more |
| 51 | No Image | Right Front Axle Spring | MV66 | $0.00Read more |
| 52 | No Image | VAC BRUSHROLL ASSY 12 PF1886 | MV11A | $40.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 52A | No Image | VAC BRUSHROLL ASSY 16 PF1887DC NEW STYLE | MV73 | $84.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 53 | No Image | LEFT HAND BEARING SUPPORT PF1886 PF1887 | MV13 | $5.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 53A | No Image | RIGHT HAND BEARING SUPPORT PF1886 PF1887 | MV13A | $5.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 57 |  | KOBLENZ UPRIGHT BOTTOM PLATE PF1886 PF1886DC | MV23 | $65.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 57A | No Image | 16 BOTTOM PLATE FOR PF1887 PF1887DC | MV94 | $63.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 58 | No Image | Bottom Plate Retainer | MV08 | $0.00Read more |
| # | Part image | Description | SKU | Price |
| 1A | No Image | Motor Cover | MV64 | $0.00Read more |
| 3 | No Image | Carbon Brush | MV63 | $0.00Read more |
| 4 | No Image | Carbon Brush Holder | MV21 | $0.00Read more |
| 8 | No Image | Armature Assembly | MV10 | $0.00Read more |
| 9 | No Image | Field Assembly | MV09 | $0.00Read more |
| 11 | No Image | Motor Base W/Gasket | MV27 | $0.00Read more |
| 11B |  | MOTOR BASE GASKET PF1886 PF1887 | MV49 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 14 | No Image | VAC FAN UPRIGHTS KOBLENZ U210 U230 PF1886-1887 | MV02 | $64.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 15 | No Image | Belt Pulley Nut | MV01 | $0.00Read more |
