Schematic and parts book for Powr-Flight FM100H . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| Not Shown |  | HANDLE HOOK, SQUEEGEE FM100H FM200H | WD192 | $9.99Add to cart Special order: ships in 2 to 4 weeks |
| XX |  | Squeegee Wet/Dry Front Mount 26in 17gal Poly Assy | FM100H | $292.99Add to cart Special order: ships in 2 to 4 weeks |
| 91 |  | Bracket,Vacuums,Wet/Dry,Squeegee,Mounting | WD168 | $26.99Add to cart Special order: ships in 2 to 4 weeks |
| 92 | No Image | ADJUSTING WHEEL, WINGNUT FM100H FM100 | WD169 | $4.99Add to cart Special order: ships in 2 to 4 weeks |
| 93 |  | KNOB-ADJUSTMENT FM100 FM200 FM100H FM200H | FM7 | $7.99Add to cart Special order: ships in 2 to 4 weeks |
| 94 |  | ADJUSTING WHEEL FM100H FM100 | WD171 | $13.99Add to cart Special order: ships in 2 to 4 weeks |
| 95 |  | BUTTON SCREW M8 X 20L FM100 FM200 FM100H FM200H | WD172 | $3.99Add to cart Special order: ships in 2 to 4 weeks |
| 96 |  | WHEEL SQUEEGEE FM100 FM200 FM100H FM200H | FM2 | $4.99Add to cart Special order: ships in 2 to 4 weeks |
| 97 |  | Squeegee,Wet/Dry,body | WD174 | $59.99Add to cart Special order: ships in 2 to 4 weeks |
| 98 |  | Squeegee Wet/Dry Metal Retainer Front Mount 2 Req | WD175 | $21.99Add to cart Special order: ships in 2 to 4 weeks |
| 99 |  | 27 in Squeegee Blade Replacement Trot Mop Pair | FM1 | $33.99Add to cart Special order: ships in 2 to 4 weeks |
| 100 | No Image | Squeegee,Wet/Dry,Front Mount,Mounting Plate | WD177 | $90.99Add to cart Special order: ships in 2 to 4 weeks |
| 101 | No Image | Bracket | WD179 | $0.00Read more |
| 102 | No Image | CONNECTOR FM100 FM200 FM100H FM200H | FM10 | $14.99Add to cart Special order: ships in 2 to 4 weeks |
| 103 |  | Squeegee,Wet/Dry,Hose | WD181 | $11.99Add to cart Special order: ships in 2 to 4 weeks |
| 104 |  | BEND CONNECTOR SQUEEGEE FM100 FM200 FM100H FM200H | FM24 | $14.99Add to cart Special order: ships in 2 to 4 weeks |
| 105 | No Image | CONNECTOR GASKET PF53 PF55 PF57 PF54 | WD23 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 106 |  | Squeegee,Wet/Dry,Front Mount,Adjuster Lever | WD184 | $41.99Add to cart Special order: ships in 2 to 4 weeks |
| 107 |  | ADJUSTER LEVER KNOB FM100H FM200H | WD186 | $12.99Add to cart Special order: ships in 2 to 4 weeks |
| 109 | No Image | CONNECTOR GASKET PF53 PF55 PF57 PF54 | WD23 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 110 | No Image | HOSE CONNECTOR PF53 PF54, PF55 PF57 | WD24 | $10.99Add to cart Special order: ships in 2 to 4 weeks |
| 111 |  | Hose Wet/Dry 10ft Inc WD28 Bend Connector | WD25 | $87.99Add to cart Special order: ships in 2 to 4 weeks |
| 112 | No Image | Connector PF53 PF55 PF57 PF54 | WD26 | $6.99Add to cart Special order: ships in 2 to 4 weeks |
| 113 | No Image | HOLDER, WAND PF53 PF55 PF57 PF54 | WD27 | $5.99Add to cart Special order: ships in 2 to 4 weeks |
| 114 | No Image | BEND CONNECTOR PF53 PF55 PF57 PF54 | WD28 | $19.99Add to cart Special order: ships in 2 to 4 weeks |
| 115 | No Image | Wand Wet Dry 21in SS 2 Required | WD29 | $46.99Add to cart Special order: ships in 2 to 4 weeks |
| 116 |  | FLOOR BRUSH ASSY PF53 PF54 PF55 PF57 | WD31 | $60.99Add to cart Special order: ships in 2 to 4 weeks |
| 117 |  | VAC TOOL CREVICE BLACK, PLASTIC PF53-57 | WD32 | $10.99Add to cart Special order: ships in 2 to 4 weeks |
| 118 |  | VAC TOOL DUST BRUSH 1-1/2 PLASTIC, BLACK PF53-57 | WD33 | $14.99Add to cart Special order: ships in 2 to 4 weeks |
| 119 |  | VAC TOOL SQUEEGEE 16 1-1/2 PLASTIC BLK PF50 SERIES | WD30A | $78.99Add to cart Special order: ships in 2 to 4 weeks |
| 121 | | Squeegee Wet/Dry Front Mount 26in 17gal Poly Assy | FM100H | $292.99Add to cart Special order: ships in 2 to 4 weeks |
