Schematic and parts book for Powr-Flite CPF6S . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| # | Part image | Description | SKU | Price |
| Not Shown | No Image | Charger Vacuum 36 Lithium 5A | X1194A | $395.99Add to cart Special order: ships in 2 to 4 weeks |
| XX |  | BAG PAPER BACKPACK 6QT CLOSE COLLAR 10PK | X9735 | $12.99Add to cart Special order: ships in 2 to 4 weeks |
| XX |  | Bag,Vacuum,Paper,6 Qt,10 Pack,10 CS,Open Collar | X9737 | $19.99Add to cart Special order: ships in 2 to 4 weeks |
| 1 |  | Powr-Flite Backpack Shoulder Harness | NH2021 | $120.99Add to cart Special order: ships in 2 to 4 weeks |
| 2 |  | ''Shldr Strp - Rvt (Nut) Female'' For: eureka,sanitaire | A3529401 | $4.98Read more |
| 3 | No Image | TOOL BELT CLIP W/ RETAINER CP STYLE BP | X1241 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 4 |  | SHOULDER RIVET MALE BPV PF300BP CFR30BP SCBP-1 | A3529402 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 5 | No Image | Washer 1/4 Flat USS Zinc | X8235 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 6 |  | Nut Neoprene Rubber Bottom Mount Backpack | X1466B | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 7 |  | RIVET, COMFORT PRO LATCHES | X9758 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 8 | Not Available | Washer | 01575 | Not Available |
| 9 |  | SCREW, 1/4-20 X 5/8 PHIL PAN BLACK ZINC | X9754 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 10 |  | CLIP NUT STANDAR NO-SLIP C 1/4-20 / BACKPACK | X9691 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 11 | No Image | Bag Microcloth 6qt Comfort Backpack with Gasket | X9679A | $14.99Add to cart Special order: ships in 2 to 4 weeks |
| 12 |  | Bag,Vacuum,HEPA,6 Qt,10 Pack,10 CS,Comfort Pro | X9739 | $34.99Add to cart Special order: ships in 2 to 4 weeks |
| 13 | No Image | Lid, 6Qt Backpack Comfort Pro | X9666 | $9.99Add to cart Special order: ships in 2 to 4 weeks |
| 14 |  | Filter,Vacuum,Inlet | X9683 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 15 | No Image | Filter, Inlet Base Backpack Comfort Pro | X9668 | $3.99Add to cart Special order: ships in 2 to 4 weeks |
| 16 | Not Available | Metal Latch | A352-3300 | Not Available |
| 17 | No Image | Housing 6qt Backpack Comfort Pro with Filter | X9664F | $41.99Add to cart Special order: ships in 2 to 4 weeks |
| 18 |  | Motor Mount, Rubber Backpack | X9681 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 19 |  | SCREW TRUSS HEAD 5/16-18 THREAD I LEN ZINC/ BPV | X9688 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 20 |  | SCREW CAP, MOTOR MOUNT COMFORT PRO | X9734 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 21 |  | SCREW CAP, BASE MOTOR MOUNT COMFORT PRO | X9733 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 22 | No Image | WELD NUT 5/16-18, PLAIN (MOTOR MOUNT) | X9713 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 23 | No Image | PLUG, 1.187 DIA ROUND HOLE HEYCO PN 2733 | X1395 | $1.99Read more |
| 24 | No Image | Gasket 3/8 Donut Tank Seal V1510 PVC | X9079 | $11.99Add to cart Special order: ships in 2 to 4 weeks |
| 25 | No Image | Motor Vacuum 36 VDC Ametek PF Motor | X1208 | $124.99Add to cart Special order: ships in 2 to 4 weeks |
| 26 | No Image | Gasket, Motor Plate, Backpack 3/8 Thick 55 Durometer | X1205 | $24.99Add to cart Special order: ships in 2 to 4 weeks |
| 27 |  | Plate, Motor Mounting Backpack Comfort Pro | X9671 | $6.99Add to cart Special order: ships in 2 to 4 weeks |
| 28 |  | Shroud, Motor Backpack Comfort Pro | X9669 | $9.99Add to cart Special order: ships in 2 to 4 weeks |
| 29 |  | SCREW, 8-18 HI-LO .5 LONG ZP | X9690 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 30 |  | Filter, Sound Damping Foam Ring Comfort Vac | X9717 | $7.99Add to cart Special order: ships in 2 to 4 weeks |
| 31 | No Image | Filter, Exhaust Plate Backpack Comfort Pro | X9667 | $3.99Add to cart Special order: ships in 2 to 4 weeks |
| 32 | No Image | Bumper for Comfort Pro Backpack | X9005 | $7.13Add to cart Special order: ships in 2 to 4 weeks |
| 33 |  | Filter,Vacuum,Exhaust,Backpack | X9682 | $5.99Add to cart Special order: ships in 2 to 4 weeks |
| 34 |  | Screw 8-18x.75 Hi-Lo Zinc Plated | X9676 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 35 | No Image | Wiring Kit, CPF6P | X1261 | $27.99Read more |
| 36 | Not Available | Screw #8-18 x 5/8" | A732-8314 | Not Available |
| 37 | No Image | Battery Vacuum 36 Lithium Moli Cell | X1200C | $969.99Add to cart Special order: ships in 2 to 4 weeks |
| 38 | No Image | Foot Rubber .75d .35h Adhesive Back 3M Sj5017 | X1260 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 39 | No Image | Plunger, Spring Loaded | X1207 | $19.99Add to cart Special order: ships in 2 to 4 weeks |
| 40 | No Image | Washer No.10 Flat SAE Blk | X9747 | $2.99Read more |
| 41 | No Image | SWITCH, ROCKER, 30A, 48VDC BATT BPV | X9028 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 42 | No Image | SCREW, 8-18 PLASTITE 3/8 ZP PHIL FLAT HEAD | X1263 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 43 |  | BOLT, 1/4-20 X 1-1/4 HEX BLACK | X8843 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 44 |  | Washer 5/16 Plain ID ZP | 02568 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 45 | No Image | FRAME, HARNESS, BATTERY BPV | X1382 | $22.99Add to cart Special order: ships in 2 to 4 weeks |
| 46 | No Image | Terminal Wall Assy Battery Backpack w/switch | X2527 | $88.99Read more |
| 47 |  | Screw HI-LO #8 x 7/16” Part Number A732-8414 for Simplicity and Maytag and Riccar Models 7250, 73... | A7328414 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| # | Part image | Description | SKU | Price |
| 1 | | BAG PAPER BACKPACK 6QT CLOSE COLLAR 10PK | X9735 | $12.99Add to cart Special order: ships in 2 to 4 weeks |
| 2 | | Bag,Vacuum,Paper,6 Qt,10 Pack,10 CS,Open Collar | X9737 | $19.99Add to cart Special order: ships in 2 to 4 weeks |
| 3 | | Bag,Vacuum,HEPA,6 Qt,10 Pack,10 CS,Comfort Pro | X9739 | $34.99Add to cart Special order: ships in 2 to 4 weeks |
| 4 | No Image | Battery Vacuum 36 Lithium Moli Cell | X1200C | $969.99Add to cart Special order: ships in 2 to 4 weeks |
