Schematic and parts book for Oreck U4200H2B . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Popular Supplies
| # | Part image | Description | SKU | Price |
| 1 | Not Available | Kit Bag Dock includes 1a & 1b | 09-75657-02 | Not Available |
| 1a | Not Available | Dock Rear Bag Type CC Black | 75583-03-480 | Not Available |
| 1b | Not Available | Bag Dock Type CC Black | 75582-03-480 | Not Available |
| 5 |  | Genuine Oreck Type CC Bags 8pk | O20008DW | $22.99Read more |
| 5 | Not Available | Dust Bag (25 Pk.) Hypo Allergenic | CCPK25DW | Not Available |
| 6 | Not Available | Outer Bag | 76096-01 | Not Available |
| 6 | Not Available | Outer Bag | 76096-02 | Not Available |
| 6 | Not Available | Outer Bag | 76096-03 | Not Available |
| 6 | Not Available | Outer Bag | 76133-09 | Not Available |
| 6 | Not Available | Outer Bag Graphite | 76133-06 | Not Available |
| 8 |  | Reconditioned Connector, Bag/Handle for classic XL style screw in type and modern commercial Oreck | 430001178R | $24.99Read more |
| 8 |  | Compatible alternateConnector, Bag/Handle W/Screws XL2000 Seri Part Number: 430001178 for Oreck More Product Details | 430001178 | $27.42Add to cart Special order: ships in 1 to 2 weeks |
| 9 | Not Available | Collar | 75199-02-0327 | Not Available |
| 10 | Not Available | Tube Assembly | 75198-05 | Not Available |
| 12 | Not Available | Fan Housing Assembly includes Rivet & Spring | 09-75343-03 | Not Available |
| 16 | Not Available | Endcard Metal Pulley Brush Rt | 75704-01 | Not Available |
| 18 |  | Fan (Plastic)-Oreck Upt 5300/888/8300/100/9100 For: oreck | 097530001 | $13.76Add to cart Special order: ships in 1 to 2 weeks |
| 19 | Not Available | Fan Cup Seal | 75012-01 | Not Available |
| 23 | Not Available | Bulb | 77051-01 | Not Available |
| 26 | Not Available | Top Cover/Belt Door Assy Peacoat Blue Antimicrobial | 09-76074-08 | Not Available |
| 26 | Not Available | Top Cover/Belt Door Black | 09-76074-03 | Not Available |
| 27 | Not Available | Bumper Clear | 75765-01 | Not Available |
| 28 | Not Available | Intake Pivot Assembly includes #29 | 09-75066-02 | Not Available |
| 29 |  | Cover Frame Tayberry Red Of 3 Parking | 7506501 | $100.00Read more |
| 32 |  | Gasket, Felt Motor Seal XL Platinum Pilot Ea Part Number: 75117-01M for Oreck | 7511701M | $2.06Read more |
| 34 | Not Available | Motor Assembly Kit | 09-75886-01 | Not Available |
| 35 | Not Available | Motor Seal | 75095-01 | Not Available |
| 36 | Not Available | Kit Motor Brush / Spring | 09-75514-01 | Not Available |
| 39 |  | Belt-Oreck - 3Pk - Upright - All Models For: oreck | 0300604 | $22.28Add to cart Special order: ships in 1 to 2 weeks |
| 39 |  | Compatible alternateOreck Upright Vacuum Flat Stretch Belt More Product Details | OR-1000 | $5.99Add to cart |
| 39 |  | Compatible alternateBelt, Oreck Upright Replacement DVC 2Pk More Product Details | OR-1010 | $10.99Add to cart |
| 39a | Not Available | Drive Belt Single | 75024-01 | Not Available |
| 39a | Not Available | Drive Belt | 75864-01 | Not Available |
| 40 | Not Available | Door Belt Peacoat Blue Antimicrobial U4180HHT/U4180HHC/U4190H2/U4300H2B: Door Belt Black7 6002-01-0327 1 1 | 76002-01-487 | Not Available |
| 42 |  | Reconditioned Oreck XL Wooden Brush Roller 9000 Series w/o Magnet - 75202-01 | OR2000R | $23.99Read more |
| 42 |  | Compatible alternateOreck XL Wooden Brush Roller 9000 Series w/o Magnet - 75202-01 More Product Details | OR2000 | $24.69Add to cart Special order: ships in 2 to 4 weeks |
| 42a | Not Available | Endcard Metal Pulley Side Lft | 75705-01 | Not Available |
| 42b | Not Available | Brush Roll Pulley Metal | 75706-01 | Not Available |
| 43 | Not Available | Seal Baseplate | 75008-01 | Not Available |
| 44 | Not Available | Plastic Detent (uses 2 #49 screws) | 75299-01 | Not Available |
| 45 | Not Available | Complete Baseplate Assembly includes: #43 #46 #47 #50 #51 #52 #84 #85 #86 Antimicrobial | 09-75715-56 | Not Available |
| 46 | Not Available | MICRO SWEEP Blade | 75700-02 | Not Available |
| 47 | Not Available | Channel | 75701-01 | Not Available |
| 50 | Not Available | Edge Brush | 75766-03 | Not Available |
| 51 | Not Available | Wheel Axle | 03-00630-01M | Not Available |
| 51 | Not Available | ORECK POWER TEAM 2.0 (Type 7 units) Hypo Bag Light LED and Bulb Models D2 Handle | SERIES | Not Available |
| 52 | Not Available | Soft Rear Wheel Black | 75187-02-0327 | Not Available |
| 54 | Not Available | Switch 2 Speed Hardwire | 75585-01 | Not Available |
| 55 | Not Available | Grips Peacoat Blue Set Antimicrobial | 09-75577-02 | Not Available |
| 55 |  | NO LONGER AVAILABLE Handle grips used on Orecks that have an integrated grommet/relief integrated... | 097557703 | $38.49Read more |
| 57 | Not Available | Handle Tube Chrome | 75190-03 | Not Available |
| 58 | Not Available | Cord Harness Assembly Black | 75552-02-327 | Not Available |
| 59 | Not Available | Cord Set Black w/ molded strain relief | 75896-03-327 | Not Available |
| 60 | Not Available | Motor Spring | 75283-01 | Not Available |
| 61 | Not Available | Tube Label | 75087-05 | Not Available |
| 67 |  | 3MM TO 6.5MM strain relief compair to heyco PG7 | 3TO65MMSTRAIN | $4.99Read more |
| 86 | Not Available | Front Wheel | 75709-01 | Not Available |
| 92 | Not Available | Fascia | 09-76126-59 | Not Available |
| 92 | Not Available | Fascia | 09-76126-63 | Not Available |
| 92 | Not Available | Fascia | 09-76126-64 | Not Available |
| 92 | Not Available | Fascia | 09-76126-15 | Not Available |
| 92 | Not Available | Fascia Graphite | 09-76126-17 | Not Available |
| 93 | Not Available | Light LED w/PCB | 75770-02 | Not Available |
| 94 | Not Available | Lower Bag Stiffener | 76061-01-0327 | Not Available |
