Schematic and parts book for Oreck u2160hh . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Popular Supplies
| # | Part image | Description | SKU | Price |
| 2 | Not Available | Cord Clamp | 03-00613-01M | Not Available |
| 2 | Not Available | WBD CLAMP CORD | 03-00619-01M | Not Available |
| 3 | Not Available | WBD SCREW 8-32 X | 03-00478-02M | Not Available |
| 5 | Not Available | DUST BAG / 8 PACK | CCPK8 | Not Available |
| 5 | Not Available | DUST BAG / 25 PACK | CCPK25 | Not Available |
| 6 | Not Available | OUTER BAG | 75645-21 | Not Available |
| 7 | Not Available | GREEN BAG CLIP | 09-75822-03 | Not Available |
| 8 | Not Available | CONNECTOR WITH | 09-75308-57 | Not Available |
| 9 | Not Available | SRA 75199-03-0327 | 75199-02-0327 | Not Available |
| 10 | Not Available | Tube Assembly | 75198-05 | Not Available |
| 12 | Not Available | ASSY FAN HOUSING | 09-75343-03 | Not Available |
| 15 | No Image | SCREW, :( HEADLIGHT LENS 100PK Part Number: 03752-01M for Oreck | 0375201M | $30.26Read more |
| 16 | Not Available | End Cap | 013-4623 | Not Available |
| 18 |  | Fan (Plastic)-Oreck Upt 5300/888/8300/100/9100 For: oreck | 097530001 | $13.76Add to cart Special order: ships in 2 to 4 weeks |
| 19 | Not Available | SEAL FAN | 75012-01 | Not Available |
| 26 | Not Available | Housing and Belt Door | 09-75780-54 | Not Available |
| 27 | Not Available | BUMPER CLEAR | 75765-01 | Not Available |
| 28 | Not Available | ASSEMBLY INTAKE | 09-75066-02 | Not Available |
| 29 |  | Cover Frame Tayberry Red Of 3 Parking | 7506501 | $100.00Add to cart Special order: ships in 2 to 4 weeks |
| 30 | Not Available | CHROME MC | 03-00448-01M | Not Available |
| 32 |  | Gasket, Felt Motor Seal XL Platinum Pilot Ea Part Number: 75117-01M for Oreck | 7511701M | $2.06Read more |
| 33 | Not Available | STRAIN RELIEF | 03-00494-01 | Not Available |
| 34 | Not Available | MOTOR KIT AL | 09-75886-01 | Not Available |
| 35 | Not Available | SEAL MOTOR | 75095-01 | Not Available |
| 36 | Not Available | KIT BRUSH/SPRING | 09-75514-01 | Not Available |
| 36 | Not Available | MOTOR | 3-N-1 | Not Available |
| 38 | No Image | SCREW, SMALL HEAD D HDLE 2800 100PK Part Number: 030045601M for Oreck | 030045601M | $18.25Read more |
| 38 | Not Available | Screw #8 x .75 | 03-00476-01M | Not Available |
| 39 |  | Belt-Oreck - 3Pk - Upright - All Models For: oreck | 0300604 | $22.28Add to cart Special order: ships in 2 to 4 weeks |
| 39 |  | Compatible alternateOreck Upright Vacuum Flat Stretch Belt More Product Details | OR-1000 | $5.99Add to cart |
| 39 |  | Compatible alternateBelt, Oreck Upright Replacement DVC 2Pk More Product Details | OR-1010 | $10.99Add to cart |
| 40 | Not Available | U2160HH: Door Belt | 75057-01-479 | Not Available |
| 41 | Not Available | WIRE NUT TAN 71B | 03-00599-01M | Not Available |
| 41 | No Image | Powerlifter Powerbrush | 1622 | $143.80Read more |
| 42 | Not Available | Brush Roll Assembly | 75104-02 | Not Available |
| 43 | Not Available | SEAL BASE | 75008-01 | Not Available |
| 44 | Not Available | SPRING DETENT | 75299-01 | Not Available |
| 45 | Not Available | ASSY BASEPLATE | 09-75715-01 | Not Available |
| 46 | Not Available | SQUEEGEE LOW | 75700-02 | Not Available |
| 47 | Not Available | CHANNEL W/SCREW | 75701-01 | Not Available |
| 48 | Not Available | Screw #8 x .75 Phillips | 03-00476-01M | Not Available |
| 48 | Not Available | TORX (Use T-20 bit | 03-00688-01M | Not Available |
| 49 | Not Available | SCREW #8 X .38 | 03-00475-01M | Not Available |
| 50 | Not Available | BRUSH HORSEHAIR | 75766-03 | Not Available |
| 51 | Not Available | AXLE BASEPLATE | 03-00630-01M | Not Available |
| 52 | Not Available | Soft Rear Wheel Black | 75187-02-0327 | Not Available |
| 54 | Not Available | SWITCH SINGLE | 75559-01 | Not Available |
| 55 | Not Available | U2160HH: Grip Set | 09-75576-42 | Not Available |
| 56 | Not Available | ASSY CORD WRAP | 09-75185-01 | Not Available |
| 57 |  | Handle, Upper Metal U2000/XL2100RHS Part Number: 430000905 for Oreck | 430000905 | $23.84Add to cart Special order: ships in 2 to 4 weeks |
| 57 |  | Available ReconditionedPre owned Oreck chrome/black handle for classic style orecks. Square silver or metal handle More Product Details | 7519007R | $14.99Add to cart |
| 58 | Not Available | CORD BLACK 30' | 75896-02-327 | Not Available |
| 59 | Not Available | Cord Set Black | 75896-03-327 | Not Available |
| 60 | Not Available | WBD SPRING | 75283-01 | Not Available |
| 61 | Not Available | Tube Label | 75087-05 | Not Available |
| 63 | Not Available | WBD SCREW CORD | 03-00450-01M | Not Available |
| 65 | Not Available | U2160HH: "Oreck" | 75599-08 | Not Available |
| 67 | Not Available | HINGE BLUE BAG | 75582-03-480 | Not Available |
| 68 | Not Available | SCREW MASTER | 03-00482-01M | Not Available |
| 69 | Not Available | COLLAR O-RING | 75191-02M | Not Available |
| 72 |  | Washer, :( Fan Thrush Part Number: 030047901M for Oreck | 030047901M | $0.30Read more |
| 73 | Not Available | WASHER LOCK EXT | 03-00480-01M | Not Available |
| 74 | Not Available | 1" x 3" Loop Fastener | 75304-01M | Not Available |
| 75 | Not Available | 1" x 1" Hook Fastener | 75303-01M | Not Available |
| 77 | Not Available | WBD RETAINER | 03528M | Not Available |
| 78 | Not Available | Wireform | 75194-03M | Not Available |
| 79 | Not Available | INSERT | 75619-01 | Not Available |
| 81 |  | Strain Relief, Cord U4080/U4090/XL2320 Part Number: 03-00600-01 for Oreck | 030060001 | $5.15Add to cart Special order: ships in 2 to 4 weeks |
| 82 | Not Available | BUSHING RING | 03-00598-01M | Not Available |
| 83 | Not Available | KIT BAG DOCK | 09-75657-01 | Not Available |
| 84 |  | Square Nut, Handle Brace 2000RH Part Number: 03-00606-01M for Oreck | 030060601M | $2.01Add to cart |
| 86 | Not Available | WIREFORM 1 PC | 75698-01 | Not Available |
| 87 | Not Available | FRONT WHEEL | 75709-01 | Not Available |
| 88 | Not Available | INSULATOR - JST | 75679-01M | Not Available |
| 89 | No Image | Rivet, 3/16 x 1.41 Master Pack XLPlatin Part Number: 03-00453-01M for Oreck | 030045301M | $39.33Read more |
