Schematic and parts book for Oreck PR3000, PR3000PI, S5327, 5327, PR3200 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | Handle Spring Black | 0-8011401 | Not Available |
| 2 | Not Available | Shutter Spring | 0-8010601 | Not Available |
| 3 | Not Available | Swing Arm Axle | 0-8011201 | Not Available |
| 4 | Not Available | Grip Handle Black | 0-80116010327 | Not Available |
| 4a | Not Available | Handle Set (4 Sections w/Grip) | 0-098014601 | Not Available |
| 5 | Not Available | Hook for Shutter Spring | 0-8012401 | Not Available |
| 6 | Not Available | Rivet for Shutter Spring | 0-030049001M | Not Available |
| 7 | Not Available | Dust Pan w/corner brushes | 0-098013401 | Not Available |
| 8 | Not Available | Corner Brush | 0-8011301 | Not Available |
| 9 | Not Available | Rotorblade | 0-30002 | Not Available |
| 10 | Not Available | Wheel | 0-8014801 | Not Available |
| 11 | Not Available | Axle Cap | 0-8012001 | Not Available |
| 12 | Not Available | Rotorblade Holder | 0-8010901 | Not Available |
| 13 | Not Available | Spring Bracket | 0-8012202 | Not Available |
| 14 | Not Available | Joint (Handle Connector Stud) | 0-8012501 | Not Available |
| 15 | Not Available | Screws #7 x 3/8' w/ #6 Head | 0-030047501M | Not Available |
| 16 | Not Available | Stabilizer Bar | 0-8010401 | Not Available |
| 17 | Not Available | Bumper | 0-80115010327 | Not Available |
| 18 | Not Available | Bumper Band Stopper | 0-8012301 | Not Available |
| 19 | Not Available | Screws #6 X 7/16" (100 Pack) Parts Diagram | 0-030049201M | Not Available |
