Schematic and parts book for Oreck APU255 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | HANDLE ASSEMBLY | 09-26585-04 | Not Available |
| 2 | Not Available | COLLAR LOCK | 26538-02-0327 | Not Available |
| 4 | Not Available | CORD ASSEMBLY | 26847-01 | Not Available |
| 5 | Not Available | FRONT WHEEL | AXLE | Not Available |
| 6 | Not Available | FRONT WHEEL | 25311-02-0327 | Not Available |
| 7 | Not Available | MAIN SWITCH | 00941-0037 | Not Available |
| 9 | Not Available | LEFT HOUSING ASSEMBLY | 09-26853-01 | Not Available |
| 10 | Not Available | HAND I HANDLE | 26541-01-0327 | Not Available |
| 11 | Not Available | BAG COVER ASSEMBLY | 09-26872-01 | Not Available |
| 12 | Not Available | OWNER'S MANUAL (APU255) | 26852-02 | Not Available |
| 12A | Not Available | OWNER'S MANUAL (BR225) | 26869-03 | Not Available |
| 13 | Not Available | LOWER DUCT SEAL | 26529-02 | Not Available |
| 14 | Not Available | POWER NOZZLE MOTOR (APU255) | 26842-01 | Not Available |
| 15 | Not Available | BELT{APU255) | 26610-01 | Not Available |
| 16 | Not Available | RETAINER BEARING (APU255) | 09-26615-01 | Not Available |
| 17 | Not Available | REAR WHEEL (APU255) | 26552-02-0327 | Not Available |
| 17 | No Image | NOZZLE, BASE W/WHEELS APU255 Part Number: 09-26630-03 for Oreck | 092663003 | $14.38Read more |
| 19A | Not Available | NOZZLE BASE ASSEMBLY (BR225) | 09-26874-01 | Not Available |
| 20 | Not Available | POWER NOZZLE CLAMP w/SEAL 00- | 26886-01 | Not Available |
| 22A | Not Available | NOZZLE COVER (BR225) | 26543-03-0327 | Not Available |
| 23A | Not Available | NOZZLE ASSEMBLY (BR225) | 09-26867-01 | Not Available |
| 24 | No Image | SWITCH, BROOM RG212/221 Part Number: 2662401 for Regina | 2662401 | $8.22Read more |
| 24 | Not Available | LIGHTED SWITCH (APU255) Type 2 Units Only | 26865-01 | Not Available |
| 25 | Not Available | POWER NOZZLE CORD (APU255) Type 1 Units Only | 09-26588-51 | Not Available |
| 25 | Not Available | POWER NOZZLE CORD (APU255) Type 2 Units Only | 09-26588-52 | Not Available |
| 26 | Not Available | REAR WHEEL AXLE (APU255) | 26553-01 | Not Available |
| 27 | Not Available | ELBOW RING | 26506-01-0327 | Not Available |
| 28 |  | BRUSHROLL, APU255 Part Number: 26540-02 for Oreck | 2654002 | $33.84Read more |
| 29 | Not Available | MOTOR CLAMP (APU255} | 26626-01 | Not Available |
| 31 | Not Available | HANDLE GRIP LOWER | 26563-01-0327 | Not Available |
| 32 | Not Available | HANDLE GRIP UPPER | 26562-01-0327 | Not Available |
| 33 | Not Available | HANDLE TUBE | 26560-53-0327 | Not Available |
| 34 | Not Available | HANDLE | TUBE | Not Available |
| 36 | Not Available | GLAMOUR CAP | 05453-0075 | Not Available |
| 37 | Not Available | LEAD W/TERMINAL (APU255) Type 1 Units Only | 26844-01 | Not Available |
| 37 | Not Available | LEAD W/TERMINAL (APU255) Type 2 Units Only | 26844-02 | Not Available |
| 38 | Not Available | LEAD (APU255) Type 1 Units Only | 26845-01 | Not Available |
| 40 | Not Available | BAG COVER | 25670-02-0327 | Not Available |
| 41 | Not Available | PLENUM | 26673-02-0327 | Not Available |
| 43 | Not Available | RIGHT HOUSING AND MOTOR ASSEMBLY | 09-26864-01 | Not Available |
| 43 | Not Available | RIGHT HOUSING AND MOTOR ASSEMBLY | 09-26868-01 | Not Available |
| 44 | Not Available | WHEEL SOLID | 24467-04-0327 | Not Available |
| 45 | No Image | MOTOR, BR225 Part Number: 26876-01 for Oreck | 2687601 | $88.74Read more |
| 46 | Not Available | MOTOR BULK HEAD | 26513-01 | Not Available |
| 47 | Not Available | MOTOR DISK | 26663-02 | Not Available |
| 48 | Not Available | CUP WASHER | 03-00422-01 | Not Available |
| 49 | Not Available | FAN | 25561-01 | Not Available |
| 50 | Not Available | MOTOR HOUSING MOUNT | 09-26884-01 | Not Available |
| 54 | Not Available | GASKET POWER NOZZLE (APU255) Parts Diagram | 78084-01 | Not Available |
| 2222 | Not Available | NNOOZZZZLLEE CCOOVVEERR (( | AAPPUU225555 | Not Available |
| 2233 | Not Available | PPOOWWEERR NNOOZZZZLLEE AASSSSEEMMBBLLYY (( | AAPPUU225555 | Not Available |
| 2233 | Not Available | POWER NOZZLE ASSEMBLY (APU255) Type 2 Units Only | 09-26785-03 | Not Available |
