Schematic and parts book for oreck airpcb . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 2 | Not Available | 1 | 21024-01 | Not Available |
| 3 | Not Available | 1 | 7848-2041 | Not Available |
| 4 | Not Available | 1 | 7848-4040 | Not Available |
| 5 | Not Available | Rear Diffuser 1 | 7849-2040 | Not Available |
| 6 | Not Available | FRONT DIFFUSER 1 | 7053-1040 | Not Available |
| 7 | Not Available | 1 | 7053-6041 | Not Available |
| 8 | Not Available | 1 | 7054-0041 | Not Available |
| 9 | Not Available | WBD MOTOR COVER 1 | 7849-9040 | Not Available |
| 10 | Not Available | 1 | 1201-0048 | Not Available |
| 11 | Not Available | Motor Fixing Plate 1 | 7053-7040 | Not Available |
| 12 | Not Available | Motor Rubber Pad Upper | 2900-8502 | Not Available |
| 13 | Not Available | 1 | 7849-8040 | Not Available |
| 14 | Not Available | 1 | 5510-3060 | Not Available |
| 17 | Not Available | Motor Rubber Pad Lower | 2900-8500 | Not Available |
| 18 | Not Available | 1 | 09-21058-01 | Not Available |
| 19 | Not Available | 1 | 4080-3002 | Not Available |
| 20 | Not Available | Collector Cell Pad | 2900-8503 | Not Available |
| 21 | Not Available | 1 | 5507-4315 | Not Available |
| 22 | Not Available | Interlock Switches Front Grill | 4168-0103 | Not Available |
| 23 | Not Available | Spacer Interlock Switch 1 | 2900-8507 | Not Available |
| 24 | Not Available | SWITCHES TOP 2 | 4168-0115 | Not Available |
| 25 | Not Available | Stays Cord & Switch 4 | 7053-8040 | Not Available |
| 26 | Not Available | 1 | 7848-1041 | Not Available |
| 27 | Not Available | 1 | 7848-3131 | Not Available |
| 29 | Not Available | PCB ASSEMBLY AIRP 1 | 5510-0227 | Not Available |
| 30 | Not Available | MOUNT CAPACITOR 1 | 6310-0330 | Not Available |
| 31 | Not Available | 1 | 5815-7640 | Not Available |
| 32 | Not Available | 4 | 7849-3040 | Not Available |
| 33 | Not Available | 1 | 7848-5040 | Not Available |
| 34 | Not Available | Ozone Filter 1 Not Shown | 4012-0054 | Not Available |
| 35 | Not Available | Badge Logo Domed 1 Not Shown | 2900-10801 | Not Available |
| 36 | Not Available | IRON MESH AIRP 1 Not Shown | 8564-4851 | Not Available |
| 37 | Not Available | 1 Not Shown | 4280-3603 | Not Available |
| 38 | Not Available | 4 Not Shown | 09-5510-0200M | Not Available |
| 39 | Not Available | 1 Not Shown | 2900-8509 | Not Available |
| 40 | Not Available | 1 Not Shown | 2900-2680 | Not Available |
| 41 | Not Available | Cord Clamp 1 Not Shown | 7741-7100 | Not Available |
| 42 | Not Available | Screw: Microswitch Stays 4 Not Shown | 0111-5080M | Not Available |
| 43 | Not Available | 2 Not Shown | 0111-5100M | Not Available |
| 44 | Not Available | 4 Not Shown | 0111-5121M | Not Available |
| 45 | Not Available | Screw: Cord Clamp 2 Not Shown | 0111-8100M | Not Available |
| 46 | Not Available | Screw: Power Supply 2 Not Shown | 0111-8140M | Not Available |
| 47 | Not Available | 3 Not Shown | 0111-8201M | Not Available |
| 48 | Not Available | 4 Not Shown | 0131-5088M | Not Available |
| 49 | Not Available | Screw: Back Diffuser 4 Not Shown | 0141-5121M | Not Available |
| 50 | Not Available | Screw: Front Diffuser 2 Not Shown | 0141-5123M | Not Available |
| 51 | Not Available | 2 Not Shown | 0181-5120M | Not Available |
| 52 | Not Available | Screw: Capacitor 2 Not Shown | 0211-5061M | Not Available |
| 53 | Not Available | 1 Not Shown | 0211-5101M | Not Available |
| 54 | Not Available | 3 Not Shown | 0211-5122M | Not Available |
| 55 | Not Available | Hex Nut: Capacitor 3 Not Shown | 0990-5005M | Not Available |
| 56 | Not Available | 1 Not Shown | 1204-1030M | Not Available |
| 60 | Not Available | ASSAIL A CELL 20 OZ 1 Not Shown | 32358 | Not Available |
| 61 | Not Available | 1 Not Shown | 21057-01 | Not Available |
| 62 | Not Available | Carton 1 Not Shown | 21064-01 | Not Available |
