Schematic and parts book for Kenmore 116.26212601 Powered head. Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Popular Supplies
| # | Part image | Description | SKU | Price |
| 3 |  | Window Cover For: kenmore | 4370711 | $17.58Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 4 | Not Available | WINDOW COVER (HEIGHT ADJ.) | 4369687 | Not Available |
| 5 | Not Available | BUTTON EXTENSION | 4370941 | Not Available |
| 7 | Not Available | FLOOR NOZZLE UPPER UNIT (INCLUDES ILLUS. 38 AND 9) | KC98RCUZZG09 | Not Available |
| 8 | No Image | FILTER, INTAKE/EXHAUST PN 116.55813503 Part Number: 4370713 for Kenmore | 4370713 | $4.21Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 8 |  | Compatible alternateSecondary Filter Foam
On Power Nozzle For: kenmore More Product Details | 591004161 | $4.22Add to cart Special order — allow 2-4 weeks. |
| 9 | Not Available | GUARD FURNITURE | 4370714 | Not Available |
| 10 | Not Available | COVER AGITATOR | 4370715 | Not Available |
| 15 | Not Available | SCREW | KS681550 | Not Available |
| 16 | Not Available | SWIVEL CAP THERMAL UNIT | KC62VAKTZV06 | Not Available |
| 18 |  | Swivel (65607) For: kenmore | KS4155049 | $26.92Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 19 | Not Available | PAD FOOT PEDAL | 4370577 | Not Available |
| 20 | Not Available | INDICATOR LEVER | 4370720 | Not Available |
| 21 | Not Available | CATCH INDEXING | KS722955 | Not Available |
| 22 |  | Kenmore Swivel Seal | KS742019 | $16.81Read more |
| 23 | Not Available | WASHER | KS725635 | Not Available |
| 24 | Not Available | CAM INDICATOR | KS747291 | Not Available |
| 25 | Not Available | INDICATOR BLOCK | 8195106 | Not Available |
| 26 | Not Available | SPRING ASSIST | KS725775 | Not Available |
| 27 |  | Brushroll, 116.51612001 W/Ball Brg Sq End Caps Part Number: 8192535 for Kenmore | 8192535 | $128.50Read more |
| 28 | Not Available | BULB SEARS NO. 20-5240 | FA-3515 | Not Available |
| 29 | Not Available | SOCKET BULB | 8175249 | Not Available |
| 31 | Not Available | WASHER THRUST | KS722909 | Not Available |
| 32 | Not Available | RATCHET CATCH | KS742016 | Not Available |
| 33 |  | Indicator Block Assembly For: kenmore | KC83MAKSZV06 | $20.30Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 41 | Not Available | PROTECTOR OVERLOAD | 8175256 | Not Available |
| 42 |  | Pedal, Handle Release 116.23612300 Part Number: KC47AGJ3V06 for Kenmore | KC47AGJ3V06 | $7.79Add to cart |
| 43 |  | Wheel, SINGLE WHEEL Rear Power Nozzle 116.22612203/3203 2Pk Part Number: 4370724 for Kenmore | 4370724 | $13.18Add to cart |
| 44 | Not Available | FLOOR NOZZLE LOWER | 4370725 | Not Available |
| 45 | Not Available | WIRE NUT | 4368552 | Not Available |
| 46 | Not Available | SPRING MOTOR ADJUSTMENT | KS742002 | Not Available |
| 47 |  | Lifter For: kenmore | 4370726 | $12.16Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 48 | Not Available | MOTOR BRIDGE | KS705093 | Not Available |
| 49 | No Image | CORD, POWER NNOZZLE LONG 116.54212400 Part Number: 8192034 for Kenmore | 8192034 | $85.69Read more |
| 50 | Not Available | MOTOR GASKET | KS747156 | Not Available |
| 51 | Not Available | SCREW | KS681297 | Not Available |
| 52 | Not Available | BELT SEARS NO. 20-5201/KENMORE STYLE NO. CB-2 | 1000 | Not Available |
| 53 | Not Available | MOTOR | 8192730 | Not Available |
| 54 |  | Front Axle Assy For: kenmore | KS744029 | $15.28Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 55 | Not Available | SCREW | KS681297 | Not Available |
