Schematic and parts book for Janome QMPRO-STITCHER QMPRO-STITCHER. Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | No Image | Pro-Stitcher, 8W | QF09537 | $1,165.82Read more |
| 2 |  | PS FLEXIRACK CLAMP sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM10010 | $7.47Add to cart Special order: ships in 2 to 4 weeks |
| 3 |  | Ps Flexirack Clamp Kit | QM10020 | $26.05Add to cart Special order: ships in 2 to 4 weeks |
| 4 |  | Ps Base Plate Repair Kit | QM10050 | $19.86Read more |
| 5 | Not Available | PS FLEXIRACK 1.0, 20 DEG | QM10065 | Not Available |
| 6 |  | SCREW-M5X8 SKC ZN sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM10180 | $7.47Add to cart Special order: ships in 2 to 4 weeks |
| 7 | Not Available | PROSTITCHER MODULE FROM MSI | QM20802-4 | Not Available |
| 8 |  | BRACKET Y AXIS PS 16/18/20 sewing machine part or accessory For Janome Models: QMPSTITCHER-20, Pr... | QM20862 | $303.60Add to cart Special order: ships in 2 to 4 weeks |
| 9 |  | SCREW-6-32X1/4 PHP ZN sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM10749 | $4.55Add to cart Special order: ships in 2 to 4 weeks |
| 10 | No Image | Ps Foam Set | QM11850 | $303.60Read more |
| 11 | No Image | Box-Prostitcher | QM33030 | $99.28Read more |
| 12 | No Image | Holder-Cable Press-In | QM11882 | $12.39Add to cart Special order: ships in 2 to 4 weeks |
| 13 |  | Art & Stitch Program | QM20807 | $1,740.20Add to cart Special order: ships in 2 to 4 weeks |
| 14 | Not Available | CABLE PS PWR 19V TO PC | QM20812-5 | Not Available |
| 15 |  | Cable Ps Serial-Motor | QM20851 | $79.42Add to cart Special order: ships in 2 to 4 weeks |
| 16 |  | USB Flash drive (Janome) sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM21869 | $119.13Add to cart Special order: ships in 2 to 4 weeks |
| 17 |  | Cable-Ps Pc Serial-Hq 24 | QM24850 | $55.83Add to cart Special order: ships in 2 to 4 weeks |
| 18 | No Image | Quick Reference Guide | QM30030 | $19.99Add to cart Special order: ships in 2 to 4 weeks |
| 19 | No Image | Getting Started Guide | QM30031 | $38.20Add to cart Special order: ships in 2 to 4 weeks |
| 20 |  | Manual engagement/disengagement tool (T 5mm hex) sewing machine part or accessory For Janome Mode... | QM40240 | $71.50Add to cart Special order: ships in 2 to 4 weeks |
| 21 |  | Ferrite-Clamp-On-Power Cord | QM20281 | $9.93Add to cart Special order: ships in 2 to 4 weeks |
| 22 | No Image | Ferrite-28A2026-0A2 | QM20284 | $10.47Add to cart Special order: ships in 2 to 4 weeks |
| 23 |  | Line Filter Ps | QM20831 | $253.60Add to cart Special order: ships in 2 to 4 weeks |
| 24 |  | Power Cord Ps 10' | QM20833 | $37.40Add to cart Special order: ships in 2 to 4 weeks |
| 25 |  | Power Cord N.A. 2' | QM20298 | $18.80Add to cart Special order: ships in 2 to 4 weeks |
| 26 | No Image | Cable Ps Usb Right Angle | QM208115 | $10.40Add to cart Special order: ships in 2 to 4 weeks |
| 27 | Not Available | TUBING CORRUGATED PS | QM10066 | Not Available |
| 28 | | ASSY-PRO STITCHER DISPLAY sewing machine part or accessory For Janome Models: QMPRO-STITCHER | QM20802-4-131 | $5,491.20Read more |
| # | Part image | Description | SKU | Price |
| 1 | | PS FLEXIRACK CLAMP sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM10010 | $7.47Add to cart Special order: ships in 2 to 4 weeks |
| 2 | | SCREW #6 X 1/2 PHP ZN sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM10015 | $4.55Add to cart Special order: ships in 2 to 4 weeks |
| 3 |  | 3/32-inch drill bit sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM10113 | $12.39Add to cart Special order: ships in 2 to 4 weeks |
| 4 |  | Screw #8 X 18 X 5/8 Slh Sd Zn | QM10067 | $3.73Add to cart Special order: ships in 2 to 4 weeks |
| # | Part image | Description | SKU | Price |
| 1 | No Image | Carriage, Painted, 18E 8W | QF10537 | $412.90Add to cart Special order: ships in 2 to 4 weeks |
| 2 |  | SCREW, HEX 1/4-20 X 3/4 ZINC sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QF10514 | $1.00Add to cart Special order: ships in 2 to 4 weeks |
| 3 |  | TAPE- DOUBLE-SIDED 1 FOOT* sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QF10607 | $5.01Add to cart Special order: ships in 2 to 4 weeks |
| 4 | No Image | Carriage Track, Aluminum | QF10708 | $67.03Add to cart Special order: ships in 2 to 4 weeks |
| 5 |  | END CAP-CARRIAGE sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QF10705 | $3.01Add to cart Special order: ships in 2 to 4 weeks |
| 6 | Not Available | SCREW-1/4-20 X5/6 SBH ZN | QF10701 | Not Available |
| 7 |  | Assy-Carriage Encoder | QM29773 | $364.32Add to cart Special order: ships in 2 to 4 weeks |
| 8 |  | WHEEL, CARRIAGE sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM10234 | $44.72Add to cart Special order: ships in 2 to 4 weeks |
| 9 |  | WASHER-1/4” X .063 sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM12438 | $1.00Add to cart Special order: ships in 2 to 4 weeks |
| 10 |  | PIN, SLOTTED SPRING sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM12435 | $1.00Add to cart Special order: ships in 2 to 4 weeks |
| 11 | No Image | Screw 1/4 X 3/8 Shoulder Skt | QM10767 | $5.01Add to cart Special order: ships in 2 to 4 weeks |
| 12 |  | Spring, Torsion, Sr | QM10817 | $14.94Add to cart Special order: ships in 2 to 4 weeks |
| 13 |  | WASHER, SR ZINC sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM10778 | $4.01Add to cart Special order: ships in 2 to 4 weeks |
| # | Part image | Description | SKU | Price |
| 1 |  | Encoder Crg Assy Mechanical | QM29773M | $364.32Add to cart Special order: ships in 2 to 4 weeks |
| 2 |  | ENCODER HKT3006-READER sewing machine part or accessory For Janome Models: QMPRO16 | QM22417-1 | $69.52Add to cart Special order: ships in 2 to 4 weeks |
| 3 |  | ENCODER HKT3006-DISK sewing machine part or accessory For Janome Models: QMPRO16 | QM22417-2 | $69.52Add to cart Special order: ships in 2 to 4 weeks |
| 4 |  | Encoder Hkt3006-Case | QM224173 | $13.60Add to cart Special order: ships in 2 to 4 weeks |
| 5 |  | Board, Terminator X | QM22418 | $79.42Add to cart Special order: ships in 2 to 4 weeks |
| 6 |  | Cover-Encoder Assy Crg | QM12333 | $14.94Add to cart Special order: ships in 2 to 4 weeks |
| 7 |  | SCREW-4-40 X 5/16 PHP ZN sewing machine part or accessory For Janome Models: QMPRO16 | QM10769 | $1.00Add to cart Special order: ships in 2 to 4 weeks |
| 8 |  | O-Ring SR sewing machine part or accessory Work with QMPRO18 encoders | QM10805 | $12.30Add to cart Special order: ships in 2 to 4 weeks |
| # | Part image | Description | SKU | Price |
| 1 |  | CLIP-RETAINING FOR POWER CORD sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM10481 | $19.86Add to cart Special order: ships in 2 to 4 weeks |
| 2 |  | SCREW-4-48 RETAINING CLAMP sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM10483 | $16.39Add to cart Special order: ships in 2 to 4 weeks |
| 3 | No Image | Pro-Stitcher Plate | QM208024100 | $131.80Add to cart Special order: ships in 2 to 4 weeks |
| 4 |  | POWER SUPPLY COVER sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM20802-4-101 | $133.58Add to cart Special order: ships in 2 to 4 weeks |
| 5 |  | Standoff-Ps | QM208024102 | $8.60Add to cart Special order: ships in 2 to 4 weeks |
| 6 |  | Cable-Ps Motor Power Serial | QM24853 | $210.60Add to cart Special order: ships in 2 to 4 weeks |
| 7 | No Image | Cable-Ps Stepper Motor | QM24854 | $50.28Add to cart Special order: ships in 2 to 4 weeks |
| 8 |  | CABLE-PS AC GROUND sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM24855 | $9.93Add to cart Special order: ships in 2 to 4 weeks |
| 9 |  | CABLE-PS AC sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM24856 | $40.99Add to cart Special order: ships in 2 to 4 weeks |
| 10 |  | ASSY-STEPPER MOTOR PS sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM10094 | $89.80Read more |
| 11 | No Image | Assy-Servo Motor Ps | QM2080241 | $4,614.72Read more |
| 12 |  | FILTER-LINE FN9222E-03-06 PS C sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM20802-4-132 | $84.43Add to cart Special order: ships in 2 to 4 weeks |
| 13 |  | WASHER-M3 FLAT sewing machine part or accessory For Janome Models: PROSTITCHER-LITE | QM00500-36 | $4.55Add to cart Special order: ships in 2 to 4 weeks |
| 14 |  | POWER SUPPLY PRO-STITCHER II sewing machine part or accessory QM20809-2 POWER SUPPLY PRO-STITCHER... | QM20809-2 | $455.40Add to cart Special order: ships in 2 to 4 weeks |
| 15 |  | Screw-M3 X 8 Pph Zn | QM13235 | $0.40Add to cart Special order: ships in 2 to 4 weeks |
| 16 |  | SCREW-M5 X 70 SKC SS sewing machine part or accessory For Elna Models: EL920 | QM20802-4-126 | $5.56Add to cart Special order: ships in 2 to 4 weeks |
| 17 |  | BOARD-PS STEPPER DRIVER sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM21845 | $182.16Add to cart Special order: ships in 2 to 4 weeks |
| 18 |  | NUT, M5 sewing machine part or accessory For Janome Models: QMPROVERSA | QM10529 | $4.55Add to cart Special order: ships in 2 to 4 weeks |
| 19 | | SCREW, 4-40 X 3/16 PHP ZN sewing machine part or accessory For Janome Models: QMPRO20 | QM10350 | $4.55Add to cart Special order: ships in 2 to 4 weeks |
| 20 |  | STANDOFF-4-40 X 3/16 M/F sewing machine part or accessory For Janome Models: PROSTITCHER-LITE | QM20802-4-130 | $1.20Add to cart Special order: ships in 2 to 4 weeks |
| 21 |  | Screw-M4x6 SHCS ZN sewing machine part or accessory For Janome Models: QT09015 | QM20802-4-129 | $1.00Add to cart Special order: ships in 2 to 4 weeks |
| 22 | No Image | Washer-M4 Flat Znc | QM10129 | $0.40Read more |
| # | Part image | Description | SKU | Price |
| 1 |  | MOTOR MOUNT sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM20802-4-109 | $7.00Add to cart Special order: ships in 2 to 4 weeks |
| 2 |  | X-AXIS MOUNTING PLATE sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM20802-4-104 | $7.01Add to cart Special order: ships in 2 to 4 weeks |
| 3 |  | BEARING-5/8 X 1/4 X 196 FLANGED sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM20802-4-117 | $64.58Add to cart Special order: ships in 2 to 4 weeks |
| 4 | Not Available | ASSY-GEAR BOX PS | ENG-10002 | Not Available |
| 5 |  | PULLEY-20T GT X 2MM* sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM20802-4-125 | $44.72Add to cart Special order: ships in 2 to 4 weeks |
| 6 |  | SCREW-M5 X 12 SKC ZN sewing machine part or accessory For Janome Models: QMPROVERSA | QM10892 | $1.00Add to cart Special order: ships in 2 to 4 weeks |
| 7 |  | Spring Mount | QM208024105 | $9.93Add to cart Special order: ships in 2 to 4 weeks |
| 8 |  | SPRING-1.25IN sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM20802-4-127 | $22.31Add to cart Special order: ships in 2 to 4 weeks |
| 9 |  | SCREW, M5 X 55 SKC ZN sewing machine part or accessory For Janome Models: QMPRO20 | QM20802-4-128 | $2.46Add to cart Special order: ships in 2 to 4 weeks |
| 10 | Not Available | MOTOR-SM23165D-HQU1, ANIMATICS | ENG-10011 | Not Available |
| 11 | | NUT, M5 sewing machine part or accessory For Janome Models: QMPROVERSA | QM10529 | $4.55Add to cart Special order: ships in 2 to 4 weeks |
| 12 |  | WASHER, M4 ZN sewing machine part or accessory For Janome Models: QMPROVERSA | QM10229 | $1.00Add to cart Special order: ships in 2 to 4 weeks |
| 13 |  | SCREW- M4 X 30 SKC SS sewing machine part or accessory For Janome Models: QMPROVERSA | QM10882 | $1.46Add to cart Special order: ships in 2 to 4 weeks |
| 14 |  | PULLEY-GT TIMING 2MM PIT* sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM20802-4-114 | $44.72Add to cart Special order: ships in 2 to 4 weeks |
| 15 |  | PULLEY 60T-20T GT 2MM sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM20802-4-115 | $99.28Add to cart Special order: ships in 2 to 4 weeks |
| 16 |  | BELT-TIMING 93 GROOVE X 6MM sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM20802-4-116 | $29.78Read more |
| 17 |  | BELT-TIMING 67 GROOVE X 6MM sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM20885 | $44.72Add to cart Special order: ships in 2 to 4 weeks |
| 18 | | BEARING-5/8 X 1/4 X 196 FLANGED sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM20802-4-117 | $64.58Add to cart Special order: ships in 2 to 4 weeks |
| 19 |  | SPRING-.265X490X.011 WAVE sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM20802-4-119 | $19.86Add to cart Special order: ships in 2 to 4 weeks |
| 20 |  | E-CLIP-1/4 DIA PS sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM20802-4-120 | $0.60Read more |
| 21 |  | Shaft-.249X1.5625 Ps | QM208024121 | $52.83Add to cart Special order: ships in 2 to 4 weeks |
| 22 |  | Nut-M4 Jam | QM208024123 | $1.00Add to cart Special order: ships in 2 to 4 weeks |
| 23 |  | Screw-M4X30 Skc Ss Low | QM208024124 | $0.80Add to cart Special order: ships in 2 to 4 weeks |
| 24 | No Image | Gear Box Motor Mount | QM208024147 | $6.00Read more |
| 25 | No Image | Gear Box Plate | QM208024148 | $6.00Read more |
| 26 | Not Available | ASSY-DRIVE GEAR PS | ENG-10003 | Not Available |
| # | Part image | Description | SKU | Price |
| 1 |  | STEPPER MOTOR MOUNT sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM20802-4-103 | $64.55Add to cart Special order: ships in 2 to 4 weeks |
| 2 |  | DISENGAGE CAM sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM20802-4-106 | $5.01Add to cart Special order: ships in 2 to 4 weeks |
| 3 |  | SCREW-4-40 X 1/8 SKS CUP ZN* sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM13232 | $1.00Add to cart Special order: ships in 2 to 4 weeks |
| 4 |  | PIN-ROLL 1.5MM X 12MM SS sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM20802-4-112 | $2.73Add to cart Special order: ships in 2 to 4 weeks |
| 5 | | WASHER-M3 FLAT sewing machine part or accessory For Janome Models: PROSTITCHER-LITE | QM00500-36 | $4.55Add to cart Special order: ships in 2 to 4 weeks |
| 6 | | Screw-M3 X 8 Pph Zn | QM13235 | $0.40Add to cart Special order: ships in 2 to 4 weeks |
| 7 |  | MOTOR-STEPPER sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM20802-4-110 | $57.60Read more |
| 8 |  | ENCODER-UP/DOWN INDICATOR PS sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM20802-4-113 | $65.12Add to cart Special order: ships in 2 to 4 weeks |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | PS TOUCHSCREEN TABLET | QM20887-7 | Not Available |
| 2 |  | PS TABLET MTG BRACKET TOP sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM11086-1 | $19.86Add to cart Special order: ships in 2 to 4 weeks |
| 3 |  | Ps Computer Brkt Slide Rod | QM110864 | $8.00Add to cart Special order: ships in 2 to 4 weeks |
| 4 |  | Slide Rod Spring | QM110866 | $1.40Add to cart Special order: ships in 2 to 4 weeks |
| 5 | No Image | Ps Tablet Mtg Bracket Bottom | QM11086 | $27.32Add to cart Special order: ships in 2 to 4 weeks |
| 6 |  | E-CLIP sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM11086-5 | $1.00Add to cart Special order: ships in 2 to 4 weeks |
| 7 |  | SCREW-M4X30 PHF ZN sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM11086-7 | $1.00Add to cart Special order: ships in 2 to 4 weeks |
| 8 |  | M4 LOCK NUT ZN sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM11086-8 | $1.00Add to cart Special order: ships in 2 to 4 weeks |
| 9 | No Image | Ps Spacer For Tablet .458 | QM1108631 | $0.00Read more |
| 10 |  | ALT SPACER FOR TABLET 25 sewing machine part or accessory | QM11086-3 | $1.00Add to cart Special order: ships in 2 to 4 weeks |
| 11 | Not Available | BOARD PS PWR USB CONVTR | QM20840-7 | Not Available |
| 12 |  | SCREW-6-32X1/4 PHF U-CUT ZN sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM10746 | $1.00Add to cart Special order: ships in 2 to 4 weeks |
| 13 |  | WASHER M5 sewing machine part or accessory For Janome Models: QM00512 | QM10250 | $1.00Add to cart Special order: ships in 2 to 4 weeks |
| 14 |  | BRACKET-POWER DIST GEN3 sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM10823 | $74.44Add to cart Special order: ships in 2 to 4 weeks |
| 15 |  | SCREW-4-40 X 1/2 PHP ZN sewing machine part or accessory For Janome Models: QMPROVERSA | QM10742 | $1.00Add to cart Special order: ships in 2 to 4 weeks |
| 16 |  | PS MONITOR HINGE sewing machine part or accessory For Janome Models: QMPSTITCHER-20 | QM10810 | $333.96Add to cart Special order: ships in 2 to 4 weeks |
| 17 |  | USB cable (top of black box to tablet) sewing machine part or accessory For Janome Models: QMPSTI... | QM20811-9 | $79.42Add to cart Special order: ships in 2 to 4 weeks |
| 18 | Not Available | CABLE PS PWR 19V TO PC | QM20812-5 | Not Available |
| 19 | No Image | Screw-M4X16 Skc Bl | QM10949 | $1.00Add to cart Special order: ships in 2 to 4 weeks |
| 20 | No Image | Washer-M4 Flat Znc | QM10129 | $0.40Read more |
| 21 |  | Ps Power Dist Box Front | QM10813 | $102.62Add to cart Special order: ships in 2 to 4 weeks |
| 22 |  | Bracket, Quilt Maker Ps | QM10821 | $69.49Add to cart Special order: ships in 2 to 4 weeks |
