Schematic and parts book for Janome 5' Frame 5' Frame. Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides replacement parts and accessories for vacuum cleaners, sewing machines, and other small appliances for repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | No Image | Table Section With Plastic Top | QF05300300 | $630.40Add to cart Special order: ships in 2 to 4 weeks |
| 2 | No Image | Front Pole (56") | QF10005 | $90.90Read more |
| 3 | No Image | Rear Pole (68") | QF10009 | $97.09Read more |
| 4 | No Image | Rear Pole End-Caps | QF10011 | $7.47Add to cart Special order: ships in 2 to 4 weeks |
| 5 | No Image | Upper Leg A - F R And B L | QF05300402 | $120.20Read more |
| 6 | No Image | Upper Leg B - F L And B R | QF05300403 | $120.20Read more |
| 7 | No Image | Lower Legs | QF05300401 | $214.60Read more |
| 8 |  | LEVELING GLIDE sewing machine part or accessory QF09318-108 LEVELING GLIDE | QF09318-108 | $3.60Add to cart Special order: ships in 2 to 4 weeks |
| 9 |  | Genuine Janome/Elna WASHER-M8 NYLON For: QF01502-JA | QF05300-157 | $0.80Read more |
| 10 |  | M6 X 10Mm Socket Cap Screws | QF10006 | $12.84Add to cart Special order: ships in 2 to 4 weeks |
| 11 | No Image | M8 X 20Mm Sock Butt Screws | QM10959 | $6.38Add to cart Special order: ships in 2 to 4 weeks |
| 12 | No Image | Left Side Arm | QF10008JA | $194.30Read more |
| 13 | No Image | Right Side Arm | QF10007JA | $164.20Read more |
| # | Part image | Description | SKU | Price |
| 1 | No Image | Front Pole Corner Connectors | QF10003 | $49.64Add to cart Special order: ships in 2 to 4 weeks |
| 2 | No Image | Brackets | QF10010 | $74.50Add to cart Special order: ships in 2 to 4 weeks |
| 3 | No Image | Side Arm Pole | QF10004 | $45.20Add to cart Special order: ships in 2 to 4 weeks |
| 4 | No Image | Clamp Assembly | QF10041 | $17.20Add to cart Special order: ships in 2 to 4 weeks |
| 5 | No Image | Right Side Arm Pole Clamp | QF10042 | $73.00Add to cart Special order: ships in 2 to 4 weeks |
| 6 | | SCREW-M3X8 PHP ZN sewing machine part or accessory For Janome Models: QMPROVERSA | QM10945 | $1.00Add to cart Special order: ships in 2 to 4 weeks |
| 7 | No Image | Clamp Assembly | QF10041 | $17.20Add to cart Special order: ships in 2 to 4 weeks |
| 8 | No Image | Left Side Arm Pole Clamp | QF10043 | $73.00Add to cart Special order: ships in 2 to 4 weeks |
| 9 | | SCREW-M3X8 PHP ZN sewing machine part or accessory For Janome Models: QMPROVERSA | QM10945 | $1.00Add to cart Special order: ships in 2 to 4 weeks |
| 10 |  | Open End Wrench 17/13Mm | QF09318114 | $22.31Add to cart Special order: ships in 2 to 4 weeks |
| 11 |  | Genuine Janome/Elna ALLEN WRENCH 5mm QF09318-113 ALLEN WRENCH 5mm | QF09318-113 | $24.86Add to cart Special order: ships in 2 to 4 weeks |
| 12 |  | Hex Key Handle 4Mm | QF09318112 | $19.86Add to cart Special order: ships in 2 to 4 weeks |
| 13 | No Image | Easy Grasp Quilt Clamps 5' | QF10013 | $49.64Read more |
| # | Part image | Description | SKU | Price |
| 1 | No Image | Deluxe Quilt Clamp | QF10018 | $74.50Add to cart Special order: ships in 2 to 4 weeks |
| 2 | No Image | 2-Inch Small Quilt Clamps | HG10000 | $14.94Add to cart Special order: ships in 2 to 4 weeks |
| 3 | No Image | 3-Inch Large Quilt Clamps | QF10014 | $23.68Add to cart Special order: ships in 2 to 4 weeks |
| 4 | No Image | Track Support 5’ | QF0530002 | $133.58Add to cart Special order: ships in 2 to 4 weeks |
| 5 |  | Screw-M6 X 12 W/17Mm Swh | QF09318303 | $1.09Add to cart Special order: ships in 2 to 4 weeks |
| 6 | No Image | 10’ Track Insert | QF0530004 | $148.89Add to cart Special order: ships in 2 to 4 weeks |
