Schematic and parts book for hoover U8361-900 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Popular Supplies
| # | Part image | Description | SKU | Price |
| 1 | No Image | HANDLE UPPER/WAND ASSEMB. Part Number: 48642099 for Hoover | 48642099 | $0.94Read more |
| 2 | Not Available | CREVICE TOOL - 7" BLACK | 38617033 | Not Available |
| 3 |  | Dust Brush, :( Black WindTunnel Upright Part Number: 43414197 for Hoover | 43414197 | $12.88Read more |
| 4 | Not Available | FURNITURE NOZZLE - BLACK | 38614045 | Not Available |
| 5 | Not Available | HOSE ASSEMBLY - BLACK | 43431232 | Not Available |
| 5 | Not Available | HOSE ASSEMBLY - BONUS HOSE | 43434275 | Not Available |
| 6 | Not Available | HOSE CLIP | 36172038 | Not Available |
| 7 | Not Available | CORD WRAP | 3944203E | Not Available |
| 8 | Not Available | POWER CORD - 35' | 46383334 | Not Available |
| 9 | Not Available | CORD PROTECTOR | 36215028 | Not Available |
| 10 | No Image | WAND, RETAINER U8311 WT2 Part Number: 92001290 for Hoover | 92001290 | $1.96Read more |
| 11 | Not Available | SCREW - SELF TAPPING | 21447242 | Not Available |
| 12 | Not Available | RELEASE LATCH / WAND RETAINER - SILVER SAND | 91001121 | Not Available |
| 13 | Not Available | WAND RELEASE LATCH - SANDSTONE GRAY | 38567060 | Not Available |
| 14 | Not Available | UPPER HANDLE COVER | 39467083 | Not Available |
| 15 | Not Available | SCREW - SELF TAPPING | 21447242 | Not Available |
| 16 | Not Available | UPPER HOUSING / BACK PANEL | 92001291 | Not Available |
| 17 | Not Available | LOWER HOSE | 91001177 | Not Available |
| 18 | Not Available | TURBINE TOOL | 49129044 | Not Available |
| 20 | Not Available | INSULATOR | 91001123 | Not Available |
| 21 |  | Circuit Power Board Assembly - U8361 Windtunnel 2 For: hoover | 46851068 | $71.70Add to cart Special order: ships in 2 to 4 weeks |
| 22 | Not Available | SCREW - SELF TAPPING | 21447242 | Not Available |
| 23 | Not Available | DIRT LENS | 91001150 | Not Available |
| 24 | Not Available | SCREW - SELF TAPPING | 21447228 | Not Available |
| 25 | Not Available | FINAL / EXHAUST FILTER | 38769032 | Not Available |
| 26 | Not Available | SCREW - SELF TAPPING | 21447242 | Not Available |
| 27 | No Image | COVER, MOTOR Part Number: 91001125 for Hoover | 91001125 | $10.54Read more |
| 28 | Not Available | LEAD WIRE TIE | 91001178 | Not Available |
| 29 | Not Available | FOAM MOTOR MUFFLER | 91001152 | Not Available |
| 30 | Not Available | BULB | 27313107 | Not Available |
| 31 | Not Available | MOTOR MOUNT - SMALL | 36322030 | Not Available |
| 32 | Not Available | MOTOR ASSEMBLY | 27212067 | Not Available |
| 33 | Not Available | MOTOR SEAL - BLACK | 91001148 | Not Available |
| 34 | Not Available | DIRT DUCT COVER | 38648007 | Not Available |
| 35 | Not Available | SCREW - SELF TAPPING | 21447242 | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | MEDALLION | 51661020 | Not Available |
| 2 | Not Available | NON-EDF COVER | 37246030 | Not Available |
| 3 | Not Available | HOOD / NOZZLE COVER NAME PLATE | 91001187 | Not Available |
| 4 | Not Available | HOOD / NOZZLE COVER - SPLIT | 92001292 | Not Available |
| 5 | Not Available | SCREW - SELF TAPPING | 21447242 | Not Available |
| 6 | Not Available | AGITATOR / BRUSH ROLL HOUSING | 37243060 | Not Available |
| 7 | Not Available | TRUNNION COVER - RIGHT SILVER SAND MEDIUM | 36131139 | Not Available |
| 8 | Not Available | TRUNNION COVER - LEFT SILVER SAND MEDIUM | 36131140 | Not Available |
| 9 | Not Available | NOZZLE LINER - NEURON ORANGE | 92001294 | Not Available |
| 10 | Not Available | HEIGHT ADJUSTMENT TRANSMISSION | 91001188 | Not Available |
| 11 | Not Available | TORSION SPRING | 38356014 | Not Available |
| 12 |  | Actuator Arm Trunnion For: hoover | 36171058 | $0.54Add to cart Special order: ships in 2 to 4 weeks |
| 13 | Not Available | IDLER PULLEY ARM | 38458083 | Not Available |
| 14 | Not Available | BEARING | 91001105 | Not Available |
| 15 | No Image | SCREW, TAPPING Part Number: 21479450 for Hoover | 21479450 | $0.03Read more |
| 16 | Not Available | HANDLE RELEASE LEVER | 38434026 | Not Available |
| 17 | Not Available | PCB HALL ASSEMBLY | 46851067 | Not Available |
| 18 | Not Available | FRONT AXLE ASSEMBLY | 91001159 | Not Available |
| 19 | Not Available | MAIN BODY / NOZZLE BASE | 91001156 | Not Available |
| 21 | Not Available | VALVE ARM SPRING | 38331006 | Not Available |
| 22 | Not Available | VALVE DOOR - BLACK | 91001142 | Not Available |
| 24 | Not Available | REAR WHEEL ASSEMBLY | 521960001 | Not Available |
| 25 | Not Available | REAR AXLE | 32434007 | Not Available |
| 26 | Not Available | RETAINING RING | 91001106 | Not Available |
| 27 |  | Hoover U8300 Vacuum Cleaner Belt H-38528050 | 38528050 | $14.68Add to cart Special order: ships in 2 to 4 weeks |
| 28 | Not Available | TRANSFER PULLEY | 43241009 | Not Available |
| 29 | Not Available | TRANSFER PULLEY SHAFT | 91001110 | Not Available |
| 30 | Not Available | RETAINING RING | 91001107 | Not Available |
| 31 |  | NLA USE SKU 38-3305-04 Hoover Wind Tunnel Self Propelled Belt | 38528034 | $10.99Read more |
| 32 | Not Available | BELT COVER - BLACK | 91001128 | Not Available |
| 33 | Not Available | AGITATOR / BRUSH ROLL ASSEMBLY - WOODEN | 48414160 | Not Available |
| 34 |  | Seal-Agitator Pulley-Hoover U5445 For: hoover | 38781053 | $1.44Add to cart |
| 35 | Not Available | BOTTOM PLATE / NOZZLE GUARD | 42246146 | Not Available |
| 36 | Not Available | SCREW - SELF TAPPING 5/8" | 214793DA | Not Available |
| 36 | Not Available | WIRE HARNESS | 46383348 | Not Available |
| 36 | Not Available | BARE FLOOR BRUSH - 12" | 59156137 | Not Available |
| 36 | Not Available | STATIC WIRE ASSEMBLY | 47811008 | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | SCREW - SELF TAPPING | 21447242 | Not Available |
| 2 | Not Available | PCB HEIGHT ADJUSTMENT BOARD | 46851063 | Not Available |
| 3 | Not Available | CARRY HANDLE COVER | 37258198 | Not Available |
| 4 | Not Available | SCREW - SELF TAPPING 5/8" | 214793DA | Not Available |
| 5 | Not Available | HEIGHT ADJUSTMENT KNOB | 38411041 | Not Available |
| 6 | Not Available | POWER BUTTON | 90001353 | Not Available |
| 7 | Not Available | CLEAN AIR DUCT | 91001140 | Not Available |
| 8 |  | Gasket,Circular Foam Adh Dirt Cup Filter U8371-900 Part Number: 38784105 for Hoover | 38784105 | $5.18Read more |
| 9 | Not Available | FILTER KIT ASSEMBLY | 12002820 | Not Available |
| 10 | Not Available | THRUST WASHER | 21312837 | Not Available |
| 11 |  | GASKET, FILTER U8351 Part Number: 91001172 for Hoover | 91001172 | $11.39Read more |
| 12 | Not Available | FILTER KIT ASSEMBLY | 12002820 | Not Available |
| 13 | | GASKET, FILTER U8351 Part Number: 91001173 for Hoover | 91001173 | $3.23Read more |
| 14 | Not Available | FILTER HOUSING - LEGACY PURPLE | 92001296 | Not Available |
| 15 | Not Available | PRIMARY FILTER TRANSMISSION | 27271004 | Not Available |
| 16 | Not Available | FILTER PARTITION | 91001143 | Not Available |
| 17 | Not Available | FILTER FLICKER | 91001155 | Not Available |
| 18 | No Image | SPRING, FLICKER TORSION U5183-900 Part Number: 91001175 for Hoover | 91001175 | $1.57Read more |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | DIRT CUP LATCH | 91001115 | Not Available |
| 2 | Not Available | LATCH SPRING | 90001037 | Not Available |
| 3 | Not Available | DIRT CUP LID GASKET | 38783042 | Not Available |
| 4 | Not Available | DIRT CUP LID - NEURON ORANGE | 92001298 | Not Available |
| 5 | | Gasket,Circular Foam Adh Dirt Cup Filter U8371-900 Part Number: 38784105 for Hoover | 38784105 | $5.18Read more |
| 6 | Not Available | DIRT CUP PARTITION | 38766038 | Not Available |
| 7 | Not Available | DIRT CUP INSERT | 92001289 | Not Available |
| 8 | Not Available | SCREW - SELF TAPPING | 21447242 | Not Available |
| 10 | Not Available | DIRT CUP | 92001299 | Not Available |
| 11 | Not Available | DIRT CUP DOOR | 91001130 | Not Available |
| 12 | Not Available | DIRT CUP DOOR LATCH LEVER - BLACK | 91001114 | Not Available |
| 13 | No Image | SPRING, TORSION U8361-900 Part Number: 91001176 for Hoover | 91001176 | $1.78Read more |
| 14 | No Image | GASKET, DIRT CUP U8361 Part Number: 91001149 for Hoover | 91001149 | $4.00Read more |
