Schematic and parts book for Hoover U5025900, U5025-900 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 3 | Not Available | Hose Assm | 59153094 | Not Available |
| 4 | Not Available | Combo Brush | 59153102 | Not Available |
| 5 | Not Available | ST Screw M4x12 | 59153007 | Not Available |
| 6 | Not Available | Combo Tool Clip | 59153005 | Not Available |
| 8 | Not Available | Crevice Tool | 59153100 | Not Available |
| 11 | Not Available | Handle | 59153001 | Not Available |
| 12 | Not Available | Cord Wrap Upper | 59153006 | Not Available |
| 12 | Not Available | Dust Tank Cover | 59153052 | Not Available |
| 12 | Not Available | DUST TANK COVER ASSEMBLY (INC. | 59153164 | Not Available |
| 13 | Not Available | Filter Bracket | 59153063 | Not Available |
| 14 |  | Hoover HEPA Filter for Widepath PowerMax Turbo Power | 40110008 | $14.29Read more |
| 15 | Not Available | Pre-filter w/Screen | 59153060 | Not Available |
| 16 | Not Available | ST Screw M 4x12 01700 1FW | 59153007 | Not Available |
| 17 | Not Available | Wand Clip | 59153013 | Not Available |
| 18 | Not Available | HOOD ASSEMBLY - AGZ - U5023-90 | 59153166 | Not Available |
| 18 | Not Available | EXTENSION TUBE-AG | 38634078 | Not Available |
| 19 | Not Available | Hood | 59153071 | Not Available |
| 20 | Not Available | Switch Cover | 59153022 | Not Available |
| 21 | Not Available | ST Screw M4x12 | 59153007 | Not Available |
| 22 | Not Available | Housing Back | 59153010 | Not Available |
| 23 | Not Available | Elbow Con Tube | 59153024 | Not Available |
| 24 | Not Available | Air Path Back Cover | 59153015 | Not Available |
| 25 | Not Available | Seal-Inlet (3 pc) | 59153030 | Not Available |
| 26 | Not Available | ST Screw M3x12 | 59153033 | Not Available |
| 27 |  | DIRT CUP, SPRINT U5025- 900 Part Number: 59153062 for Hoover | 59153062 | $33.21Read more |
| 28 | Not Available | Dust Tank Ret | 59153012 | Not Available |
| 29 | Not Available | ST Screw M4x12 | 59153007 | Not Available |
| 30 | Not Available | Seal-Outlet (4 pc) | 59153031 | Not Available |
| 31 | Not Available | Motor Filter | 59153029 | Not Available |
| 32 | Not Available | Mtr Fil Holder | 59153021 | Not Available |
| 33 |  | Filter, :( Final Exhaust U5025 Bagless Bel Part Number: 59153028 for Hoover | 59153028 | $3.33Read more |
| 34 | Not Available | Hose Hdl Rank | 59153018 | Not Available |
| 35 | Not Available | Exhaust Grid | 59153136 | Not Available |
| 36 | Not Available | Ex Deflector Cover | 59153016 | Not Available |
| 37 | Not Available | Blwr Inlet Cushion | 59153027 | Not Available |
| 38 |  | MOTOR, U5023-900 UPRIGHT Part Number: 59153036 for Hoover | 59153036 | $87.08Read more |
| 39 | Not Available | Blwr Cush/Belt End | 59153020 | Not Available |
| 40 | Not Available | Foot Hose Clamp | 59153083 | Not Available |
| 41 | Not Available | Tool Rack | 59153017 | Not Available |
| 42 | No Image | HOSE, LOWER U5025-900 Part Number: 59153081 for Hoover | 59153081 | $12.18Read more |
| 43 | Not Available | Pivot Cover/Up Body | 59153079 | Not Available |
| 44 | Not Available | Ht Adj Knob | 59153074 | Not Available |
| 45 | Not Available | Ht Adj. Lower | 59153075 | Not Available |
| 46 | Not Available | Pedal | 59153080 | Not Available |
| 47 | Not Available | Main Body | 59153073 | Not Available |
| 48 | Not Available | Rear Wheel | 59153077 | Not Available |
| 49 | Not Available | Rear Wheel Shaft | 59153078 | Not Available |
| 50 | Not Available | AG BELT-12AMP BULK | 38528040 | Not Available |
| 51 | Not Available | Fr. Wheel | 59153067 | Not Available |
| 52 | Not Available | AGITATOR | 48414127 | Not Available |
| 53 | No Image | BOTTOM PLATE MODEL 5025 Part Number: 59153076 for Hoover | 59153076 | $8.28Read more |
| 54 | Not Available | Poppet Valv e-U502590 | 59153025 | Not Available |
| 55 | Not Available | Housing Front | 59153011 | Not Available |
| 56 | Not Available | ST Screw M4x12 | 59153007 | Not Available |
| 57 | Not Available | BULB | 27313107 | Not Available |
| 58 | Not Available | Headlt Cover | 59153026 | Not Available |
| 59 | Not Available | Switch | 59153037 | Not Available |
| 60 | Not Available | Deflector Door | 59153019 | Not Available |
| 61 | Not Available | Bulb Socket-U5025900 | 59153042 | Not Available |
| 90 | Not Available | Power Cord-21 Ft | 59153034 | Not Available |
| 90 | Not Available | Owner Manual | 59153119 | Not Available |
