Schematic and parts book for Hoover U4247030, U4247-900 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Popular Supplies
| # | Part image | Description | SKU | Price |
| 1 | Not Available | UPPER HANDLE ASSM - | 48663142 | Not Available |
| 1 | Not Available | UPPER HANDLE ASSEM-M | 48663141 | Not Available |
| 1 | Not Available | EXTENSION TUBE-AG-PO | 3863801P | Not Available |
| 1 | Not Available | THREAD GUARD - RH - | 36423016 | Not Available |
| 2 | Not Available | CORD-30 FT-U5254/56 | 46388043 | Not Available |
| 2 | Not Available | HANDLE CAP - ABE | 37911079 | Not Available |
| 2 | Not Available | FURNITURE BRUSH-AG | 43414016 | Not Available |
| 2 | Not Available | FAN CHAMBER | 38736033 | Not Available |
| 2 |  | NO LONGER AVAILABLE Bearing, Brushroll W/Nylon Washer Celebrity/Spirit Part Number: 43267002 for ... | 43267002 | $4.81Read more |
| 3 | Not Available | ATTACH. CORD | 46388027 | Not Available |
| 3 |  | Crevice Tool-Hoover - W/Pin - Canister - Grey
Nla 10-2023 - Please Use Alt Part Number For: hoover | 38617017 | $2.53Read more |
| 3 | Not Available | FAN | 38755030 | Not Available |
| 3 | Not Available | CONICAL WASHER | 21347003 | Not Available |
| 4 | Not Available | BAG STRAP SPRING - A | 38335020 | Not Available |
| 4 | Not Available | HOSE CONNECTOR-AAP-U | 32288004 | Not Available |
| 4 | Not Available | AGITATOR END - U4455 | 36422022 | Not Available |
| 5 | Not Available | BAG STRAP-ABE | 36425071 | Not Available |
| 5 | Not Available | BAG STRAP-ABE-U4717- | 36425072 | Not Available |
| 5 | Not Available | HOSE LESS ENDS-AAP-U | 38671028 | Not Available |
| 6 | Not Available | JACKET SUPPORT-UPPER | 36425067 | Not Available |
| 6 | Not Available | JACKET SUP-UPPER-ABE | 36425064 | Not Available |
| 6 | Not Available | HOSE SLEEVE - BZ | 32156010 | Not Available |
| 6 | Not Available | AGITATOR SHAFT - U44 | 32724013 | Not Available |
| 7 | Not Available | OUTER JACKET-U4253-9 | 43675182 | Not Available |
| 7 | Not Available | OUTER JACKET-U4166-9 | 43686240 | Not Available |
| 7 | Not Available | JACKET ASSEM.-U4247- | 43675183 | Not Available |
| 7 | Not Available | HOSE CONNECTOR COLLA | 36171025 | Not Available |
| 7 | Not Available | THREAD GUARD - LH - | 36423017 | Not Available |
| 8 | Not Available | SWITCH CONTROL ROD | 38456036 | Not Available |
| 8 | Not Available | HOSE CONNECTOR-CURVE | 43466058 | Not Available |
| 8 | Not Available | HAND GRIP | 39454059 | Not Available |
| 9 | Not Available | LOWER HANDLE - ABE | 39464005 | Not Available |
| 9 | Not Available | LATCH RING-AG-S3273 | 36153009 | Not Available |
| 10 | Not Available | NUT & BOLT ASSEMBLY- | 40201085 | Not Available |
| 10 | Not Available | HOSE ASSEM COMP-AAP- | 43434210 | Not Available |
| 10 | Not Available | SWITCH BUS BAR - U44 | 36914004 | Not Available |
| 11 |  | Lower Jacket Support-Hoover 4557/4731 For: hoover | 36425063 | $7.84Add to cart Special order: ships in 2 to 4 weeks |
| 11 | Not Available | JACKET SUPPORT-LOWER | 36425068 | Not Available |
| 11 | Not Available | FLOOR BRUSH-AG-S3273 | 43414073 | Not Available |
| 11 |  | Dusting Brush, Accessory Kit W/Locking Tab CH30000 Part Number: 43414064 for Hoover | 43414064 | $7.15Add to cart Special order: ships in 2 to 4 weeks |
| 11 |  | Upholstery Tool, With plastic bump for hoover porta power | 43414057 | $9.58Add to cart Special order: ships in 2 to 4 weeks |
| 11 | Not Available | CONVERTOR BODY-AAP-U | 38656016 | Not Available |
| 11 | Not Available | ATTACHMENT TERMINAL | 39116005 | Not Available |
| 11 |  | COVER, MOTOR U5272-9RM BAGLESS UPRIGHT W/HEADLT Part Number: 37194050 for Hoover | 37194050 | $21.18Read more |
| 12 | Not Available | WHEEL REAR - AG | 38522011 | Not Available |
| 12 | Not Available | SWITCH ASSEMBLY - U4 | 28218043 | Not Available |
| 12 | Not Available | SWITCH ASSEMBLY-ELIT | 28161062 | Not Available |
| 13 | Not Available | REAR WHEEL SHAFT | 31523012 | Not Available |
| 14 | Not Available | MAIN BODY ASSEM W/RE | 42242270 | Not Available |
| 14 | Not Available | MOTOR END CAP W/HL | 37194049 | Not Available |
| 15 | Not Available | HANDLE RELEASE LEVER | 38458022 | Not Available |
| 16 | Not Available | MOTOR RETAINER CAP - | 36131057 | Not Available |
| 16 |  | Fan Washer-Hoover Elite Motor For: hoover | 21312793 | $1.11Add to cart Special order: ships in 2 to 4 weeks |
| 17 | Not Available | SCREW-SELF TAPPING | 21447217 | Not Available |
| 17 | Not Available | DUCT SEAL-MOLDED | 38783020 | Not Available |
| 18 |  | Paper Bags-Hoover - A - 3Pk - Top Fill - Upright For: hoover | 4010001A | $7.24Add to cart Special order: ships in 2 to 4 weeks |
| 18 | Not Available | BRUSH HOLDER ASSEMBL | 41311016 | Not Available |
| 19 | Not Available | HOOD-ABN-U4245-030 | 37252112 | Not Available |
| 19 | Not Available | HOOD-AAY-U4249-030 | 37252114 | Not Available |
| 19 | Not Available | HOOD-ABN-U4247-030 | 37252113 | Not Available |
| 19 | Not Available | HOOD-JM-U4467 | 37252067 | Not Available |
| 19 | Not Available | HOOD-AAY-U4250 | 37252115 | Not Available |
| 19 | Not Available | HOOD - MT - U4455 | 37252065 | Not Available |
| 19 | Not Available | HOOD-ABN-U4245 | 37252111 | Not Available |
| 19 | Not Available | HOOD-MR-U4467-980 | 37252081 | Not Available |
| 19 | Not Available | HOOD-AAP-U4283-970 | 37252110 | Not Available |
| 19 | Not Available | HOOD-MN-U4467-960 | 37252087 | Not Available |
| 19 | Not Available | TAPE - CONCEPT MOTOR | 54821001 | Not Available |
| 19 | Not Available | DUCT SEAL - ELITE | 38781013 | Not Available |
| 20 | Not Available | MOTOR RETAINER | 36131090 | Not Available |
| 21 | Not Available | MOTOR-12 AMP-U4250 | 43576205 | Not Available |
| 21 | Not Available | MOTOR-C1404/12/14-90 | 43576201 | Not Available |
| 21 | Not Available | MOTOR COMPLETE W/O H | 43576141 | Not Available |
| 22 | Not Available | BELT-ELITE | 38528027 | Not Available |
| 22 | Not Available | AG BELT-12AMP BULK | 38528040 | Not Available |
| 23 | Not Available | RIB SHOE | 13261AY | Not Available |
| 24 | Not Available | WHEEL RETAINER - BZ | 36131056 | Not Available |
| 25 | Not Available | FRONT WHEEL ASSEM-C1 | 43248055 | Not Available |
| 26 | Not Available | WHEEL SHAFT - AY -U | 32563012 | Not Available |
| 27 | Not Available | FRONT WHEEL ASSEM-C1 | 43248055 | Not Available |
| 28 | Not Available | AGITATOR-AG | 48414079 | Not Available |
| 29 | Not Available | BOTTOM PLATE -AG | 37245106 | Not Available |
| 29 | Not Available | BOTTOM PLATE - AG | 37245017 | Not Available |
| 30 | Not Available | SEAL - U4455 | 38784016 | Not Available |
| 31 | Not Available | REAR SUPPORT-U4467-9 | 58369061 | Not Available |
| 31 | Not Available | OWNER MANUAL-ELITE/S | 56511280 | Not Available |
| 31 | Not Available | OWNER MANUAL-U4283/U | 56511343 | Not Available |
| 31 | Not Available | OWNER MANUAL-U4245-0 | 56511387 | Not Available |
| 31 | Not Available | OWNER M NUAL-U4245 | 56511390 | Not Available |
| 31 | Not Available | OWNER M NUAL-U4247-0 | 56511A18 | Not Available |
| 31 | Not Available | OWNER MANUAL-U4266-9 | 56511B24 | Not Available |
| 31 | Not Available | FRONT SUPPORT - U445 | 58346004 | Not Available |
| 31 | Not Available | REAR SUPPORT - U4455 | 58353009 | Not Available |
| 40 | Not Available | GASKET-MAIN BODY | 34123056 | Not Available |
| 40 | Not Available | CREVICE TOOL - AG | 38617024 | Not Available |
| 40 | Not Available | EXTENSION TUBE-AG | 38634078 | Not Available |
| 40 | Not Available | CONVERTOR BODY-AAP-U | 38656016 | Not Available |
| 40 | Not Available | CORD WRAP | 3944201P | Not Available |
| 40 | Not Available | DUSTING BRUSH | 43414145 | Not Available |
| 40 | Not Available | HOSE ASSEMBLY COMP-F | 43434225 | Not Available |
| 40 | Not Available | FURNITURE NOZZLE-AG | 38614029 | Not Available |
