Schematic and parts book for Hoover H3040, H3044, H3045 FloorMate. Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Popular Supplies
| # | Part image | Description | SKU | Price |
| 1 | Not Available | BEARING - MODE CONTROL RIGHT | 93001119 | Not Available |
| 2 | Not Available | CABLE - MODE CONTROL | 93001120 | Not Available |
| 2 | Not Available | CABLE RETAINER - FOOT | 93002293 | Not Available |
| 3 | Not Available | CABLE RETAINER | 93001136 | Not Available |
| 4 | Not Available | ACTUATOR - MODE CONTROL | 93001121 | Not Available |
| 5 | No Image | SPRING, MODE CONTROL Part Number: 93001122 for Hoover | 93001122 | $1.03Read more |
| 6 | Not Available | SWITCH - MODE CONTROL | 59178361 | Not Available |
| 7 | Not Available | BEARING - MODE CONTROL LEFT | 93001123 | Not Available |
| 8 | Not Available | KNOB - MODE CONTROL CRYSTAL BLUE | 59178552 | Not Available |
| 8 | Not Available | KNOB - MODE CONTROL IMPERIAL RED | 59178907 | Not Available |
| 9 | No Image | HOUSING, TANK H3030 Part Number: 93001129 for Hoover | 93001129 | $21.34Read more |
| 10 | Not Available | SCREW #8 X 12-3/4" | 93001736 | Not Available |
| 11 | Not Available | UPPER CORD WRAP | 93001130 | Not Available |
| 12 | Not Available | LOWER CORD HOOK | 93001131 | Not Available |
| 13 | Not Available | CORD RETAINER | 93001127 | Not Available |
| 14 | No Image | SCREW, MODE CONTROL Part Number: 93001733 for Hoover | 93001733 | $0.94Read more |
| 15 | Not Available | LATCH - UPPER HANDLE CRYSTAL BLUE | 59178535 | Not Available |
| 15 | Not Available | LATCH - UPPER HANDLE IMPERIAL RED | 59178910 | Not Available |
| 16 | Not Available | SPRING | 93001159 | Not Available |
| 17 | Not Available | SCREW #6 X 10-1/2" | 93001734 | Not Available |
| 18 | Not Available | LOWER SUCTION DUCT | 93001172 | Not Available |
| 19 | Not Available | HOSE ASSEMBLY | 59178830 | Not Available |
| 19 | Not Available | HOSE ASSEMBLY | 59178899 | Not Available |
| 20 | Not Available | CONTROL ROD - LOWER | 93001161 | Not Available |
| 21 |  | SWITCH, RESET FLOORMATE Part Number: 93001160 for Hoover | 93001160 | $5.30Read more |
| 22 | Not Available | RESERVOIR ASSEMBLY | 93001829 | Not Available |
| 23 | Not Available | O-RING | 93001155 | Not Available |
| 24 | Not Available | TUBING - 28" | 93001165 | Not Available |
| 25 | Not Available | HANDLE RETAINER | 93001154 | Not Available |
| 26 | Not Available | CARRY HANDLE | 93001176 | Not Available |
| 26 | Not Available | CARRY HANDLE | 59178909 | Not Available |
| 27 | Not Available | SEAL - SUCTION DUCT | 93001174 | Not Available |
| 28 | Not Available | SEAL - RECOVERY DUCT | 93001175 | Not Available |
| 29 | Not Available | RECOVERY DUCT | h-93002026 | Not Available |
| 30 | Not Available | SUCTION DUCT | 59178291 | Not Available |
| 31 | Not Available | CORD COVER - TANK HOUSING | 93001166 | Not Available |
| 32 | No Image | SCREW, #6 X 24 3/8 Part Number: 93001735 for Hoover | 93001735 | $1.12Read more |
| 33 | Not Available | SEAL | 93001743 | Not Available |
| 33 | Not Available | RECOVERY SEAL PLATE | 93001995 | Not Available |
| 34 | Not Available | O-RING | 93001202 | Not Available |
| 35 | Not Available | MOTOR COVER REAR | 93001173 | Not Available |
| 36 | Not Available | MOTOR SEAL RETAINER | 93001186 | Not Available |
| 37 | Not Available | MOTOR MOUNT | 93001185 | Not Available |
| 38 | Not Available | SEAL - MOTOR END BEARINGS | 93001184 | Not Available |
| 39 | Not Available | MOTOR COVER CAP - CRYSTAL BLUE | 59178507 | Not Available |
| 39 | Not Available | MOTOR COVER CAP - CLEAR | 59178915 | Not Available |
| 40 | Not Available | MOTOR COVER VENT | 93001194 | Not Available |
| 41 | Not Available | MOTOR COVER | 93001193 | Not Available |
| 42 | Not Available | MOTOR ASSEMBLY | 93001828 | Not Available |
| 43 | Not Available | SEAL - MOTOR FAN | 93001190 | Not Available |
| 43 | Not Available | ATTACHMENT CORD | 93001203 | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | No Image | SCREW, MODE CONTROL Part Number: 93001733 for Hoover | 93001733 | $0.94Read more |
| 2 |  | Upper Handle Rh Blue For: hoover | 59178565 | $16.22Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 2 | Not Available | UPPER HANDLE - RIGHT IMPERIAL RED | 59178914 | Not Available |
| 3 | Not Available | SWITCH BOOT - CRYSTAL BLUE | 93001113 | Not Available |
| 3 | Not Available | SWITCH BOOT - IMPERIAL RED | 59178906 | Not Available |
| 4 | Not Available | SWITCH | 93001972 | Not Available |
| 5 | Not Available | CONTROL LEVER | 93001109 | Not Available |
| 6 |  | Upper Handle Lh Blue For: hoover | 59178564 | $16.44Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 6 | Not Available | UPPER HANDLE - LEFT IMPERIAL RED | 59178913 | Not Available |
| 7 | Not Available | WIRING HARNESS - UPPER HANDLE | 93001115 | Not Available |
| 8 | Not Available | CONTROL ROD UPPER | 93001110 | Not Available |
| 9 | Not Available | WIRING HARNESS - UPPER HANDLE CORE | 93001141 | Not Available |
| 10 | Not Available | UPPER HANDLE CORE ASSEMBLY | 93001137 | Not Available |
| 11 | Not Available | FILTER LID | 93001179 | Not Available |
| 12 |  | Filter, Floormate H3044/H3040/H3045 Recovery Tank Part Number: 40112050 for Hoover | 40112050 | $16.70Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 13 | Not Available | RECOVERY TANK LID ASSEMBLY - C BLUE | 93001181 | Not Available |
| 13 | Not Available | RECOVERY TANK LID ASSEMBLY - CLEAR | 59178875 | Not Available |
| 14 | Not Available | FLOAT - HINGED FRONT | 59178801 | Not Available |
| 15 | Not Available | RECOVERY TANK - CRYSTAL BLUE | 59178791 | Not Available |
| 15 | Not Available | RECOVERY TANK - CLEAR | 59178873 | Not Available |
| 16 | Not Available | SOLUTION TANK CAP ASSEMEMBLY - CRYSTAL BLUE | 93001143 | Not Available |
| 16 | Not Available | SOLUTION TANK CAP ASSEMEMBLY - IMPERIAL RED | 59178885 | Not Available |
| 17 |  | ***USE H-300107037 TANK, :(SOLUTION CRYSTAL BLUE Part Number: 93001146 for Hoover | 93001146 | $35.05Read more |
| 17 | Not Available | SOLUTION TANK ASSEMBLY - IMPERIAL RED | 59178884 | Not Available |
| 18 | Not Available | VALVE STEM | 93001148 | Not Available |
| 19 | Not Available | VALVE SEAL | 93001149 | Not Available |
| 20 | No Image | SPRING, VALVE FLOOR MATE H3030 Part Number: 93001150 for Hoover | 93001150 | $1.18Read more |
| 21 | Not Available | LATCH - SOLUTION TANK CRYSTAL BLUE | 59178493 | Not Available |
| 21 | Not Available | LATCH - SOLUTION TANK IMPERIAL RED | 59178882 | Not Available |
| 22 | No Image | SCREW, #6 X 24 3/8 Part Number: 93001735 for Hoover | 93001735 | $1.12Read more |
| 22 | Not Available | SPRING - SOLUTION TANK LATCH | 93001976 | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | HOOD REAR COVER - RIGHT | 93001041 | Not Available |
| 1 | Not Available | HOOD REAR COVER - RIGHT CLEAR | 59178904 | Not Available |
| 2 | Not Available | HOOD REAR COVER - LEFT | 93001038 | Not Available |
| 2 | Not Available | HOOD REAR COVER - LEFT CLEAR | 59178905 | Not Available |
| 3 | Not Available | HOOD / NOZZLE COVER | 93001057 | Not Available |
| 4 | Not Available | SCREW #8 X 12-3/4" | 93001736 | Not Available |
| 5 | Not Available | TRUNNION COVER - RIGHT | 93001056 | Not Available |
| 6 | Not Available | TRUNNION COVER - LEFT | 93001055 | Not Available |
| 7 | Not Available | HANDLE RELEASE PEDAL - CRYSTAL BLUE | 59178543 | Not Available |
| 7 | Not Available | HANDLE RELEASE PEDAL - IMPERIAL RED | 59178903 | Not Available |
| 8 | Not Available | GROMMET - WATER CHANNEL CRYSTAL BLUE | 59178534 | Not Available |
| 8 | Not Available | GROMMET - WATER CHANNEL IMPERIAL RED | 59178901 | Not Available |
| 9 | No Image | SPRING, HANDLE RELEASE H3030 H3060 Part Number: 93001049 for Hoover | 93001049 | $1.02Read more |
| 10 | Not Available | SPRING - HANDLE RELEASE | 93001051 | Not Available |
| 11 | Not Available | HANDLE RELEASE | 93001050 | Not Available |
| 12 | Not Available | LIFTER LINK | 93001068 | Not Available |
| 13 | Not Available | FASTENER - PINCH PIN | 93001066 | Not Available |
| 14 | Not Available | CAM ARM - BRUSH BLOCK | 93001069 | Not Available |
| 15 | Not Available | CAM ARM - FRONT WHEEL CARRIAGE | 93001067 | Not Available |
| 16 | Not Available | MAIN BODY / NOZZLE BASE - CRYSTAL BLU | 93001044 | Not Available |
| 16 | Not Available | MAIN BODY / NOZZLE BASE - IMPERIAL RED | 59178911 | Not Available |
| 17 | Not Available | LOCK RING | 59177088 | Not Available |
| 18 | Not Available | REAR WHEEL ASSEMBLY - CRYSTAL BLUE | 93001061 | Not Available |
| 18 | Not Available | REAR WHEEL ASSEMBLY - BLACK | 59178902 | Not Available |
| 19 | Not Available | REAR WHEEL AXLE | 93001059 | Not Available |
| 20 | Not Available | BRUSH MOTOR ASSEMBLY | 93001079 | Not Available |
| 21 | Not Available | LATCH - BRUSH BLOCK RIGHT CRYSTAL BLUE | 59178518 | Not Available |
| 21 | Not Available | LATCH - BRUSH BLOCK RIGHT IMPERIAL RED | 59178898 | Not Available |
| 22 | Not Available | NOZZLE LATCH - LEFT CRYSTAL BLUE | 93001071 | Not Available |
| 22 | Not Available | NOZZLE LATCH - LEFT IMPERIAL RED | 59178892 | Not Available |
| 23 | Not Available | NOZZLE ASSEMBLY - CRYSTAL BLUE | 59178924 | Not Available |
| 23 | Not Available | NOZZLE ASSEMBLY - IMPERIAL RED | 59178888 | Not Available |
| 24 | Not Available | NOZZLE LATCH - RIGHT CRYSTAL BLUE | 93001074 | Not Available |
| 24 | Not Available | NOZZLE LATCH - RIGHT IMPERIAL RED | 59178890 | Not Available |
| 25 | Not Available | SQUEEGEE ASSEMBLY - CRYSTAL BLUE | 93001095 | Not Available |
| 25 | Not Available | SQUEEGEE ASSEMBLY - IMPERIAL RED | 59178889 | Not Available |
| 26 | Not Available | BRUSH BLOCK ASSEMBLY - 7 BRUSH | 93001090 | Not Available |
| 26 | Not Available | GROUT BRUSH BLOCK ASSEMBLY H3044 | 93001092 | Not Available |
| 27 | Not Available | DISTRIBUTOR ASSEMBLY - CRYSTAL BLUE H3045 | 93001084 | Not Available |
| 27 | Not Available | DISTRIBUTOR ASSEMBLY - IMPERIAL RED | 59178894 | Not Available |
| 28 | Not Available | ELBOW CONNECTION | 93001086 | Not Available |
| 29 | Not Available | LATCH - BRUSH BLOCK LEFT CRYSTAL BLUE | 93001088 | Not Available |
| 29 | Not Available | LATCH - BRUSH BLOCK LEFT IMPERIAL RED | 59178897 | Not Available |
| 30 | Not Available | FRONT WHEEL | 59178205 | Not Available |
| 31 | Not Available | FRONT WHEEL SHAFT | 93001065 | Not Available |
| 32 | Not Available | FRONT WHEEL ASSEMBLY | 93001063 | Not Available |
