Schematic and parts book for Hoover H3030, H3032, H3060-900 Floor Mate. Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | Mode Control Bearing - RH | 93001119 | Not Available |
| 2 | Not Available | Mode Control Cable | 93001120 | Not Available |
| 3 | Not Available | Cable Retainer | 93001136 | Not Available |
| 4 | Not Available | Mode Control Actuator | 93001121 | Not Available |
| 5 | No Image | SPRING, MODE CONTROL Part Number: 93001122 for Hoover | 93001122 | $1.03Read more |
| 6 | Not Available | Mode Control Switch | 93001135 | Not Available |
| 7 | Not Available | Mode Control Bearing - LH | 93001123 | Not Available |
| 8 | Not Available | Mode Control Knob | 93001124 | Not Available |
| 9 | Not Available | Tool Door | 93001132 | Not Available |
| 10 | Not Available | Tank Housing | 93001128 | Not Available |
| 11 | Not Available | Screw #8-12 3/4"L | 93001736 | Not Available |
| 12 | Not Available | Attachment Cord | 93001203 | Not Available |
| 12 | Not Available | Upper Cord Hook | 93001130 | Not Available |
| 13 | Not Available | Lower Cord Hook | 93001131 | Not Available |
| 14 |  | SEAL, TUBE PORT Part Number: 93001164 for Hoover | 93001164 | $2.26Read more |
| 15 | Not Available | Cord Retainer | 93001127 | Not Available |
| 16 | No Image | SCREW, MODE CONTROL Part Number: 93001733 for Hoover | 93001733 | $0.94Read more |
| 17 | Not Available | Upper Handle Latch | 93001156 | Not Available |
| 18 | Not Available | Spring | 93001159 | Not Available |
| 19 | Not Available | Screw #6-10 1/2"L | 93001734 | Not Available |
| 20 | Not Available | Lower Suction Duct | 93001172 | Not Available |
| 21 | Not Available | Hose Ass'y | 93001191 | Not Available |
| 22 | Not Available | Lower Control Rod | 93001161 | Not Available |
| 23 |  | SWITCH, RESET FLOORMATE Part Number: 93001160 for Hoover | 93001160 | $5.30Read more |
| 24 | Not Available | Reservoir Ass'y | 93001162 | Not Available |
| 25 | Not Available | O-Ring | 93001155 | Not Available |
| 26 | Not Available | Tubing - Pump | 93001134 | Not Available |
| 27 | Not Available | Tubing - Quick Disconnect | 93001169 | Not Available |
| 28 | Not Available | O-Ring | 93001171 | Not Available |
| 29 | Not Available | Quick Disconnect | 93001170 | Not Available |
| 30 | Not Available | Pump | 93001163 | Not Available |
| 31 | Not Available | Screw #6-10 1/2"L | 93001734 | Not Available |
| 32 | No Image | Gasket, Circular Gray Turbine Pump Duct Seal H3060 Part Number: 93001168 for Hoover | 93001168 | $1.18Read more |
| 33 | Not Available | Distributor Tubing | 93001165 | Not Available |
| 34 | Not Available | Handle Retainer | 93001154 | Not Available |
| 35 | Not Available | Carry Handle | 93001176 | Not Available |
| 36 | Not Available | Suction Duct Seal | 93001174 | Not Available |
| 37 | Not Available | Recovery Duct Seal | 93001175 | Not Available |
| 38 | Not Available | Recovery Duct | 93001201 | Not Available |
| 39 | Not Available | Suction Duct | 93001167 | Not Available |
| 40 | Not Available | Tank Housing Cord Cover | 93001166 | Not Available |
| 41 | No Image | SCREW, #6 X 24 3/8 Part Number: 93001735 for Hoover | 93001735 | $1.12Read more |
| 42 | Not Available | Seal | 93001743 | Not Available |
| 43 | Not Available | O-Ring | 93001202 | Not Available |
| 44 | Not Available | Motor Cover - Rear | 93001173 | Not Available |
| 45 | Not Available | Motor Seal Retainer | 93001186 | Not Available |
| 46 | Not Available | Motor Mount | 93001185 | Not Available |
| 47 | Not Available | Motor End Bearing Seal | 93001184 | Not Available |
| 48 | Not Available | Motor Cover Cap | 93001198 | Not Available |
| 49 | Not Available | Motor Cover Vent | 93001194 | Not Available |
| 50 | Not Available | Motor Cover | 93001193 | Not Available |
| 51 | Not Available | Motor Ass'y | 93001189 | Not Available |
| 52 | Not Available | Motor Fan Seal | 93001190 | Not Available |
| 53 | No Image | SCREW, MODE CONTROL Part Number: 93001733 for Hoover | 93001733 | $0.94Read more |
| 54 | Not Available | Upper Handle - RH | 93001138 | Not Available |
| 55 | Not Available | Switch Boot | 93001111 | Not Available |
| 56 | Not Available | Main Switch | 93001114 | Not Available |
| 57 | Not Available | Control Lever | 93001109 | Not Available |
| 58 | Not Available | Upper Handle - LH | 93001116 | Not Available |
| 59 | Not Available | Wiring Harness | 93001115 | Not Available |
| 60 | Not Available | Control Rod Upper | 93001110 | Not Available |
| 61 | Not Available | Wiring Harness | 93001141 | Not Available |
| 62 | Not Available | Upper Handle Core Ass'y | 93001137 | Not Available |
| 63 | Not Available | Filter Lid | 93001179 | Not Available |
| 64 | Not Available | Filter | 59177051 | Not Available |
| 65 | Not Available | Recovery Tank Lid Ass'y | 93001180 | Not Available |
| 66 | Not Available | Float | 93001183 | Not Available |
| 67 | Not Available | Recovery Tank | 93001195 | Not Available |
| 68 | Not Available | Solution Tank Cap Ass'y | 93001142 | Not Available |
| 69 | Not Available | Solution Tank Ass'y | 93001145 | Not Available |
| 70 | Not Available | Valve Stem | 93001148 | Not Available |
| 71 | Not Available | Valve Seal | 93001149 | Not Available |
| 72 | No Image | SPRING, VALVE FLOOR MATE H3030 Part Number: 93001150 for Hoover | 93001150 | $1.18Read more |
| 73 | Not Available | Latch | 93001151 | Not Available |
| 74 | No Image | SCREW, #6 X 24 3/8 Part Number: 93001735 for Hoover | 93001735 | $1.12Read more |
| 75 | Not Available | Hood Rear Cover - RH | 93001040 | Not Available |
| 76 | Not Available | Hood Rear Cover - LH | 93001037 | Not Available |
| 77 | Not Available | Hood | 93001057 | Not Available |
| 78 | Not Available | Screw #8-12 3/4"L | 93001736 | Not Available |
| 79 | Not Available | Trunnion Cover - RH | 93001056 | Not Available |
| 80 | Not Available | Trunnion Cover - LH | 93001055 | Not Available |
| 81 |  | PEDAL, HANDLE RELEASE H3030 Part Number: 93001046 for Hoover | 93001046 | $3.79Read more |
| 82 | Not Available | Water Channel Grommet | 93001052 | Not Available |
| 83 | No Image | SPRING, HANDLE RELEASE H3030 H3060 Part Number: 93001049 for Hoover | 93001049 | $1.02Read more |
| 84 | Not Available | Handle Release Spring | 93001051 | Not Available |
| 85 | Not Available | Handle Release | 93001050 | Not Available |
| 86 | Not Available | Lifter Link | 93001068 | Not Available |
| 87 | Not Available | Pinch Pin Fastener | 93001066 | Not Available |
| 88 | Not Available | Brush Block Cam Arm | 93001069 | Not Available |
| 89 | Not Available | Front Wheel Carriage Cam Arm | 93001067 | Not Available |
| 90 | Not Available | Main Body H3030 | 93001045 | Not Available |
| 90 | Not Available | Main Body H3060 | 93001043 | Not Available |
| 91 | Not Available | Lock Ring | 59177088 | Not Available |
| 92 | Not Available | Rear Wheel Ass'y | 93001060 | Not Available |
| 93 | Not Available | Rear Wheel Axle | 93001059 | Not Available |
| 94 | Not Available | Brush Motor Ass'y | 93001079 | Not Available |
| 95 | Not Available | Brush Block Latch RH | 93001080 | Not Available |
| 96 | Not Available | Nozzle Latch LH H3030 | 93001072 | Not Available |
| 96 | Not Available | Nozzle Latch LH H3060 | 93001070 | Not Available |
| 97 | Not Available | Nozzle H3030 | 93001078 | Not Available |
| 97 | Not Available | Nozzle H3060 | 93001076 | Not Available |
| 98 | Not Available | Nozzle Latch RH H3030 | 93001075 | Not Available |
| 98 | Not Available | Nozzle Latch RH H3060 | 93001073 | Not Available |
| 99 | Not Available | Squeegee H3030 | 93001096 | Not Available |
| 99 | Not Available | Squeegee H3060 | 93001094 | Not Available |
| 100 | Not Available | Brush Block Ass'y H3060 (7 Brush) | 93001090 | Not Available |
| 100 | Not Available | Brush Block Ass'y H3060- Grout (7 Brush' | 93001092 | Not Available |
| 100 | Not Available | Brush Block Ass'y H3030 H3032 (6 Brush) | 93001091 | Not Available |
| 100 | Not Available | Brush Block Ass'y H3030 H3032 Grout) | 93001093 | Not Available |
| 101 | Not Available | Distributor Ass'y H3030 | 93001085 | Not Available |
| 101 | Not Available | Distributor Ass'y H3032 H3060 | 93001083 | Not Available |
| 102 | Not Available | Elbow Connector | 93001086 | Not Available |
| 103 | Not Available | Brush Block Latch LH | 93001087 | Not Available |
| 104 | Not Available | Front Wheel | 93001064 | Not Available |
| 105 | Not Available | Front Wheel Shaft | 93001065 | Not Available |
| 106 | Not Available | Front Wheel Ass'y | 93001063 | Not Available |
| 107 | Not Available | Tool/Hose Caddy | 93001097 | Not Available |
| 108 | Not Available | Tool/Hose Caddy Insert | 93001099 | Not Available |
| 109 | Not Available | Grout Tool With Brush Ass'y | 93001103 | Not Available |
| 110 | Not Available | Hose/Grip Ass'y | 93001101 | Not Available |
| 111 | Not Available | Squeegee Tool Ass'y | 93001105 | Not Available |
| 112 | Not Available | Extension Tube Ass'y | 93001107 | Not Available |
