Schematic and parts book for Hoover H2850 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | No Image | SCREW, MODE CONTROL Part Number: 93001733 for Hoover | 93001733 | $0.94Read more |
| 1 | Not Available | SCREW #8-12 3/4"L | 93001736 | Not Available |
| 1 | Not Available | NOZZLE LATCH - RIGHT C | 93001984 | Not Available |
| 2 | Not Available | SCREW #6-10 1/2"L | 93001734 | Not Available |
| 2 | Not Available | CORD WRAP - UPPER | 93001130 | Not Available |
| 2 | Not Available | NOZZLE ASSY - C | 93001981 | Not Available |
| 3 | Not Available | UPPER HANDLE RIGHT | 93001967 | Not Available |
| 3 | Not Available | TANK HOUSING - C | 93001989 | Not Available |
| 3 | Not Available | NOZZLE LATCH - LEFT C | 93001983 | Not Available |
| 4 | Not Available | SWITCH BOOT W/PAD PRINT | 93001969 | Not Available |
| 4 | Not Available | CORD HOOK - LOWER | 93001131 | Not Available |
| 4 | No Image | SCREW, TOREX L Part Number: 93001741 for Hoover | 93001741 | $1.02Read more |
| 5 | Not Available | CONTROL LEVER | 93001109 | Not Available |
| 5 | No Image | SCREW, MODE CONTROL Part Number: 93001733 for Hoover | 93001733 | $0.94Read more |
| 5 | No Image | SCREW, NO 6-10 3/4" L Part Number: 93001742 for Hoover | 93001742 | $1.12Read more |
| 6 | Not Available | UPPER HANDLE LEFT | 93001966 | Not Available |
| 6 | Not Available | CORD RETAINER | 93001127 | Not Available |
| 6 | Not Available | SQUEEGEE OVERMOLDED | 93001982 | Not Available |
| 7 | Not Available | SWITCH MAIN (DOUBLE POLE/TAPE) | 93001972 | Not Available |
| 7 | Not Available | CONTROL ROD - LOWER | 93001161 | Not Available |
| 7 | Not Available | SCREW #8-12 3/4"L | 93001736 | Not Available |
| 8 | Not Available | GROMMET UPPER | 93001968 | Not Available |
| 8 | Not Available | RESERVOIR ASSEMBLY | 93001829 | Not Available |
| 8 | Not Available | HOOD C (WITH PAD PRINT) | 93001994 | Not Available |
| 9 | Not Available | CONTROL ROD UPPER | 93001110 | Not Available |
| 9 | Not Available | O RING | 93001155 | Not Available |
| 9 | Not Available | TUBING PROTECTOR JACKET - C | 93002003 | Not Available |
| 10 | Not Available | MOLEX MALE 12 A CRIMP TERMINAL | 93001971 | Not Available |
| 10 | Not Available | HANDLE RETAINER - C | 93001990 | Not Available |
| 10 | Not Available | DISTRIBUTOR ASSEMBLY | 93001978 | Not Available |
| 11 | Not Available | QUICK CONNECT RECEPTACLE | 93001970 | Not Available |
| 11 | Not Available | SCREW #8-12 3/4"L | 93001736 | Not Available |
| 11 | No Image | COVER, RIGHT REAR HOOD Part Number: 93001993 for Hoover | 93001993 | $4.69Read more |
| 12 | Not Available | UPPER HANDLE CORE LEFT C | 93001973 | Not Available |
| 12 | Not Available | SOLUTION TANK SUPPORT | 93001988 | Not Available |
| 12 |  | Hood Rearcover-Lh -H3030 For: hoover | 93001039 | $3.21Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 13 | Not Available | UPPER HANDLE CORE RIGHT C | 93001974 | Not Available |
| 13 | Not Available | SEAL-SUCTION DUCT | 93001174 | Not Available |
| 13 | Not Available | TRUNNION COVER-RH | 93001056 | Not Available |
| 14 | Not Available | FILTER LID | 93001179 | Not Available |
| 14 | Not Available | SEAL - RECOVERY DUCT | 93001175 | Not Available |
| 14 | Not Available | TRUNNION COVER-LH | 93001055 | Not Available |
| 15 | Not Available | Filter-FloorMate | 59177051 | Not Available |
| 15 | Not Available | SCREW #6-10 1/2"L | 93001734 | Not Available |
| 15 | Not Available | HANDLE RELEASE | 93001050 | Not Available |
| 16 | Not Available | REC.TANK LID ASSEM | 93002063 | Not Available |
| 16 | Not Available | DUCT-RECOVERY-B-C | 93002026 | Not Available |
| 16 |  | PEDAL, HANDLE RELEASE H3030 Part Number: 93001046 for Hoover | 93001046 | $3.79Read more |
| 17 | Not Available | FLOAT-HINGED SIDE | 93001183 | Not Available |
| 17 | Not Available | DUCT - SUCTION | 93001167 | Not Available |
| 17 | No Image | SPRING, HANDLE RELEASE H3030 H3060 Part Number: 93001049 for Hoover | 93001049 | $1.02Read more |
| 18 | No Image | TANK, RECOVERY H2850 Part Number: 93002062 for Hoover | 93002062 | $30.09Read more |
| 18 | Not Available | CORD COVER - TANK HOUSING | 93001166 | Not Available |
| 18 | Not Available | SPRING TENSION-MODE INDICATOR | 93001999 | Not Available |
| 19 | Not Available | WIRING HARNESS | 93001141 | Not Available |
| 19 | No Image | SCREW, #6 X 24 3/8 Part Number: 93001735 for Hoover | 93001735 | $1.12Read more |
| 19 | Not Available | MODE INDICATOR W/PAD PRINT | 93001998 | Not Available |
| 20 | Not Available | SOL. TANK CAP ASSEM - H3030 | 93001144 | Not Available |
| 20 | Not Available | SEAL | 93001743 | Not Available |
| 20 | Not Available | SWITCH - MODE CONTROL - C | 93002004 | Not Available |
| 21 |  | ***USE H-300107037 TANK,:( SOLUTION H3030/3060 FLO Part Number: 93001147 for Hoover | 93001147 | $37.38Read more |
| 21 | Not Available | RECOVERY SEAL PLATE | 93001995 | Not Available |
| 21 | Not Available | MAIN BODY - C | 93001992 | Not Available |
| 22 | Not Available | VALVE STEM | 93001148 | Not Available |
| 22 | Not Available | RING - RECOVERY DUCT | 93001997 | Not Available |
| 22 | Not Available | CONTROL PEDAL | 93002010 | Not Available |
| 23 | Not Available | VALVE SEAL | 93001149 | Not Available |
| 23 | Not Available | CONNECTOR SUCTION TO HOSE | 93001987 | Not Available |
| 23 | Not Available | SPRING CONTROL PEDAL | 93002011 | Not Available |
| 24 | No Image | SPRING, VALVE FLOOR MATE H3030 Part Number: 93001150 for Hoover | 93001150 | $1.18Read more |
| 24 | Not Available | HOSE ASSEM - H3030 | 93001192 | Not Available |
| 24 | Not Available | FRONT WHEEL CARRIAGE ASSY | 93001979 | Not Available |
| 25 | Not Available | SPRING SOL TANK LATCH | 93001976 | Not Available |
| 25 | Not Available | TUBING-DIST(CUT/28" LEN) | 93001165 | Not Available |
| 25 | Not Available | LOCK RING | 59177088 | Not Available |
| 26 | Not Available | LATCH SOLUTION TANK | 93001975 | Not Available |
| 26 | Not Available | MOTOR COVER - REAR | 93001173 | Not Available |
| 26 | Not Available | REAR WHEEL ASSEMBLY-H3060 | 93001060 | Not Available |
| 27 | No Image | SCREW, #6 X 24 3/8 Part Number: 93001735 for Hoover | 93001735 | $1.12Read more |
| 27 | Not Available | MOTOR SEAL RETAINER | 93001186 | Not Available |
| 27 | Not Available | REAR WHEEL AXLE | 93001059 | Not Available |
| 28 | Not Available | MOTOR MOUNT | 93001185 | Not Available |
| 28 | Not Available | SCREW #6-10 3/4"L | 93001740 | Not Available |
| 29 | Not Available | SEAL - MOTOR END BEARING | 93001184 | Not Available |
| 29 | Not Available | AGITATOR MOTOR HOUSING - LOWER | 93002002 | Not Available |
| 30 | Not Available | MOTOR COVER CAP - H3030 | 93001200 | Not Available |
| 30 | Not Available | MOTOR AGITATOR DRIVE - C | 93002005 | Not Available |
| 31 | Not Available | MOTOR COVER VENT | 93001194 | Not Available |
| 31 | Not Available | AGITATOR DRIVE BELT - C | 93002000 | Not Available |
| 32 | Not Available | MOTOR COVER | 93001193 | Not Available |
| 32 | Not Available | AGITATOR MOTOR HOUSING - C | 93002001 | Not Available |
| 33 | Not Available | MOTOR ASSEMBLY | 93001189 | Not Available |
| 33 | Not Available | FRONT WHEEL SHAFT | 93001065 | Not Available |
| 34 | Not Available | SEAL - MOTOR FAN | 93001190 | Not Available |
| 34 | Not Available | FRONT WHEEL OVERMOLDED | 93001980 | Not Available |
| 35 | Not Available | WASHER - THRUST AGITATOR | 93002008 | Not Available |
| 36 | Not Available | AGITATOR ASSEMBLY LACED | 93001985 | Not Available |
| 37 | Not Available | THREAD GUARD | 93002007 | Not Available |
| 38 | Not Available | BOTTOM PLATE | 93002009 | Not Available |
| 39 | No Image | SCREW, MODE CONTROL Part Number: 93001733 for Hoover | 93001733 | $0.94Read more |
