Schematic and parts book for hoover F8100900 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | HANDLE ASSEMBLY COMPLETE | 302594001 | Not Available |
| 2 | Not Available | UPPER HANDLE ASSEMBLY | 302595001 | Not Available |
| 3 | Not Available | FRONT COVER - UPPER HANDLE | 302596002 | Not Available |
| 4 | Not Available | CIRCUIT BOARD - TRIGGER SWITCH | 280519001 | Not Available |
| 5 | Not Available | TRIGGER | 517404001 | Not Available |
| 6 | Not Available | TRIGGER STOP | 521076001 | Not Available |
| 7 | Not Available | REAR COVER - UPPER HANDLE | 517402001 | Not Available |
| 8 | Not Available | CORD WRAP | 517538001 | Not Available |
| 9 | Not Available | CARRY HANDLE | 517410001 | Not Available |
| 10 | Not Available | CONTROL PANEL ASSEMBLY | 302632002 | Not Available |
| 11 | Not Available | HARDWARE PACKAGE - UPPER HANDLE | 40201319 | Not Available |
| 12 | Not Available | TOOL DOOR ASSEMBLY | 42227189 | Not Available |
| 13 |  | Insert-Hoover F8100 Upper Handle For: hoover | 517403001 | $17.18Add to cart Special order: ships in 2 to 4 weeks |
| 14 | Not Available | SOLUTION TANK ASSEMBLY COMPLETE | 302664002 | Not Available |
| 15 | Not Available | CLEAN WATER TANK ASSEMBLY COMPLETE | 302668001 | Not Available |
| 16 | Not Available | TANK CAP ASSEMBLY | 302666001 | Not Available |
| 17 |  | Hose, :( Black W/Ends F8100-900 Part Number: 43434282 for Hoover | 43434282 | $48.84Read more |
| 18 | Not Available | RUBBER SEAL ADAPTOR - HOSE | 562125001 | Not Available |
| 19 |  | Hoover Shampooer Crevice Tool | 517550001 | $6.12Read more |
| 20 | Not Available | FURNITURE NOZZLE ASSEMBLY | 517438001 | Not Available |
| 21 |  | Hoover 302598001 Upholstery Tool, Air Driven Extactor | 302598001 | $50.89Read more |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | REAR COVER - LOWER HANDLE | 517443001 | Not Available |
| 2 | Not Available | POWER CORD ASSEMBLY | 730719002 | Not Available |
| 3 |  | Circuit Board Power Control - Hoover F8100 Steamer For: hoover | 280518001 | $71.08Add to cart Special order: ships in 2 to 4 weeks |
| 4 |  | Circuit Board-Hoover F8100 Platinum Steamer For: hoover | 280516001 | $59.67Add to cart Special order: ships in 2 to 4 weeks |
| 5 | Not Available | CHEMICAL PORT MANIFOLD ASSEMBLY | 302602001 | Not Available |
| 6 | Not Available | O-RING - CHEMICAL PORT MANIFOLD | 25156514 | Not Available |
| 7 | Not Available | MANIFOLD SUPPORT | 517444002 | Not Available |
| 8 | Not Available | FRONT COVER - LOWER HANDLE | 517442001 | Not Available |
| 9 | Not Available | HOSE HOLDER | 517454001 | Not Available |
| 10 |  | Strain Relief-Hoover For: hoover | 590220008 | $0.27Add to cart Special order: ships in 2 to 4 weeks |
| 11 | No Image | COVER, VALVE Part Number: 517448001 for Hoover | 517448001 | $2.16Add to cart Special order: ships in 2 to 4 weeks |
| 12 | Not Available | TEE - TUBING | 519523001 | Not Available |
| 13 |  | GASKET, TEE F8100-900 Part Number: 562121001 for Hoover | 562121001 | $0.25Read more |
| 14 | No Image | Tube - Id 4.0Mm For: hoover | 562109001 | $4.81Add to cart Special order: ships in 2 to 4 weeks |
| 15 | Not Available | GEAR PUMP | 302603001 | Not Available |
| 16 | Not Available | TUBE - ID 4.0MM PUMP FLOW METER | 562109005 | Not Available |
| 17 | Not Available | WATER TANK MANIFOLD ASSEMBLY | 302604002 | Not Available |
| 18 | Not Available | LOW FLOW METER WITH PCB HALL SENSOR | 302606001 | Not Available |
| 19 |  | Clamp-Hoover F6210 Agility Hose For: hoover | 25411015 | $1.96Read more |
| 20 | Not Available | HOSE CLAMP - ID .301 | 25411016 | Not Available |
| 21 | Not Available | TUBE - ID 6.35MM X 90MM DETERGENT | 562108004 | Not Available |
| 22 | Not Available | TUBE - ID 6.35MM X 49MM WATER TANK MANIFOLD | 562108003 | Not Available |
| 23 | Not Available | TUBE - ID 6.35MM X 73 MM FLOW METER VALVE | 562108008 | Not Available |
| 24 | Not Available | TUBE - ID 6.35MM X 220MM WATER MANIFOLD NOZZLE VALVE | 562108002 | Not Available |
| 25 | Not Available | TUBE - ID 4.0MM X 220MM FLOW METER HOSE | 562109002 | Not Available |
| 26 |  | Valve, :( Solution Gravity V2 Part Number: 25686057 for Hoover | 25686057 | $20.80Read more |
| 27 | Not Available | FUSE HARNESS | 290873033 | Not Available |
| 28 | Not Available | TOOL HOLDER / LOWER CORD WRAP | 517453001 | Not Available |
| 29 | Not Available | CLIP - CREVICE TOOL HOLDER ORDER 40201319 - HANDLE HARDWARE PACKAGE | 517455001 | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | DIRTY WATER TANK LID ASSEMBLY | 42272178 | Not Available |
| 2 | Not Available | DIRTY WATER TANK | 517585001 | Not Available |
| 3 | Not Available | DIRTY WATER TANK SCREEN - ORANGE | 43613036 | Not Available |
| 4 | Not Available | NOZZLE ASSEMBLY | 302631001 | Not Available |
| 5 | Not Available | GASKET - NOZZLE | 562128001 | Not Available |
| 6 | No Image | Trunnion Cover - Right For: hoover | 517531001 | $4.16Add to cart Special order: ships in 2 to 4 weeks |
| 7 |  | COVER, TRUNION LEFT Part Number: 517529001 for Hoover | 517529001 | $5.80Read more |
| 8 | Not Available | COVER - MOTOR AIR DUCT | 517498001 | Not Available |
| 9 |  | Motor Cover - Hoover F8100 - Platinum Steam Vac For: hoover | 517497001 | $14.00Add to cart Special order: ships in 2 to 4 weeks |
| 10 | Not Available | RUBBER SEAL - MOTOR COVER | 562120001 | Not Available |
| 11 |  | MOTOR MAIN F8100-900 | H741179001 | $126.45Add to cart |
| 12 |  | Seal - Rubber-Hoover F8100 Steam Vac For: hoover | 562117001 | $1.38Add to cart Special order: ships in 2 to 4 weeks |
| 13 | Not Available | RUBBER SEAL - MOTOR | 562118001 | Not Available |
| 14 | Not Available | RUBBER SEAL - MOTOR MOUNT | 562119001 | Not Available |
| 15 | Not Available | TEE - TUBING | 517500001 | Not Available |
| 16 |  | Hose Clamp-.250 Id For: hoover | 25411017 | $2.13Add to cart Special order: ships in 2 to 4 weeks |
| 17 | Not Available | HOSE CLAMP - ID .301 | 25411016 | Not Available |
| 18 | Not Available | FRONT SPRAY AND HEADLIGHT ASSEMBLY | 302611001 | Not Available |
| 18 |  | Wire Assembly-Hoover Headlight/Heat Light For: hoover | 290873022 | $6.24Add to cart Special order: ships in 2 to 4 weeks |
| 19 | Not Available | PCB - THERMISTOR | 280522001 | Not Available |
| 20 | Not Available | HANDLE RELEASE PEDAL | 517503001 | Not Available |
| 21 | Not Available | NOZZLE BASE | 517496001 | Not Available |
| 22 | Not Available | SOLENOID PUMP WITH WELDED GROUND | 303127001 | Not Available |
| 23 | | Valve, :( Solution Gravity V2 Part Number: 25686057 for Hoover | 25686057 | $20.80Read more |
| 24 | Not Available | WHEEL AND HUB CAP | 43244047 | Not Available |
| 25 | Not Available | SLEEVE BEARING - WHEEL | 641617001 | Not Available |
| 26 | Not Available | WHEEL MAGNET | 517534001 | Not Available |
| 27 | Not Available | REAR WHEEL AXLE | 632555001 | Not Available |
| 28 | Not Available | MICRO SWITCH | 760758001 | Not Available |
| 29 | Not Available | PCB HALL ASSEMBLY | 280521001 | Not Available |
| 30 | Not Available | GEAR BOX ASSEMBLY | 302610001 | Not Available |
| 31 | Not Available | COVER - GEAR BOX | 517499001 | Not Available |
| 32 |  | HOOD, NOZZLE Part Number: 517511001 for Hoover | 517511001 | $24.72Read more |
| 33 | Not Available | DISTRIBUTOR - WELDED | 302609001 | Not Available |
| 34 | Not Available | WIRE CHANNEL COVER | 517502001 | Not Available |
| 35 |  | Hoover Agitator / Brush Roll Belt Guard With Bristles | 302613001 | $3.09Read more |
| 36 |  | End Cap - W/Bristles - Left - Hoover F8100 Steam Vac For: hoover | 302617001 | $3.36Read more |
| 37 | Not Available | END CAP WITH BRISTLES - RIGHT | 302615001 | Not Available |
| 38 | Not Available | BRUSH ROLL ASSEMBLY | 302629001 | Not Available |
| 39 |  | Hoover Brush Block 6 Bristle Green for F8100 | 302619001 | $54.99Read more |
| 40 | Not Available | BELT | 562124001 | Not Available |
| 41 | Not Available | AGITATOR / BRUSH ROLL SHIELD | 521100001 | Not Available |
| 42 | | GASKET, TEE F8100-900 Part Number: 562121001 for Hoover | 562121001 | $0.25Read more |
| 43 | | Valve, :( Solution Gravity V2 Part Number: 25686057 for Hoover | 25686057 | $20.80Read more |
