Schematic and parts book for hoover F5824900 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | SOLUTION TANK HANDLE | 39457016 | Not Available |
| 2 | Not Available | SOLUTION TANK CAP ASSEM | 42272002 | Not Available |
| 3 |  | NO LONGER AVAILABLE Gasket, :( Circular Tank SteamVac/Uprights Part Number: 38784062 for Hoover | 38784062 | $1.73Read more |
| 4 |  | TANK, CLEAN SOLUTION F5815/6020/6023 Part Number: 42272134 for Hoover | 42272134 | $43.16Read more |
| 5 | Not Available | SPRING | 38312014 | Not Available |
| 6 | Not Available | WASHER-BRASS | 21312518 | Not Available |
| 7 | Not Available | VALVE SEAL | 38784061 | Not Available |
| 8 | Not Available | VALVE STEM | 38717009 | Not Available |
| 9 | Not Available | RECOVERY TANK LID | 42272111 | Not Available |
| 10 | Not Available | HANDLE HARDWARE ASSEM | 40201149 | Not Available |
| 11 | Not Available | DUCT | 38661003 | Not Available |
| 12 | Not Available | RECOVERY TANK-SERVICE | 38777081 | Not Available |
| 13 | Not Available | HANDLE COVER | 37276001 | Not Available |
| 14 | Not Available | SCREW | 21447020 | Not Available |
| 16 | Not Available | SEAL (NOZ. FRT. PLAT | 38781037 | Not Available |
| 17 | Not Available | DOOR ASSEM. - F5 827 | 37257140 | Not Available |
| 17 | Not Available | DOOR-F5817 | 37257104 | Not Available |
| 17 | Not Available | DOOR ASSEM - F5825 | 37257103 | Not Available |
| 17 | Not Available | DOOR ASSEM - F5815 | 37257102 | Not Available |
| 18 | Not Available | SEAL | 38783019 | Not Available |
| 19 | Not Available | SPEED NUT | 21362006 | Not Available |
| 20 |  | Spring Access Door Hoover F5815/25 For: hoover | 38351017 | $0.91Read more |
| 21 | Not Available | HOOD ASSEM - F5827 | 37271033 | Not Available |
| 21 | Not Available | HOOD - F5825 | 37271031 | Not Available |
| 21 | Not Available | HOOD - F5815 | 37271030 | Not Available |
| 22 | Not Available | SCREW-SELF-TAPPING | 21447228 | Not Available |
| 23 | Not Available | BRUSH BACK ASSEM. | 48443005 | Not Available |
| 24 | Not Available | MAIN BODY - F5815/25 | 37272081 | Not Available |
| 24 | Not Available | MAIN BODY | 37272095 | Not Available |
| 27 | Not Available | REAR WHEEL | 38522076 | Not Available |
| 28 | Not Available | REAR AXLE | 32434007 | Not Available |
| 29 | Not Available | ELBOW DUCT | 38664001 | Not Available |
| 29 | Not Available | 1 | 12002693 | Not Available |
| 29 | Not Available | 1 | 37271031 | Not Available |
| 30 | Not Available | Key Part Number | 36131085 | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | 37271034 | 92 | Not Available |
| 1 | Not Available | 52313110 | 92 | Not Available |
| 1 | Not Available | 48439002 | 92 | Not Available |
| 1 | Not Available | 40302016 | 99 | Not Available |
| 1 | Not Available | 0M100168 | 99 | Not Available |
| 1 | Not Available | 57337216 | 99 | Not Available |
| 1 | Not Available | 38784070 | 99 | Not Available |
| 1 | Not Available | 36433092 | 99 | Not Available |
| 1 | Not Available | 43412003 | 99 | Not Available |
| 1 | Not Available | 38719027 | 99 | Not Available |
| 1 | Not Available | 48417003 | 99 | Not Available |
| 1 | Not Available | 40309044 | 99 | Not Available |
| 1 | Not Available | 43611041 | 99 | Not Available |
| 1 | Not Available | 43538001 | 99 | Not Available |
| 1 | Not Available | 40201142 | 99 | Not Available |
| 1 | Not Available | 46583066 | 900 | Not Available |
| 1 | Not Available | 43576212 | 900 | Not Available |
| 1 | Not Available | 43576203 | 900 | Not Available |
| 1 | Not Available | 58346006 | 996 | Not Available |
| 1 | Not Available | 37257277 | 996 | Not Available |
| 1 | Not Available | 37271071 | 996 | Not Available |
| 1 | Not Available | 58461019 | 996 | Not Available |
| 1 | Not Available | 58332025 | 996 | Not Available |
| 1 | Not Available | 58332024 | 996 | Not Available |
| 1 | Not Available | 58315006 | 996 | Not Available |
| 1 | Not Available | 39442039 | 996 | Not Available |
| 1 | Not Available | 56518091 | 996 | Not Available |
| 1 | Not Available | 48663181 | 996 | Not Available |
| 1 | Not Available | 48447002 | 996 | Not Available |
| 1 | Not Available | 40309007 | 996 | Not Available |
| 1 | Not Available | 41426030 | 996 | Not Available |
| 1 | Not Available | 57333016 | 996 | Not Available |
