Schematic and parts book for Hoover bh52100pc, BH52100PC Cordless 2-in-1 Stick & Handheld BH52100PC Cordless 2-in-1 Stick & Handheld. Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides replacement parts and accessories for vacuum cleaners, sewing machines, and other small appliances for repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | HANDLE ASSEMBLY | 440007093 | Not Available |
| 2 | Not Available | NLA SCREW,HANDLE | 440007094 | Not Available |
| 3 | Not Available | WBD TOOL HOLDER | 440007095 | Not Available |
| 4 | Not Available | Main Body with Nozzle & Lower Hose Assembly | 440007096 | Not Available |
| 5 | Not Available | HAND VAC ASSY | 440007098 | Not Available |
| 6 | Not Available | FILTER ASSY | 440007099 | Not Available |
| 7 | Not Available | SEPARATOR ASSEMBLY | 440007100 | Not Available |
| 8 | Not Available | NLA DIRT CUP ASSY | 440007101 | Not Available |
| 9 | Not Available | WBD BOTTOM PLAT ASSY, NOZZLE GUARD | 440007102 | Not Available |
| 10 | Not Available | BRUSH ROLL ASSY | 440007103 | Not Available |
| 11 | Not Available | BELT | 440005954 | Not Available |
| 12 | Not Available | CREVICE TOOL | 440007104 | Not Available |
| 13 | Not Available | WBD R/A BH03100PC BATTERY-20 VOLT LI-ON STND RUN TIME \ BH03100 | 440005966 | Not Available |
| 14 | Not Available | CHARGER ASSEMBLY | 440007105 | Not Available |
