Schematic and parts book for Evolution 6700 Motor. Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Helpful Repair Videos
| # | Part image | Description | SKU | Price |
| 1 | No Image | MOTOR ASSY, EVOLUTION 6707Z Part Number: V700998300 for Evolution | V700998300 | $459.04Read more |
| 2 | Not Available | Carbon Brush (117776-01) | V700992300 | Not Available |
| 3 | Not Available | Motor Mount (Rear) | V700233301 | Not Available |
| 4 | Not Available | Motor Mount (Front) | V700232301 | Not Available |
| 5 | Not Available | Motor Pivot Sleeve | V700234301 | Not Available |
| 6 | Not Available | Noise Suppressor | V700231300 | Not Available |
| 7 | Not Available | Set Screw (M4*15) | VM400191 | Not Available |
| 8 | Not Available | PCB and Cord Complete | V700964400 | Not Available |
| 9 | Not Available | Cord (16AWG Black) | V700966300 | Not Available |
| 10 |  | Switch, Reset Evolution Part Number: V700944300 for Evolution | V700944300 | $20.02Read more |
| 11 | Not Available | Washer (4.2*14*1) | VWA00194 | Not Available |
| 12 | No Image | SCREW, BOTTOM PLATE LATCH ALL EVOLUTION UPRIGHTS Part Number: VM300295 for Evolution | VM300295 | $0.84Read more |
| 13 | Not Available | Wire Connector (HW-C4) | V700939300 | Not Available |
| 14 | Not Available | Cord Clip (TSL-100-M) | V700938300 | Not Available |
| 15 | Not Available | Check Bag Cord (16AWG Black) | V700956300 | Not Available |
| 16 | Not Available | Motor Cord (18AWG White) | V700963300 | Not Available |
| 17 | Not Available | Wire Cord (SPT-2 18AWG White) | V700968300 | Not Available |
| 18 | Not Available | Bulb Socket Support Frame | V700242305 | Not Available |
| 19 | Not Available | Set Screw (M4*15) | VM400191 | Not Available |
| 20 | Not Available | Bulb Socket (75W 125V) | V700949500 | Not Available |
| 21 | Not Available | Light Bulb (15W 120-130V) | V700947300 | Not Available |
| 22 | Not Available | Spring Washer (3.1*5.9*0.7) | VWA00691 | Not Available |
| 23 | Not Available | Set Screw (M3*17) | VM300694 | Not Available |
