Schematic and parts book for Eureka EL4072A . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| XX | Not Available | FOAM FILTER | G4290320003 | Not Available |
| 1 | Not Available | INLET FILTER | A4293950004R | Not Available |
| 2 | Not Available | PROTECTOR | A0007530007R | Not Available |
| 3 | Not Available | FILTER PKG-EUREKA | 68944 | Not Available |
| 4 | Not Available | SEALING | X4292620001R | Not Available |
| 5 | Not Available | DUST CUP | B4290340611R | Not Available |
| 6 | Not Available | MIDDLE | B4291050606R | Not Available |
| 7 | Not Available | EXHAUST | Q429B862B25R | Not Available |
| 8 | Not Available | EXHAUST | Q429B850B20R | Not Available |
| 9 | Not Available | BODY ASSEMBLY | B4290750604R | Not Available |
| 10 | Not Available | SMALL WHEEL | A4290030019R | Not Available |
| 11 | Not Available | SEALING | X4291140001R | Not Available |
| 12 | Not Available | INLET TUBE | Q4294720233R | Not Available |
| 13 | Not Available | SEALING | Q429Z340H08R | Not Available |
| 14 | Not Available | CW ASSEMBLY | A4290050021R | Not Available |
| 15 | Not Available | MOTOR | 63160-4 | Not Available |
| 16 | Not Available | SEALING | X0000341164R | Not Available |
| 17 | Not Available | MOTOR | Q429H08P233 | Not Available |
| 18 | Not Available | REAR COVER | B4290780604R | Not Available |
| 19 | No Image | SWITCH - EL4071A Part Number: D3024000006R for Eureka | D3024000006R | $8.56Read more |
| 20 | Not Available | SPRING | 63157-10 | Not Available |
| 21 | Not Available | SWITCH | Q429513A233 | Not Available |
| 22 | Not Available | CORDWINDER | Q429521A233 | Not Available |
| 23 | Not Available | REAR COVER | B4293140610R | Not Available |
| 24 | Not Available | AIR CHANNEL | Q429H46P233 | Not Available |
| 25 | Not Available | SEALING | X4290750001R | Not Available |
| 26 | Not Available | MOTOR | X0000390150R | Not Available |
| 27 | Not Available | PCBASSEMBLY | D2429012001R | Not Available |
| 28 | Not Available | MOTOR | Q429291P233 | Not Available |
| 29 | Not Available | SEALING | X4290440002R | Not Available |
| 30 | Not Available | TCO | D4042302017R | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | HAND TURBO - KC#54 | 86839 | Not Available |
| 2 | Not Available | CREVICE/KCL | 86834 | Not Available |
| 3 | Not Available | NOZZLE COMBICARPET GNGRY | 1099100-56 | Not Available |
| 4 | Not Available | SWIVEL HOSE ASSY - CARTON | 61054-16 | Not Available |
| 5 | Not Available | EXTENSION WAND Comes with telescopic wand | B4290350604R | Not Available |
| 6 | Not Available | EXTENSION WAND | B4290350604R | Not Available |
| 7 | No Image | NOZZLE, TURBO EL4071A CANISTER Part Number: B4290280601R for Eureka | B4290280601R | $36.78Read more |
| 8 | Not Available | SPEEDY CLEAN NOZZLE | F1100000130R | Not Available |
| 9 | Not Available | FLOOR BRUSH | 86835 | Not Available |
