Schematic and parts book for Eureka EL4071A . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| XX | Not Available | FOAM FILTER | G4290320003 | Not Available |
| 1 | Not Available | INLET FILTER ASSEMBLY | A4293950004R | Not Available |
| 2 | Not Available | PROTECTOR ASSEMBLY | A0007530007R | Not Available |
| 3 | Not Available | FLTR ASSY-920 Canster EUR | 81908 | Not Available |
| 4 | Not Available | SEALING - EXHAUST COVER | X4292620001R | Not Available |
| 5 | No Image | Dirt Cup, Orange/Clear EL4071A Canister Part Number: B4290340610R for Eureka | B4290340610R | $75.83Read more |
| 6 | Not Available | MIDDLE FRAME ASSEMBLY | B4291050606R | Not Available |
| 7 | Not Available | EXHAUST FRAME CATCH | Q429B860686 | Not Available |
| 8 | Not Available | EXHAUST HEPA COVER | Q429B850B20R | Not Available |
| 9 | Not Available | BODY ASSEMBLY | B4290750604R | Not Available |
| 10 | Not Available | SMALL WHEEL ASSEMBLY | A4290030019R | Not Available |
| 11 | Not Available | SEALING - SUCTION | X4291140001R | Not Available |
| 12 | Not Available | INLET TUBE | Q4294720233R | Not Available |
| 13 | Not Available | SEALING - INLET TUBE | Q429Z340H08R | Not Available |
| 14 | Not Available | CW ASSEMBLY | A4290050021R | Not Available |
| 15 | Not Available | MOTOR ASSY - PACKAGED | 63160-4 | Not Available |
| 16 | Not Available | SEALING - MOTOR (NLA) | X0000341164R | Not Available |
| 17 | Not Available | MOTOR - FRONT COVER (NLA) | Q429H08P233 | Not Available |
| 18 | Not Available | REAR COVER ASSEMBLY | B4290780604R | Not Available |
| 19 | No Image | SWITCH - EL4071A Part Number: D3024000006R for Eureka | D3024000006R | $8.56Read more |
| 20 | Not Available | SPRING PACKAGE | 63157-10 | Not Available |
| 21 | Not Available | SWITCH BUTTON | Q429513A233 | Not Available |
| 22 | Not Available | CORDWINDER BUTTON | Q429521A233 | Not Available |
| 23 | Not Available | REAR COVER PLATE ASSEMBLY | B4293140610R | Not Available |
| 24 | Not Available | AIR CHANNEL CONNECTOR | Q429H46P233 | Not Available |
| 25 | Not Available | SEALING - AIR CHANNEL | X4290750001R | Not Available |
| 26 | Not Available | MOTOR WEDGE | X0000390150R | Not Available |
| 27 | Not Available | PCB ASSEMBLY (NLA) | D2429012001R | Not Available |
| 28 | Not Available | MOTOR HOUSING (NLA) | Q429291P233 | Not Available |
| 29 | Not Available | SEALING - MOTOR HOUSING (NLA) | X4290440002R | Not Available |
| 30 | Not Available | TCO | D4042302017R | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | HAND TURBO - KC#54 | B4290280602R | Not Available |
| 2 | Not Available | CREVICE/KCL | 86834 | Not Available |
| 3 | Not Available | NOZZLE COMBICARPET GNGRY | 1099100-56 | Not Available |
| 4 | Not Available | SWIVEL HOSE ASSY - CARTON | 61054-16 | Not Available |
| 5 | Not Available | TOOL CADDY | S5303720233 | Not Available |
| 6 | Not Available | METAL TELESCOPIC WAND | B4290350603R | Not Available |
| 7 | Not Available | R TURBO NOZZLE | B4290280601 | Not Available |
| 8 | Not Available | Low Profile Nozzle | F1100000130R | Not Available |
| 9 | Not Available | FLOOR BRUSH | 86835 | Not Available |
