Schematic and parts book for Eureka EL4050A . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | FILTER GRILL & GRAPHICS A | 2193231-02 | Not Available |
| 2 | Not Available | EXHAUST FOAM FILTER | 1180215-01 | Not Available |
| 3 | Not Available | FILTER - HEPA H12 NONWASH | 1130939-01 | Not Available |
| 4 | Not Available | GASKET - FILTER | 2192645-02 | Not Available |
| 5 | Not Available | PEDAL CORD REEL | 2193284-65 | Not Available |
| 6 | Not Available | SPRING | 2190496-01 | Not Available |
| 7 | Not Available | POWER REGULATOR | 1180223-75 | Not Available |
| 8 | Not Available | SPRING - ARM | 2190488-01 | Not Available |
| 9 | Not Available | COVER - REAR | 2193617-02 | Not Available |
| 10 | Not Available | PC CONTROL BOARD | 1180154-11 | Not Available |
| 11 | Not Available | BRAKE ARM COMPLETE | 2192177-01 | Not Available |
| 12 | Not Available | CORD REEL ASSEMBLY | 2198345-35 | Not Available |
| 13 | Not Available | ADAPTER | 1180235-02 | Not Available |
| 14 | Not Available | SUSPENSION - MOTOR | 1096540-01 | Not Available |
| 15 | Not Available | MOTOR ASSY - PACKAGED | 63160-3 | Not Available |
| 16 | Not Available | RING - SUSPENSION | 1180233-01 | Not Available |
| 17 | Not Available | PRE MOTOR FILTER | 1180217-01 | Not Available |
| 18 | Not Available | WHEEL - REAR | 1130506-04 | Not Available |
| 19 | Not Available | FRONT WHEEL & HOLDER ASSY | 2190118-10 | Not Available |
| 20 | Not Available | BOTTOM ASSEMBLY | 2193717-02 | Not Available |
| 21 | Not Available | COVER - FRONT | 1180211-08 | Not Available |
| 22 | Not Available | DUST CUP HOLDER | 2193216-03 | Not Available |
| 23 | Not Available | GASKET - CYCLONE | 1180244-02 | Not Available |
| 24 | No Image | LATCH, BAG COVER EL4050 6510 Part Number: 2192212-02 for Eureka | 219221202 | $12.45Read more |
| 25 |  | Latch Spring - Electrolux 6500 For: hizero | 118024301 | $7.18Read more |
| 26 | Not Available | CYCLONE & GRAPHICS ASSEMB | 2192182-48 | Not Available |
| 27 | Not Available | CYCLONE ASSEMBLY | 2193080-11 | Not Available |
| 28 | Not Available | CONICAL CYCLONE GRILL | 1128556-01 | Not Available |
| 29 | Not Available | DUST CUP COVER ASSEMBLY | 2193079-11 | Not Available |
| 30 | Not Available | SEAL - DUST CUP LID | 1180234-01 | Not Available |
| 31 | Not Available | DUST CUP COVER LATCH SPRI | 1180239-01 | Not Available |
| 32 | Not Available | LATCH - DUST CUP | 1180229-12 | Not Available |
| 33 | Not Available | HANDLE - DUST CUP | 1180227-66 | Not Available |
| 34 | Not Available | FILTER - HEPA CYCLONE | 2193416-01 | Not Available |
| 35 | Not Available | DUST CUP FILTER COVER | 1180224-01 | Not Available |
| 35 | Not Available | -01 SPRING | 1180241 | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | BELT - COGGED | 75614 | Not Available |
| 2 | Not Available | WASHER PACKAGE | 63153 | Not Available |
| 3 | Not Available | LIGHT BULB | 61682 | Not Available |
| 4 | Not Available | LIGHT SOCKET | 61727 | Not Available |
| 5 | Not Available | MOTOR ASSEMBLY - CARTONED | 61740-1 | Not Available |
| 6 | Not Available | SCREW PACKAGE | 63155 | Not Available |
| 7 | Not Available | WIRE SPLICE | 58313 | Not Available |
| 8 | Not Available | WAND RELEASE ASSEMBLY | 75810A-3 | Not Available |
| 9 | Not Available | HOOD ASSEMBLY - PACKAGED | 61730-5 | Not Available |
| 10 | Not Available | PEDAL ASSEMBLY | 61728-2 | Not Available |
| 11 | Not Available | SCREW PACKAGE | 63155 | Not Available |
| 12 | Not Available | CLAMP CABLE | 58430 | Not Available |
| 13 | Not Available | CIRCUIT PROTECTOR | 74594 | Not Available |
| 14 | Not Available | C-CLAMP PACKAGE | 63154 | Not Available |
| 15 | Not Available | T-JOINT ASSEMBLY | 39973-4 | Not Available |
| 16 | Not Available | BRUSHROLL ASSY - CARTONED | 61699-1 | Not Available |
| 17 | Not Available | SOLE PLATE ASSEMBLY | 61753-2 | Not Available |
| 18 | Not Available | INSERT - FRONT WHEEL | 76136 | Not Available |
| 19 | Not Available | FRONT WHEEL | 61750 | Not Available |
| 20 | Not Available | WASHER PACKAGE | 63153 | Not Available |
| 21 | Not Available | E-RING PACKAGE | 61752 | Not Available |
| 22 | Not Available | FRONT AXLE | 61749 | Not Available |
| 23 | Not Available | CAM BEARING | 61747 | Not Available |
| 24 | Not Available | BASE ASSEMBLY - PACKAGED | 61746-5 | Not Available |
| 25 | Not Available | SPRING | 61748 | Not Available |
| 26 | Not Available | AIR DUCT COVER ASSEMBLY | 61734 | Not Available |
| 27 | Not Available | FOOT PEDAL | 61743-453N | Not Available |
| 28 | Not Available | POWERHEAD ASSY (BETA-SUMO | 75922-6 | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | HOSE ASSEMBLY - CARTONED | 16103-4 | Not Available |
| 2 | Not Available | FLOOR & WALL BRUSH ASSEMB | 75973-1 | Not Available |
| 3 | Not Available | NOZZLE - FURNITURE | 75985 | Not Available |
| 4 | Not Available | NOZZLE - CREVICE | 76250 | Not Available |
| 5 | Not Available | NOZZLE - DUSTING BRUSH | 75986 | Not Available |
| 6 | Not Available | TLSCPC WAND ASSY (SUMO | 75979B-1 | Not Available |
| 6 | Not Available | CADDY - TOOL Not Pictured | 76161-366N | Not Available |
| 6 | Not Available | OWNERS GUIDE | 81782 | Not Available |
