Schematic and parts book for Eureka CV1801A . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | WALL BRACKET RH | 01707-2 | Not Available |
| 2 | Not Available | HOOD | 01721-12 | Not Available |
| 3 | Not Available | BODY ASSEMBLY | 01889-4 | Not Available |
| 4 | No Image | Intake Gasket | 14554 | $0.00Read more |
| 5 | Not Available | FILTER ASSEMBLY - LARGE | 26760-2 | Not Available |
| 6 | Not Available | GASKET - MOTOR MOUNTING | 37802 | Not Available |
| 7 | Not Available | RELAY - PACKAGED | 37808 | Not Available |
| 8 | Not Available | TRANSFORMER - CARTONED | 37821 | Not Available |
| 9 | Not Available | LABEL-LOCK/UNLOCK | 37913-3 | Not Available |
| 10 | Not Available | TIE - CABLE (PURCHASED) | 46713-1 | Not Available |
| 11 | Not Available | SCREW PACKAGE | 53238-8 | Not Available |
| 12 | Not Available | PACKAGE - PAPER BAG | 54585 | Not Available |
| 13 | Not Available | NAMEPLATE | 54611 | Not Available |
| 14 | Not Available | GASKET | 54613 | Not Available |
| 15 | Not Available | LABEL - HOOD | 54616 | Not Available |
| 16 | Not Available | SCREW - GROUND | 54618 | Not Available |
| 17 | Not Available | BOLT | 54621 | Not Available |
| 18 | Not Available | CORD ASSEMBLY | 54622 | Not Available |
| 19 | Not Available | SMALL DIAMETER GASKET SET | 54625 | Not Available |
| 20 | Not Available | WASHER | 54626 | Not Available |
| 21 | Not Available | LABEL - WARNING | 54630 | Not Available |
| 22 | Not Available | PACKAGE - HARDWARE | 54631 | Not Available |
| 23 | Not Available | EXHAUST EXTENSION 3 1/2" | 54634 | Not Available |
| 24 | Not Available | BAG ADAPTOR ASSEMBLY | 54700 | Not Available |
| 25 | Not Available | CONTROL MODULE | 54702 | Not Available |
| 26 | Not Available | ELBOW | 56838 | Not Available |
| 27 | Not Available | DEGREE "T-Y" | 5683945 | Not Available |
| 28 | Not Available | DECAL - ARROW | 57064-2 | Not Available |
| 29 | Not Available | UTILITY VALVE WHITE AUTOM | 57508-2 | Not Available |
| 30 | No Image | DIRT CUP, CENTRAL VAC CV1801 Part Number: 60135-1 for Eureka | 601351 | $69.54Read more |
| 31 | Not Available | SCREW PACKAGE | EW312-8-8ZP | Not Available |
| 32 | Not Available | WASHER - EXTERNAL TOOTH L | EW85-416Z | Not Available |
| 33 | Not Available | MOTOR ASSY - CTND | 54586 | Not Available |
