Schematic and parts book for Eureka C6446AT . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | HANDLE ASSEMBLY | 02119-1 | Not Available |
| 2 | Not Available | LATCH - BAG COVER | 27514 | Not Available |
| 3 | Not Available | CLIP - HOSE | 27515-1 | Not Available |
| 4 | Not Available | COMMERCIAL CORD ASSEMBLY | 27521-1 | Not Available |
| 5 | Not Available | BAG INDICATOR ASSEMBLY | 37761-2 | Not Available |
| 6 | Not Available | SWITCH - ROCKER | 38348-2 | Not Available |
| 7 | Not Available | SCREW PACKAGE | 53238-1 | Not Available |
| 8 |  | SCREW, 10PK Part Number: 53238-37 for Eureka | 5323837 | $0.33Read more |
| 9 | Not Available | CLOTH BAG PACKAGE - STYLE | 54686 | Not Available |
| 10 | No Image | SPRING, BAG DOOR LATCH EXCALIBUR 5 PK Part Number: 54711 for Eureka | 54711 | $3.00Read more |
| 11 | Not Available | CLIP - BAG INDICATOR | 56750 | Not Available |
| 12 | Not Available | PAPER BAG PKG ASSY (STYLE | 58183 | Not Available |
| 13 | Not Available | BUSHING - STRAIN RELIEF | 58393 | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | COVER - DIRT CHUTE | 02016-1 | Not Available |
| 2 | Not Available | HANDLE - CARRYING | 14909-1 | Not Available |
| 3 | No Image | GASKET, ACCESS DOOR EXCALIBUR UPRIGHTS Part Number: 14966 for Eureka | 14966 | $1.27Read more |
| 4 | Not Available | ACCESS DOOR ASSY | 14967-1 | Not Available |
| 5 | No Image | DIVERTER ARM, EXCALIBER Part Number: 27345 for Eureka | 27345 | $3.35Read more |
| 6 |  | FILTER, SECONDARY UPRT EXCALIBUR 6400 SERIES Part Number: 27384 for Eureka | 27384 | $3.60Read more |
| 7 | Not Available | FRAME - FILTER | 27385 | Not Available |
| 8 | No Image | HANDLE RELEASE PEDAL, EXCALIBUR Part Number: 27405 for Eureka | 27405 | $7.48Read more |
| 9 |  | MICRO SWITCH, INTERNAL EXCALIBUR Part Number: 27410 for Eureka | 27410 | $7.90Read more |
| 10 | Not Available | REAR HOUSING ASSEMBLY | 27414-1 | Not Available |
| 11 | Not Available | GASKET - MOTOR FAN | 27463 | Not Available |
| 12 | Not Available | FILTER - FINAL | 27536 | Not Available |
| 13 | Not Available | DOOR - CONVERTER VALVE | 27666 | Not Available |
| 14 | Not Available | CLAMP - MOTOR | 38243-1 | Not Available |
| 15 | Not Available | SHIELD - MOTOR | 38410 | Not Available |
| 16 | Not Available | WIRE SPLICE | 53214-2 | Not Available |
| 17 | Not Available | SCREW PACKAGE | 53238-28 | Not Available |
| 18 | Not Available | SCREW PACKAGE | 53238-32 | Not Available |
| 19 | Not Available | SCREW PACKAGE | 53238-33 | Not Available |
| 20 | Not Available | SCREW PACKAGE | 53238-34 | Not Available |
| 21 | Not Available | SCREW PACKAGE | 53238-35 | Not Available |
| 22 | Not Available | SCREW PACKAGE | 53238-4 | Not Available |
| 23 | Not Available | SCREW PACKAGE | 54669 | Not Available |
| 24 | Not Available | PACKAGE - SPRING | 54710 | Not Available |
| 25 | Not Available | MOTOR ASSEMBLY - PKGD | 54713 | Not Available |
| 26 | No Image | GASKET, MIGHTY MITE Part Number: 55463 for Eureka | 55463 | $5.09Read more |
| 27 | Not Available | MOTOR COVER KIT - COMM | 58325-1 | Not Available |
| 28 | Not Available | COMM REAR HOUSING REPLMT | 60141 | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | PLATE - SOLE | 02017-1 | Not Available |
| 2 | Not Available | WHEEL - REAR | 26270-3 | Not Available |
| 3 | No Image | HANDLE RELEASE PEDAL, EXCALIBUR Part Number: 27405 for Eureka | 27405 | $7.48Read more |
| 4 | Not Available | ADJUSTMENT COVER & GRPHCS | 27483-4 | Not Available |
| 5 | Not Available | LOWER CORD ASSEMBLY | 27520-1 | Not Available |
| 6 |  | COVER, BRUSHROLL END CAP SC6484 COMMERCIAL UPRIGHT Part Number: 27530 for Eureka | 27530 | $0.99Read more |
| 7 |  | Wheel, Blk Front C2000/6400/1400 & Most Sanitaires Part Number: 35859A1 for Eureka | 35859A1 | $3.24Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 8 | No Image | WHEEL AXLE, DREAM MACHINE UPRIGHT EXTRACTOR 2450A Part Number: 38392 for Eureka | 38392 | $6.66Read more |
| 9 | Not Available | CAP - FOOT PEDAL | 38407 | Not Available |
| 10 | Not Available | AXLE - FRONT | 38457 | Not Available |
| 11 | Not Available | TIE - CABLE (PURCHASED) | 46713 | Not Available |
| 12 | Not Available | TIE - CABLE (PURCHASED) | 46713-2 | Not Available |
| 13 |  | Spring, Handle Release Bravo Models Ea Part Number: 530762 for Eureka | 530762 | $7.04Add to cart |
| 14 |  | AXLE CLAMP - PACKAGED | 53201 | $18.99Add to cart |
| 15 | Not Available | WIRE SPLICE | 53214-2 | Not Available |
| 16 |  | SCREW, REAR AXLE QUICK KLEEN EUREKA | 5323811 | $10.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 17 | Not Available | SCREW PACKAGE | 53238-4 | Not Available |
| 18 | Not Available | MOTOR ASSEMBLY - PACKAGED | 54343-3 | Not Available |
| 19 | Not Available | BASE REPLACEMENT KIT | 54706-2 | Not Available |
| 20 | Not Available | PACKAGE - PUSH ON NUT | 54707 | Not Available |
| 21 | Not Available | PACKAGE - SPRING | 54708 | Not Available |
| 22 | Not Available | ROLL ASSEMBLY REPLACEMENT | 54712-1 | Not Available |
| 23 | Not Available | CASTER REPAIR KIT LARGE | 54790 | Not Available |
| 24 | Not Available | SCREW - HEIGHT ADJUSTMENT | 58244 | Not Available |
| 25 | Not Available | CLAMP CABLE | 58295 | Not Available |
| 26 | Not Available | PIN - FOOT PEDAL | 58298 | Not Available |
| 27 | Not Available | COVER - PULLEY | 58323-1 | Not Available |
| 28 | Not Available | LEVER - ADJUSTMENT | 58327-1 | Not Available |
| 29 | Not Available | SHIELD - WIRE | 58421 | Not Available |
| 30 | Not Available | BELT - DRIVE (STYLE RD) | 30563A | Not Available |
| # | Part image | Description | SKU | Price |
| 1 |  | Wand, 19" Blk Plstc Ext 1-Pc Upright/Canister Part Number: 140703 for Eureka | 140703 | $10.96Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 2 | Not Available | WAND ASSEMBLY | 14990-1 | Not Available |
| 3 | Not Available | TOOL - CREVICE | 54355-3 | Not Available |
| 4 | Not Available | DUSTING BRUSH - PACKAGED | 54505-1 | Not Available |
| 5 | Not Available | UPHOLSTERY NOZZLE ASSEMBL | 54506-1 | Not Available |
| 6 | Not Available | HOSE ASSY - CRTND | 54691-1 | Not Available |
| 7 | Not Available | HOSE ASSY - CRTND | 54692-1 | Not Available |
| 8 | Not Available | PACKAGE - HARDWARE | 58068 | Not Available |
