Schematic and parts book for Eureka 5902AVZ . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | HHaannddllee -- NNoo LLoonnggeerr | 74074-2 | Not Available |
| 5 |  | Wire Nuts, 5Pk Part Number: 60192-1 for Eureka | 601921 | $5.38Add to cart Special order: ships in 2 to 4 weeks |
| 7 | Not Available | TIE - CABLE (PURCHASED) | 46713-3 | Not Available |
| 8 |  | Tool Pack, Lower 5800 Series Part Number: 71455119N for Eureka | 71455119N | $10.82Add to cart Special order: ships in 2 to 4 weeks |
| 9 | Not Available | SCREW PACKAGE | 53238-27 | Not Available |
| 11 | Not Available | CORD - LOW LEAD | 39584-8 | Not Available |
| 12 | Not Available | HEPA FILTER PKG | 61830 | Not Available |
| # | Part image | Description | SKU | Price |
| 2 | Not Available | FOAM FILTER | 74038 | Not Available |
| 3 | Not Available | FILTER ASSEMBLY | 73494 | Not Available |
| 9 | Not Available | SOCKET & TERMINAL ASSY | 70701-2 | Not Available |
| 11 | Not Available | MOTOR ASSEMBLY - CTND | 62075-2 | Not Available |
| 12 | Not Available | TIE - CABLE (PURCHASED) | 46713-3 | Not Available |
| 13 | Not Available | BUSHING - MOTOR | 74112-119N | Not Available |
| 14 | Not Available | GASKET - MOTOR HUB | 74664-1 | Not Available |
| 15 | No Image | CLIP, THERMOSTAT 2903AE Part Number: 72443 for Eureka | 72443 | $4.55Read more |
| 16 | Not Available | SCREW PACKAGE Pkg of | 61803-3 | Not Available |
| 17 | | Wire Nuts, 5Pk Part Number: 60192-1 for Eureka | 601921 | $5.38Add to cart Special order: ships in 2 to 4 weeks |
| 19 | Not Available | LENS - HEADLAMP | 74025-313N | Not Available |
| 20 | Not Available | LAMP - HEADLIGHT | 57940-3 | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | HOSE ASSY - CTND Includes items 2 & | 61865-6 | Not Available |
| 3 | No Image | Solenoid,Extractor,1/8 Orifice | 71492A | $971.99Add to cart Special order: ships in 2 to 4 weeks |
| 4 | Not Available | WAND - CREVICE | 71956A-355N | Not Available |
| 5 | Not Available | WAND - OUTER | 71973-119N | Not Available |
| 6 |  | Coupling, Hose 2900/3200/5800 Series Upright Part Number: 70559A119N for Eureka | 70559A119N | $10.82Add to cart Special order: ships in 2 to 4 weeks |
| 7 |  | Dust Brush-Eureka - 7606 Combo
Sc5845 For: eureka,sanitaire | 609902 | $11.94Add to cart Special order: ships in 2 to 4 weeks |
| 8 | Not Available | TURBO NOZZLE ASSY (MODEL | 28612A-1 | Not Available |
| 9 | Not Available | PACKAGE - HARDWARE | 72892 | Not Available |
| 11 | Not Available | ELECTROSTATIC DUSTER ASSE Includes item | 72293-4 | Not Available |
| 12 | Not Available | DUSTER ASSEMBLY | 73530 | Not Available |
| 13 | Not Available | TURBO CLIP & GRAPHICS ASS | 74084-2 | Not Available |
| 71 | Not Available | ADAPTER - HOSE | 725-313N | Not Available |
| # | Part image | Description | SKU | Price |
| 8 |  | ***USE E-59397-8 SWITCH, MICRO W/BRACKET 5892 Part Number: 59397-2 for Eureka | 593972 | $9.72Read more |
| 9 | Not Available | CLAMP - MOTOR | 74080 | Not Available |
| 13 | Not Available | BRUSHROLL ASSEMBLY - CRTN | 62365-1 | Not Available |
| 14 | Not Available | BELT - COGGED | 72393 | Not Available |
| 18 | Not Available | SCREW PACKAGE Pkg of | 53238-27 | Not Available |
