Schematic and parts book for Eureka 5071E . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Popular Supplies
| # | Part image | Description | SKU | Price |
| XX | Not Available | Pivot Pin | 55067 | Not Available |
| XX | Not Available | Adjustment screw 79 E-36055-7 Handle Cord | 48642 | Not Available |
| XX | Not Available | Adjustment Clamp 80 E-56563 Grommet | 47754A | Not Available |
| XX | Not Available | Pinion 102 ER-2002 Brushroll Wood Hex End | 37066 | Not Available |
| 1 | Not Available | Hood | 01162-2 | Not Available |
| 2 | Not Available | Hood Lens | 13443-1 | Not Available |
| 3 | Not Available | Adjustment slide | 24866A-5 | Not Available |
| 4 | Not Available | Hood Cap & Name Plate Ass'y | 49987-3 | Not Available |
| 5 | Not Available | Hood Cap & Name Plate Ass'y | 49937-2 | Not Available |
| 6 | Not Available | Bushing | 43814-6 | Not Available |
| 7 | Not Available | Push-On Nut | 49933 | Not Available |
| 8 | Not Available | screw | 48876 | Not Available |
| 9 | Not Available | slide Cover | 25729-6 | Not Available |
| 10 | Not Available | Headlamp socket Ass'y | 36722 | Not Available |
| 11 |  | Bulb, Headlight Victory Part Number: 48815 for Eureka | 48815 | $5.07Read more |
| 11 | Not Available | Headlight Lamp 15 Watt | FA-3515 | Not Available |
| 12 | Not Available | Drive Belt | 49727 | Not Available |
| 13 | Not Available | Reflector | 49753 | Not Available |
| 14 | Not Available | screw | EW31210T10 | Not Available |
| 15 | Not Available | Air inlet duct Ass'y L.H. W/seal | 56384 | Not Available |
| 16 | Not Available | Motor Ass'y 5.7 Amp 1 speed | 53390-7 | Not Available |
| 16 | Not Available | Motor Ass'y 6.7 Amp 2 speed | NLA | Not Available |
| 17 | Not Available | Motor seal Gasket | 30517 | Not Available |
| 17 | Not Available | Motor Seal Gasket | ER-7600 | Not Available |
| 18 | Not Available | Motor Mounting screw | EW31210T13 | Not Available |
| 19 | Not Available | Wire Nut | EW22-17 | Not Available |
| 19 | Not Available | Wire Nut | SS-3270 | Not Available |
| 20 | Not Available | Air inlet duct R.H. | 56385 | Not Available |
| 21 | Not Available | Foot Pedal spring | 45503 | Not Available |
| 22 | No Image | CLAMP ASS'Y, 5000 SERIES POWER DRIVE Part Number: 55282 for Eureka | 55282 | $2.65Read more |
| 23 | Not Available | shoulder screw (Lever to Motor) | 49721 | Not Available |
| 24 | Not Available | screw | 49089 | Not Available |
| 25 | Not Available | Acorn Nut | 49087 | Not Available |
| 26 | Not Available | Clamp & screw Ass'y | 48823 | Not Available |
| 27 | Not Available | Base & Transmission Ass'y Black | NLA | Not Available |
| 28 | Not Available | Foot Pedal | 36707A | Not Available |
| 28 | Not Available | Foot Pedal | ER-7300 | Not Available |
| 29 | Not Available | Pedal Retainer | 36842 | Not Available |
| 30 | Not Available | screw | EW12610P10 | Not Available |
| 31 | Not Available | screw (Linkage to Yoke) | 49729 | Not Available |
| 32 | Not Available | Belt Guard | 36794 | Not Available |
| 33 | Not Available | Linkage Ass'y | 26154 | Not Available |
| 34 | Not Available | screw | EW31210T13 | Not Available |
| 35 |  | Cover, Gray Wheel C2000/1400/1900/C4000 Series Part Number: 36263 for Eureka | 36263 | $4.33Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 36 |  | Axle, Metal Front C2000/6400/1400 & Most Sanitaire Part Number: 35947A for Eureka | 35947A | $8.67Read more |
| 37 | Not Available | Axle spring | 36407A | Not Available |
| 38 | Not Available | Retainer Ring | EW193-516C | Not Available |
| 39 | Not Available | shim Washer | 49717 | Not Available |
| 40 | Not Available | Washer | 47585 | Not Available |
| 41 | Not Available | Nut | EW14-10C | Not Available |
| 42 | Not Available | Pinion Plate Ass'y | 36918 | Not Available |
| 43 | Not Available | screw | 55248 | Not Available |
| 44 | Not Available | screw | 55184 | Not Available |
| 45 | Not Available | Yoke seal | 36947 | Not Available |
| 46 | Not Available | Gear & Axle Ass'y | NLA | Not Available |
| 47 | Not Available | Axle Cover | 13507-1 | Not Available |
| 48 | Not Available | screw (Axle Cover to Base) | EW31210T8 | Not Available |
| 49 |  | Wheel, Blk Front C2000/6400/1400 & Most Sanitaires Part Number: 35859A1 for Eureka | 35859A1 | $3.24Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 50 | Not Available | Wheel Washer | 47585 | Not Available |
| 51 | Not Available | Cog Pulley | 36703 | Not Available |
| 52 | Not Available | Pulley Flange Hex End W/sleeve Bearing | 49720 | Not Available |
| 53 | Not Available | spacer | 49709 | Not Available |
| 54 | Not Available | Pinion spacer Pkg. Hex End W/Ball Bearings | 55276A | Not Available |
| 55 | Not Available | Yoke screw | 55179 | Not Available |
| 56 | Not Available | Funiture Guard | 36342-3 | Not Available |
| 57 | Not Available | Belt | 30563 | Not Available |
| 57 | Not Available | Belt 2 Pk | 52100 | Not Available |
| 57 | Not Available | Belt (ESSco) | ER-1000 | Not Available |
| 57 | Not Available | Belt | ER-1010 | Not Available |
| 58 | Not Available | Bristle strip Pair | 52282-3 | Not Available |
| 58 |  | Brush Strip sanitaire Eureka VGII 12" Upright And Pn 1 Long/1 Shor | ER-2210 | $6.72Add to cart |
| 58 |  | Compatible alternateEureka,Sanitaire Brush Inserts-eureka Sanitaire Vgii 12''orange With Blue Bristles More Product Details | 52282A4 | $6.72Add to cart Special order — allow 2-4 weeks. |
| 59 | Not Available | disturbulator Bearing & | 37377 | Not Available |
| 60 | Not Available | shaft Washer | 49561 | Not Available |
| 61 | Not Available | Nut | 49175 | Not Available |
| 62 |  | END CAP, LARGE HEX VGII BRUSHROLL 53270 Part Number: 25759A for Eureka | 25759A | $7.72Read more |
| 63 | No Image | Felt Washer For: eureka,sanitaire | 49899 | $3.65Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 63 | Not Available | Felt Washer | ER-2055 | Not Available |
| 64 | Not Available | disturbulator Core | 13236 | Not Available |
| 65 | Not Available | shaft | 37378 | Not Available |
| 66 | Not Available | Gasket* | 46538 | Not Available |
| 67 |  | Bottom Plate, Double Slot/Front Tabs 1400 Series Part Number: 259221 for Eureka | 259221 | $26.36Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 67 |  | Compatible alternateBase Plate 259221 for Sanitaire, Bissell Big Green Commercial, and Old Eureka Commercial Types More Product Details | ER-7601 | $26.36Add to cart Special order — allow 2-4 weeks. |
| 68 | Not Available | Upper Handle Grip | 13336B-3 | Not Available |
| 69 | Not Available | Lower Handle Grip | 13337-3 | Not Available |
| 70 | Not Available | screw | EW312-6T7 | Not Available |
| 71 | Not Available | spring spacer | 49710 | Not Available |
| 72 | Not Available | Neutral Lock | 36890-1 | Not Available |
| 73 | Not Available | Centering spring | 49726 | Not Available |
| 74 | Not Available | Upper Handle Tube | 13326A-2 | Not Available |
| 75 | Not Available | Cord Retainer Upper | 36964-1 | Not Available |
| 76 | Not Available | Wire Nut | EW22-17 | Not Available |
| 77 | Not Available | Lower Handle Tube | 12794 | Not Available |
| 78 | Not Available | Cord Retainer Lower | 13522-1 | Not Available |
| 79 | Not Available | Handle Cord | 36055-7 | Not Available |
| 80 | Not Available | Grommet | 56563 | Not Available |
| 81 | Not Available | Cable Retainer | 36705 | Not Available |
| 82 | Not Available | Cable Ass'y | 37078 | Not Available |
| 83 | Not Available | Rocker switch 1 speed | 36056-3 | Not Available |
| 84 | Not Available | Handle insulator | 49712 | Not Available |
| 85 | Not Available | Handle Ret. Nut | 55467-1 | Not Available |
| 86 | Not Available | Handle Ret. screw | 55466-2 | Not Available |
| 86 | Not Available | Handle Nut & Bolt | ER-7700 | Not Available |
| 87 | Not Available | supply Cord & Plug Ass'y | 25242-6 | Not Available |
| 87 | Not Available | cord 30 Ft. | NLA | Not Available |
| 87 | Not Available | cord 20 Ft. | ER-3000 | Not Available |
| 88 | Not Available | Handle socket Cover | 13413-2 | Not Available |
| 89 | Not Available | Hair Cotter Pin | EW181-7C | Not Available |
| 90 | Not Available | screw | 55466-2 | Not Available |
| 91 | Not Available | Pin | 41064E | Not Available |
| 92 | Not Available | spring | 36812 | Not Available |
| 93 | Not Available | screw | EW35-12P30 | Not Available |
| 94 | Not Available | Bracket & Bushing Ass'y | 36521A-1 | Not Available |
| 95 | Not Available | screw | EW31210T10 | Not Available |
| 96 | Not Available | Nut | 55467-1 | Not Available |
| 97 | Not Available | Handle socket | 25848-3 | Not Available |
| 97 | Not Available | Handle Socket Ass'y | ER-7000 | Not Available |
| 98 | Not Available | spacer | 45507 | Not Available |
| 99 | Not Available | Keps Nut | 45474-4 | Not Available |
| 100 | Not Available | Nut | EW1410ZP | Not Available |
| 101 | Not Available | Bolt | 48870 | Not Available |
| 102 | Not Available | Brushroll vGii | 53398-1 | Not Available |
| 102 | Not Available | Brushroll vGii | 53270 | Not Available |
| 102 |  | Brushroll, 12 Inch Hex End W/Ball Brng/Beater Bar | ER2002 | $20.85Read more |
| 102 | Not Available | Brushroll Wood All Brush | ER-2004 | Not Available |
