Schematic and parts book for Eureka 4333A . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | SUPPLY CORD & TERMINAL AS | 39585-1 | Not Available |
| 2 | Not Available | BAG COVER ASSY - PACKAGED | 54936-95 | Not Available |
| 3 | Not Available | GASKET - BAG COVER | 58505 | Not Available |
| 4 | Not Available | GASKET | 38613 | Not Available |
| 5 | Not Available | EXHAUST - FILTER | 38614 | Not Available |
| 6 | Not Available | REAR HOUSING - PACKAGED | 60126-22 | Not Available |
| 7 | Not Available | MOTOR SHIELD | 38688A | Not Available |
| 8 |  | FOAM, SOUND Part Number: 722241 for Eureka | 722241 | $2.93Read more |
| 9 | Not Available | PLUNGER | 38678-119N | Not Available |
| 10 | Not Available | SPRING | 55794 | Not Available |
| 11 | Not Available | MOTOR COVER ASSEMBLY - PK | 60788-27 | Not Available |
| 13 | Not Available | GASKET | 27962 | Not Available |
| 14 | Not Available | MOTOR ASSEMBLY - PACKAGED | 60261-15 | Not Available |
| 15 | Not Available | CAP - HANDLE | 38482A-119N | Not Available |
| 16 | Not Available | HANDLE & CAP ASSEMBLY | 71139-1 | Not Available |
| 17 |  | Screw, SC5845/4390A/SP5035A 10Pk Part Number: 5323844 for Eureka | 5323844 | $6.78Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 18 | Not Available | SCREW PACKAGE | 53197-1 | Not Available |
| 19 | Not Available | CADDY - TOOL | 02093A-119N | Not Available |
| 20 | Not Available | SWITCH - BUTTON | 27474C-288N | Not Available |
| 21 | Not Available | TORS SPRING PKG | 60134 | Not Available |
| 22 | Not Available | SWITCH - PUSHBUTTON | 28304A | Not Available |
| 23 | Not Available | RETAINING RING PKG | 60165-1 | Not Available |
| 24 | Not Available | THERMOSTAT & TERMINAL ASS | 39252-2 | Not Available |
| 25 | Not Available | MOTOR FILTER PACKAGE | 61333 | Not Available |
| 26 | Not Available | GRILLE - AIR DUCT | 28425 | Not Available |
| 27 | Not Available | GASKET - AIR DUCT | 59297SV | Not Available |
| 28 | Not Available | AIR DUCT | 15536A-119N | Not Available |
| 30 | Not Available | FLANGE - MOTOR INTAKE | 39023 | Not Available |
| 31 | Not Available | GROMMET | 27552A | Not Available |
| 31 | Not Available | FAN - MOTOR COOLING | 30474A | Not Available |
| 31 | Not Available | RETAINER - UPPER BEARING | 20217E | Not Available |
| # | Part image | Description | SKU | Price |
| 1 |  | KNOB, HIEGHT ADJUSTMENT VICTORY UPRIGHT Part Number: 27462E-288N for Eureka | 27462E288N | $4.73Read more |
| 2 | | Screw, SC5845/4390A/SP5035A 10Pk Part Number: 5323844 for Eureka | 5323844 | $6.78Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3 | Not Available | HOOD ASSEMBLY - PACKAGED | 54933-85 | Not Available |
| 4 | Not Available | BASE ASSEMBLY - CARTONED | 60843-12 | Not Available |
| 5 | Not Available | ADAPTER - BASE | 28243A-316N | Not Available |
| 6 |  | Spring, Wheel Retainer Ht Adjustment Victory 10Pk Part Number: 54943 for Eureka | 54943 | $10.34Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 7 | Not Available | CARRIAGE - WHEEL | 14993C-119N | Not Available |
| 8 |  | Wheel, Front 5191/5847AV Part Number: 39173A119N for Eureka | 39173A119N | $5.24Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 9 | Not Available | AXLE - WHEEL | 71551 | Not Available |
| 10 | Not Available | 12" DISTURBULATOR ASSY - | 60251-3 | Not Available |
| 11 | Not Available | GUARD - FURNITURE (12") | 15237A-288N | Not Available |
| 12 | Not Available | SCREW PACKAGE | 53197-1 | Not Available |
| 13 |  | CUFF, HOSE NOZZLE HSG VICTORY SERIES Part Number: 27468D-119N for Eureka | 27468D119N | $5.87Read more |
| 14 | Not Available | HOSE - COMPRESSION (PURCH | 38479-4 | Not Available |
| 15 | Not Available | RELEASE - HANDLE | 27467A-288N | Not Available |
| 16 |  | SPRING, HANDLE RELEASE VICTORY 5PK Part Number: 60133 for Eureka | 60133 | $3.14Read more |
| 17 | Not Available | WHEEL - REAR | 72117-119N | Not Available |
| 18 | Not Available | PACKAGE - RETAINING RING | 54432-1 | Not Available |
| 19 |  | Axle, Rear 4458A/4468A/4499A/2903A/2905A Part Number: 38590A for Eureka | 38590A | $7.73Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 20 | Not Available | BUSHING - AXLE | 72113-1 | Not Available |
| 21 | Not Available | GASKET | 58506-1 | Not Available |
| 22 | Not Available | BELT PKG ASSY-STYLE U EXT | 61120A | Not Available |
| 23 | Not Available | BELT CAP & GASKET -PACKA | 54376-2 | Not Available |
| 24 |  | GASKET, FELT VICTORY Part Number: 57569 for Eureka | 57569 | $3.33Read more |
| 25 | Not Available | CLAMP | 38420-2 | Not Available |
| 25 | Not Available | FAN - MOTOR COOLING | 30474A | Not Available |
| 25 | Not Available | RIVET PACKAGE | 51108A-10 | Not Available |
| 25 | Not Available | SCREW PACKAGE | 53197 | Not Available |
| 25 | Not Available | GUIDE - CORD | 27007-2 | Not Available |
| 25 | Not Available | HOOD & NAMEPLATE ASSY - P | 54000 | Not Available |
