Schematic and parts book for Eureka 300a . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | TIE - CABLE (PURCHASED) | 46713-3 | Not Available |
| 2 | Not Available | STEAM MOP SCRUB PAD PKG | 60675 | Not Available |
| 3 | Not Available | SAFETY CAP ASSEMBLY | 60710 | Not Available |
| 4 | Not Available | SEALING RING | 60712 | Not Available |
| 5 | No Image | HOUSING, UPPER YELLOW 300 ENVIRO STEAMER Part Number: 60713 for Eureka | 60713 | $33.37Read more |
| 6 | Not Available | SPRING | 60716 | Not Available |
| 7 | Not Available | BOILER SEAL | 60720 | Not Available |
| 8 | Not Available | OUTLET SEAL | 60721 | Not Available |
| 9 | Not Available | BASE | 60722 | Not Available |
| 10 | Not Available | DIFFUSER | 60724 | Not Available |
| 11 | Not Available | LENS | 60726 | Not Available |
| 12 | Not Available | SWITCH COVER | 60727 | Not Available |
| 13 | Not Available | CLAMP | 60729 | Not Available |
| 14 | Not Available | TUBE | 60731 | Not Available |
| 15 | Not Available | CABLE & WIRE ASSEMBLY | 60732 | Not Available |
| 16 | Not Available | CLAMP | 60733 | Not Available |
| 17 | Not Available | THERMOSTAT | 60734 | Not Available |
| 18 | Not Available | CLAMP | 60735 | Not Available |
| 19 | Not Available | RESISTOR WIRE | 60736 | Not Available |
| 20 | Not Available | ON-OFF SWITCH | 60738 | Not Available |
| 21 | Not Available | BUSHING | 60739 | Not Available |
| 22 | Not Available | POWER SUPPLY CORD | 60740 | Not Available |
| 23 | Not Available | FUNNEL | 60741 | Not Available |
| 24 | Not Available | MEASURING CUP | 60742 | Not Available |
| 25 | Not Available | BALL CONNECTOR LEFT/RIGHT | 60743 | Not Available |
| 26 | Not Available | CONNECTOR (LEFT & RIGHT)- | 60744 | Not Available |
| 27 | Not Available | CLAMP | 60745 | Not Available |
| 28 | Not Available | TELESCOPIC HANDLE ASSY | 60747 | Not Available |
| 29 | Not Available | HOOK | 60748 | Not Available |
| 30 | Not Available | HANDLE GRIP | 60749 | Not Available |
| 31 | Not Available | PRE-HEATING PAD | 60755 | Not Available |
| 32 | Not Available | O-RING | 60762-1 | Not Available |
| 33 | Not Available | WASHER PACKAGE | 60763-1 | Not Available |
| 34 | Not Available | RING PACKAGE | 60764-1 | Not Available |
| 35 | Not Available | SUPPORT PACKAGE | 60765-1 | Not Available |
| 36 | Not Available | SCREW PACKAGE | 60766-1 | Not Available |
| 37 | Not Available | SCREW PACKAGE | 60767-1 | Not Available |
| 38 |  | SPRING, SWITCH BUTTON 300A 5PK Part Number: 60768-1 for Eureka | 607681 | $4.62Read more |
| 39 | Not Available | WASHER PACKAGE | 60769-1 | Not Available |
| 40 | Not Available | SCREW PACKAGE | 60771-1 | Not Available |
| 41 | Not Available | SCREW PACKAGE | 60772-1 | Not Available |
| 42 | Not Available | BOILER ASSEMBLY - PACKAGE | 60846 | Not Available |
