Schematic and parts book for Eureka 2941AVZ . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | No Image | CAP, HANDLE 2971BVZ Part Number: 72221-434N for Eureka | 72221434N | $3.03Read more |
| 2 |  | Dust Brush-Eureka - 7606 Combo
Sc5845 For: eureka,sanitaire | 609902 | $11.94Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3 | Not Available | SCREW PACKAGE Pkg. of | 53238-27 | Not Available |
| 4 | Not Available | HOSE ADAPTER ASSEMBLY | 74093 | Not Available |
| 5 | Not Available | HOSE ASSEMBLY - CARTONED | 62293-3 | Not Available |
| 6 | Not Available | COUPLING - HOSE | 70559A-355N | Not Available |
| 7 | Not Available | PACKAGE - HARDWARE | 73012 | Not Available |
| 8 | Not Available | Includes 71973-119N Outer Wand and | 74149 | Not Available |
| 9 | No Image | Solenoid,Extractor,1/8 Orifice | 71492A | $971.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 10 | Not Available | LOWER HOSE HOLDER | 73649-355N | Not Available |
| 11 | Not Available | SCREW PACKAGE Pkg. of | 53238-27 | Not Available |
| 13 | Not Available | CLIP - WAND | 73694-355N | Not Available |
| 14 | Not Available | HOOK - CORD | 39977-355N | Not Available |
| 15 | Not Available | HANDLE ASSEMBLY (DUSTER) | 75765-1 | Not Available |
| 16 | Not Available | ELECTROSTATIC DUSTER ASSY Includes 73594 | 75628-1 | Not Available |
| 17 | Not Available | DUSTER ASSEMBLY | 74123-1 | Not Available |
| 18 | No Image | Retainer, Rear 45 inch squeegee | 75391 | $538.99Read more |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | FILTER DOOR & GRAPHICS | 74119-5 | Not Available |
| 2 |  | Filter, Dirt Cup Foam W/Frame 2940/2975/DCF9/2980 Part Number: 74100A for Eureka | 74100A | $8.45Read more |
| 3 | Not Available | SWITCH - ROCKER | 39455-1 | Not Available |
| 4 | Not Available | CYCLONE COVER ASSEMBLY | 63142-8 | Not Available |
| 5 | Not Available | CYCLONE ASSEMBLY | 74098 | Not Available |
| 6 | Not Available | AIR DUCT ASSEMBLY | 74092 | Not Available |
| 7 | Not Available | SHIELD - WIRING | 74169 | Not Available |
| 8 | Not Available | WASHER - FIBER | 74178 | Not Available |
| 9 | Not Available | REAR HOUSING ASSEMBLY | 74096 | Not Available |
| 10 | Not Available | CUP LID ASSEMBLY | 74094-1 | Not Available |
| 11 | Not Available | CUP & STICKER ASSY | 75762-1 | Not Available |
| 13 | Not Available | EXHAUST FLTR DOOR&GRPHCS | 74333-9 | Not Available |
| 15 | Not Available | HEPA FILTER PKG - | 61850A | Not Available |
| 16 | Not Available | GASKET - MOTOR CAN | 72476-119N | Not Available |
| 17 | Not Available | SCREW PACKAGE | 62082 | Not Available |
| 18 | Not Available | SHIELD - MOTOR | 73526 | Not Available |
| 19 | Not Available | MOTOR ASSEMBLY | 62075-1 | Not Available |
| 20 | Not Available | BUSHING - MOTOR | 72650-119N | Not Available |
| 21 | Not Available | TIE - CABLE (PURCHASED) | 46713-3 | Not Available |
| 22 | Not Available | LAMP - HEADLIGHT | 57940-3 | Not Available |
| 23 | Not Available | HEADLIGHT ASSEMBLY | 38828B-5 | Not Available |
| 24 |  | Screw, Bottom Plate Part Number: 54669-2 for Eureka | 546692 | $6.89Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 25 | Not Available | LENS - HEADLIGHT | 73313-357N | Not Available |
| 26 | Not Available | CAP - ELEVATOR | 73704-355N | Not Available |
| 27 | Not Available | PLATFORM - CUP | 73623-355N | Not Available |
| 28 | Not Available | ACTUATOR - CUP | 73624-355N | Not Available |
| 29 | Not Available | MOTOR COVER ASSEMBLY | 63141-8 | Not Available |
| 30 | Not Available | SUPPLY CORD & TERMINAL | 39585-5 | Not Available |
| 31 |  | Wire Nuts, 5Pk Part Number: 60192-1 for Eureka | 601921 | $5.38Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 32 | Not Available | CORD & TERMINAL | 73001-1 | Not Available |
| 33 | Not Available | SCREW PACKAGE | 61803-3 | Not Available |
| 34 | No Image | CLIP, THERMOSTAT 2903AE Part Number: 72443 for Eureka | 72443 | $4.55Read more |
| 35 | Not Available | THERMOSTAT & TERMINAL | 74719 | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | KNOB - HEIGHT ADJUSTMENT | 72472-355N | Not Available |
| 2 | Not Available | FELT - BASE | 73114 | Not Available |
| 3 | Not Available | BASE ASSEMBLY - PACKAGED | 62572 | Not Available |
| 4 |  | Spring, Wheel Retainer Ht Adjustment Victory 10Pk Part Number: 54943 for Eureka | 54943 | $10.34Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 5 | Not Available | WHEEL CARRIAGE | 72521-119N | Not Available |
| 6 |  | Axle, Front SC5713/SC5815/SC5845 Uprights Part Number: 71478 for Eureka | 71478 | $5.24Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 7 |  | Wheel, Front 5191/5847AV Part Number: 39173A119N for Eureka | 39173A119N | $5.24Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 8 | Not Available | BELT PKG ASSY-STYLE U EXT pkg of | 61120A | Not Available |
| 9 | Not Available | GUARD - BELT | 38063 | Not Available |
| 10 | | Screw, Bottom Plate Part Number: 54669-2 for Eureka | 546692 | $6.89Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 11 | Not Available | HOOD ASSEMBLY - PACKAGED | 62573-1 | Not Available |
| 12 |  | SPRING, HANDLE RELEASE 2903 Part Number: 71574 for Eureka | 71574 | $4.45Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 13 | Not Available | HANDLE RELEASE | 72473-355N | Not Available |
| 14 | Not Available | SCREW PACKAGE | 53238-27 | Not Available |
| 15 |  | Clamp, Motor Part Number: 71487 for Eureka | 71487 | $3.88Read more |
| 16 |  | Ring, Retaining Wheels EL6988/EL7020/EL7070/EL4300 Part Number: 54432-2 for Eureka | 544322 | $4.33Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 17 | Not Available | WHEEL - REAR | 72117-119N | Not Available |
| 18 | Not Available | BUSHING - AXLE | 73432 | Not Available |
| 19 |  | Axle, Rear 4458A/4468A/4499A/2903A/2905A Part Number: 38590A for Eureka | 38590A | $7.73Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 20 | Not Available | BELT CAP ASSEMBLY Includes item | 73289 | Not Available |
| 21 | Not Available | FELT - BASE | 73114 | Not Available |
| 22 | Not Available | 12" DISTURBULATOR ASSY - | 60844-7 | Not Available |
| 23 | Not Available | FURNITURE GUARD | 75373-355N | Not Available |
| 24 | Not Available | BASE HOSE ASSEMBLY | 74104 | Not Available |
