Schematic and parts book for Eureka 2590A . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | No Image | HANDLE, 2590 ATLANTIS Part Number: 72616-2 for Eureka | 726162 | $32.04Read more |
| 2 | Not Available | CORD - SUPPLY | 38752-2 | Not Available |
| 3 | Not Available | CLAMP - TUBE | 72979 | Not Available |
| 4 | Not Available | DIVERTER MANIFOLD ASSEMBL | 72496 | Not Available |
| 5 | Not Available | DETERGENT VALVE ASSEMBLY | 72986 | Not Available |
| 6 | Not Available | TUBING | 70316-7 | Not Available |
| 7 | Not Available | TOOL CADDY ASSEMBLY | 73232-2 | Not Available |
| 8 | No Image | SWITCH, 2590A STEAMER Part Number: 73368 for Eureka | 73368 | $9.22Read more |
| 9 | Not Available | SCREW PACKAGE | 53238-27 | Not Available |
| 10 | Not Available | GASKET - MOTOR CAN | 72859 | Not Available |
| 11 | Not Available | MOTOR - SUCTION | 72382 | Not Available |
| 12 | No Image | GASKET, MOTOR 2596 Part Number: 72834 for Eureka | 72834 | $16.20Read more |
| 13 | Not Available | AGITATOR DRIVE ASSEMBLY | 72737 | Not Available |
| 14 | Not Available | SEPARATOR - AIR | 73207 | Not Available |
| 15 | Not Available | PUMP & MOTOR ASSY - PKGD | 60221C | Not Available |
| 16 | Not Available | GASKET - MIXING MANIFOLD | 73292 | Not Available |
| 17 | Not Available | MIXING MANIFOLD ASSEMBLY | 72633 | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | CARRY HANDLE CAP & GRPHCS | 73534-2 | Not Available |
| 2 | No Image | DOOR, WATER PORT ATLANTIS EXTRACTOR 2951 Part Number: 72380-355N for Eureka | 72380355N | $1.82Read more |
| 3 | Not Available | GASKET - DOOR | 72865 | Not Available |
| 5 | Not Available | HANDLE - CARRY | 72524-386N | Not Available |
| 6 | Not Available | CUP - GASKET (EXTRUDED RI | 72964 | Not Available |
| 7 | No Image | GASKET, SUCTION COVER Part Number: 72866 for Eureka | 72866 | $4.54Read more |
| 8 | No Image | GASKET, SUCTION COVER Part Number: 72874 for Eureka | 72874 | $4.54Read more |
| 9 | Not Available | SLIDE LOCK - SUCTION COVE | 72759-355N | Not Available |
| 10 | Not Available | SCREW PACKAGE | 53238-36 | Not Available |
| 11 | Not Available | CORD WRAP ASSEMBLY | 72754-2 | Not Available |
| 12 | No Image | GASKET, RECOVERY TANK 2590 Part Number: 72861 for Eureka | 72861 | $7.72Read more |
| 14 | Not Available | HANDLE PIVOT CLAMP | 72740-386N | Not Available |
| 15 | Not Available | COVER - BOTTOM | 72346-355N | Not Available |
| 17 | Not Available | DETERGENT VALVE PLUNGER A | 73023 | Not Available |
| 18 | Not Available | GASKET - INTAKE | 72863 | Not Available |
| 19 | Not Available | CLAMP - HOLD DOWN | 72787 | Not Available |
| 20 | Not Available | RELEASE - HANDLE | 72377-355N | Not Available |
| 21 | Not Available | SPRING PACKAGE | 61866 | Not Available |
| 22 | Not Available | SPRING - COMPRESSION | 72983 | Not Available |
| 23 | Not Available | GASKET - MOTOR COVER | 72860 | Not Available |
| 24 | Not Available | RECEIVER - DETERGENT | 72540-119N | Not Available |
| 26 | No Image | COVER, MOTOR ATLANTIS EXT 2590 Part Number: 72741-2 for Eureka | 727412 | $27.06Read more |
| 27 |  | LOCK, WINDOW CORNER ATLANTIS 2451 Part Number: 72537-355N for Eureka | 72537355N | $5.09Read more |
| 28 | No Image | WHEEL AXLE, DREAM MACHINE UPRIGHT EXTRACTOR 2450A Part Number: 38392 for Eureka | 38392 | $6.66Read more |
| 29 | No Image | CLIP, REAR WHEEL EXCALIBAR Part Number: 54709 for Eureka | 54709 | $7.48Read more |
| 30 | No Image | WHEEL, 2590A Part Number: 72736 for Eureka | 72736 | $16.61Read more |
| 31 | Not Available | BASE ASSEMBLY | 72735 | Not Available |
| 32 | Not Available | AGITATOR ASSEMBLY | 72630 | Not Available |
| 33 | Not Available | SCREW PACKAGE | 53238-27 | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | SUCTION COVER & GRPHCS AS | 73533 | Not Available |
| 2 | Not Available | CLEAN WATER TANK ASSEMBLY | 72610-2 | Not Available |
| 3 | Not Available | DETERGENT TANK ASSEMBLY | 72752 | Not Available |
| 4 | Not Available | EXTRACTOR SHAMPOO PACKAGE | 60170 | Not Available |
| 5 | Not Available | PLENUM FILTER | 72751 | Not Available |
| 6 | Not Available | BRUSH - AGITATOR (BRISTLE | 73365 | Not Available |
| 8 | Not Available | GROOMING BRUSH ASSEMBLY | 72375 | Not Available |
| 9 | Not Available | RECOVERY TANK ASSEMBLY | 72609-2 | Not Available |
| 10 | Not Available | UPHOLSTERY HOSE & HANDLE | 72757 | Not Available |
| 11 | Not Available | SUCTION NOZZLE ASSEMBLY | 72763 | Not Available |
