Schematic and parts book for Eureka 1510A . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Popular Supplies
| # | Part image | Description | SKU | Price |
| XX | Not Available | cord Strap (not illustrated) | FA-3210 | Not Available |
| XX | Not Available | *sole Plate Gasket | 25903 | Not Available |
| 1 | Not Available | Upper shell & Latch Ass'y | 55273 | Not Available |
| 2 | Not Available | Handle Wood W/Large Pulley** | 13499-1 | Not Available |
| 3 | Not Available | screw | EW285-6T5C | Not Available |
| 4 | Not Available | Tool support Wood W/small Pulley | 13506-2 | Not Available |
| 5 | Not Available | Latch spring | 35564 | Not Available |
| 6 | Not Available | Handle screw Wood W/small Pulley | EW2858T6CC | Not Available |
| 7 | Not Available | Furniture Guard | 26014-1 | Not Available |
| 8 | Not Available | Disp. Bag stye H 3 Pk Wood W/Small Pulley | 52323 | Not Available |
| 8 | Not Available | Disp. Bag Style H 3 Pk | ER-1408 | Not Available |
| 9 | Not Available | Filter Disc | 34281 | Not Available |
| 9 | Not Available | Filter Foam | ER-1800 | Not Available |
| 10 | No Image | SUPPORT, FILTER 3300 713 1510 1756 Part Number: 24128A for Eureka | 24128A | $10.81Read more |
| 10 | Not Available | Filter Support W/Filter | COR-1800 | Not Available |
| 11 |  | Filter Support Clip- Eur. For: eureka,sanitaire | 487561 | $4.00Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 12 | Not Available | Motor Ass'y | 54336 | Not Available |
| 12 | Not Available | Motor Ass'y | GS-041 | Not Available |
| 13 | Not Available | Wire Nut | EW22-25 | Not Available |
| 13 | Not Available | Wire Nut | SS-3270 | Not Available |
| 14 | Not Available | Bag Gasket | 55056 | Not Available |
| 14 | Not Available | Bag Gasket Split Ring | NLA | Not Available |
| 15 | Not Available | Motor Mounting Plate | 11862A | Not Available |
| 16 | Not Available | Motor Mount Ring | 33295A | Not Available |
| 17 | Not Available | Bag support | 26011 | Not Available |
| 18 | Not Available | Locator | 34562 | Not Available |
| 19 | Not Available | Wire Clip | 47922 | Not Available |
| 20 | Not Available | Motor Mounting Bushing | 44226 | Not Available |
| 21 | Not Available | Motor Mounting screw | 46106A | Not Available |
| 22 | Not Available | Receptacle Ass'y E-25353 *Name Plate | 48600-1 | Not Available |
| 23 | Not Available | strain Relief Bushing | 43814-6 | Not Available |
| 23 | Not Available | Strain Relief Bushing | SS-3265 | Not Available |
| 24 | Not Available | supply Cord & Plug Ass'y | 36528-3 | Not Available |
| 24 | Not Available | Supply cord 30 Ft. | NLA | Not Available |
| 24 | Not Available | Supply cord 20 Ft. | NLA | Not Available |
| 25 | Not Available | Push switch | 25802-3 | Not Available |
| 25 | Not Available | Push Switch | FA-3400 | Not Available |
| 26 | Not Available | Lower shell & Wheel Ass'y | 55408-4 | Not Available |
| 27 | Not Available | Front Caster Ass'y | 48872-1 | Not Available |
| 28 | Not Available | Hinge Bracket | 37028 | Not Available |
| 29 | Not Available | Pin | 35845-1 | Not Available |
| 30 | Not Available | switch Pedal | 24766-4 | Not Available |
| 31 | Not Available | Locator screw | 48624 | Not Available |
| 32 | Not Available | Rear Wheel | 34169-9 | Not Available |
| 33 | Not Available | Pin | 46842 | Not Available |
| 34 | Not Available | Cotter Pin | EW181-5C | Not Available |
| 35 | Not Available | Bracket screw | 48624 | Not Available |
| 36 | Not Available | sole Plate Ass'y* | 25788 | Not Available |
| 37 | Not Available | Brushroll Ass'y | NLA | Not Available |
| 37 | Not Available | Brushroll Ass'y | 53408 | Not Available |
| 37 | Not Available | Brushroll Ass'y | 53348-1 | Not Available |
| 37 |  | NO LONGER AVAILABLE Eureka Canister Brush Roll W/Bearings And Sm Pulley OEM # 70097 also fits tri... | ER-2030 | $38.49Read more |
| 38 | Not Available | **Felt Washer | 49101 | Not Available |
| 39 | Not Available | **Felt Retainer | 36412 | Not Available |
| 40 | Not Available | **Bearing Ass'y Repair Kit | 53282 | Not Available |
| 41 | Not Available | **Flat Washer | 49591 | Not Available |
| 42 | Not Available | screw | EW305-8P7N | Not Available |
| 43 | Not Available | Drive Belt | 52201 | Not Available |
| 43 | Not Available | Drive Belt | ER-1050 | Not Available |
| 44 | Not Available | **Locknut | 49175 | Not Available |
| 45 |  | Cleaner, Dry Carpet Pail 4Lbs Part Number: 37114 for Oreck | 37114 | $43.29Read more |
| 46 | Not Available | Plate screw | EW312-88C | Not Available |
| 47 | Not Available | Retainer Plate | 48332 | Not Available |
| 48 | Not Available | Wire Nut | EW22-17 | Not Available |
| 48 | Not Available | Wire Nut | SS-3270 | Not Available |
| 49 | Not Available | Motor | 52314-2 | Not Available |
| 49 | Not Available | Motor | ER-6050 | Not Available |
| 50 | Not Available | On-sert | 49050 | Not Available |
| 51 | Not Available | Belt Guard | 49110A | Not Available |
| 52 | Not Available | Grounding Cover | 36680 | Not Available |
| 53 | Not Available | Housing Ass'y* | NLA | Not Available |
| 54 | Not Available | Motor screw | EW110-8P4C | Not Available |
| 55 | Not Available | Furniture Guard | 36322A-2 | Not Available |
| 56 | Not Available | Wand | 36879-2 | Not Available |
| 56 | Not Available | Wand | FA-5001 | Not Available |
| 57 | Not Available | strain Relief Bushing | 55053-1 | Not Available |
| 57 | Not Available | Strain Relief Bushing | SS-3265 | Not Available |
| 58 | Not Available | Cord | 35970-5 | Not Available |
| 58 | Not Available | cord | ER-3055 | Not Available |
| 59 | Not Available | Handle socket | NLA | Not Available |
| 60 | Not Available | Axle | 48334 | Not Available |
| 61 | Not Available | Axle Bearing | 48336 | Not Available |
| 62 | Not Available | Wheel | 36555-1 | Not Available |
| 63 | Not Available | Hose 5" | 25789-2 | Not Available |
| 63 | Not Available | Hose 5" | ER-7200 | Not Available |
| 64 | Not Available | inlet divider | 12578B-1 | Not Available |
| 65 | Not Available | screw | EW312-8-8C | Not Available |
