Schematic and parts book for dirt devil 7200, 088305 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Popular Supplies
Helpful Repair Videos
| # | Part image | Description | SKU | Price |
| I | Not Available | MOTOR GASKET | 1200121000 | Not Available |
| IS | Not Available | SPRING | 1720375000 | Not Available |
| NS | Not Available | WIRE FORM BRACKET | I720250(XX) | Not Available |
| NS | Not Available | EDGE CLEANER KNOB | 1720260600 | Not Available |
| NS | Not Available | EDGE CLEANER DOOR | 172034500071007200. 73007470 | Not Available |
| NS | Not Available | FELT BASE | 1820101700 | Not Available |
| NS | Not Available | FELT GUARD | 1820102700 | Not Available |
| NS | Not Available | NOZZLE GUARD PLATE | 1820183000 | Not Available |
| NS | Not Available | WEDGE BASE SKT | 2830160000 | Not Available |
| NS | Not Available | MOTOR COVER | 2847108600 | Not Available |
| NS | Not Available | ALL SOCKET | 3720295000 | Not Available |
| NS | Not Available | PIVOT COLLAR | 1720350000 | Not Available |
| NS | Not Available | 7100.7170. 7200. PIVOT SEAL | 1720365000 | Not Available |
| NS | Not Available | WAND SUPPORT | 1720385000 | Not Available |
| NS | No Image | WAND SUPPORT PAD, CHROME DIRT DEVIL Part Number: 1720386000 for Royal | 1720386000 | $0.94Read more |
| NS | Not Available | 7100.7170 7200 WHEEL WASHER | 1730100600 | Not Available |
| NS | Not Available | NYLON EYELET | 1730402000 | Not Available |
| 2 | Not Available | CORD HOOK | 1720120600 | Not Available |
| 2 | Not Available | SWITCH | 1720125300 | Not Available |
| 4 | Not Available | FILTER | 1720130000 | Not Available |
| 4 |  | FILTER, MICRON DIRT DEVIL HARD BODY UPRIGHT Part Number: 1727030001 for Royal | 1727030001 | $9.89Read more |
| 5 | Not Available | FILTER SUPPORT | 1720135600 | Not Available |
| 7 | Not Available | LENS | 1720150000 | Not Available |
| 8 | Not Available | ATTACHMENT CLIP | 1720170600 | Not Available |
| 9 | Not Available | NOZZLE GUARD | 28201S2600 | Not Available |
| 9 | Not Available | CHROME BASE PLATE | 1720181000 | Not Available |
| 10 | Not Available | WHEEL SLEEVE | 1720186700 | Not Available |
| 10 | Not Available | WHEEL SLEEVE | 1720189600 | Not Available |
| 11 | Not Available | 4 POS HEIGHT ADJUSTMENT | 1720240600 | Not Available |
| 12 | Not Available | HANDLE RELEASE PEDAL | 1720255600 ALL | Not Available |
| 13 | Not Available | BAG HOLDER | 1720270600 | Not Available |
| 14 | Not Available | 4 POS LEVER | 1720275000 | Not Available |
| 15 | Not Available | BELT | 1720310001 | Not Available |
| 17 | Not Available | PIVOT BUSHING | 1720355000 | Not Available |
| 19 | Not Available | PIVOT CLAMP | 1820351600 | Not Available |
| 20 | Not Available | MOTOR COVER | 2717115600 | Not Available |
| 21 | Not Available | BACK PANEL | 2717125600 | Not Available |
| 21 | Not Available | BACK PANEL | 2830115600 | Not Available |
| 21 | Not Available | BACK PANEL | 3720110600 | Not Available |
| 21 | Not Available | BACK PANEL | 9717125600 | Not Available |
| 21 | Not Available | BACK PANEL | 9820112600 | Not Available |
| 21 | Not Available | BACK PANEL | 9830115600 | Not Available |
| 21 | Not Available | NOZZLE BASE | 2720210600 | Not Available |
| 21 | Not Available | NOZZLE BASE | 9S20211600 | Not Available |
| 21 | Not Available | S0771 F. BASE | 2820211600 | Not Available |
| 21 |  | Wire Form & Roller-Royal 7000 Sreies Upright For: dirt devil | 2720247000 | $5.53Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 24 | Not Available | NOZZLE COVER | 2817207600 | Not Available |
| 24 | Not Available | NOZZLE COVER | 2849208300 | Not Available |
| 25 | Not Available | HOSE ASSEMBLY | 2820162300 | Not Available |
| 26 | Not Available | HANDLE | 3720155600 | Not Available |
| 27 | Not Available | BRUSH | 3820220000 | Not Available |
| 27 | Not Available | STANDARD BRUSH | 3720215600 | Not Available |
| 27 | Not Available | DELUXE BRUSH | 3720216600 | Not Available |
| 28 | Not Available | MOTOR 12 amp with Leads | 3847121000 | Not Available |
| 28 | Not Available | MOTOR 12 amp w/o leads | 3847122000 | Not Available |
| 29 | Not Available | POWER CORD 32 ft 2 wire | I830292600 | Not Available |
| 30 | Not Available | FRONT COVER | 2849109300 | Not Available |
| 33 | Not Available | BLK END CAP STANDARD BRUSH | 1720220600 | Not Available |
| 33 | Not Available | WHT END CAP DELUXE BRUSH | 1727220700 | Not Available |
| 33 |  | Genuine Dirt Devil Type C Bags for MVP - 3pk | 3700147001 | $6.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 33 |  | Compatible alternateEnviroCare Dirt Devil Type C Deluxe Vacuum Bags (3-Pack) More Product Details | 836301001213 | $6.99Add to cart |
| 33 | Not Available | CREVICE TOOL 8" | 1502801600 ALL | Not Available |
| 36 | Not Available | TELESCOPIC WAND | 2820480600 | Not Available |
| 37 | Not Available | ROUND DUSTING BRUSH | 3050282600 | Not Available |
| 38 | Not Available | UPHOLSTERY TOOL | 3098584600 | Not Available |
| 38 | Not Available | LOWER HOSE | 1820162600 | Not Available |
| 40 | Not Available | SOCKET | 3720295000 | Not Available |
| 41 | Not Available | BULB | 1725629000 | Not Available |
| 42 | Not Available | SCREW | 1250100000 | Not Available |
