Schematic and parts book for Commercial AS312215 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | HANDLE RELEASE | AS312215 | Not Available |
| 2 | No Image | BOLT, HANDLE RYC200 Part Number: VF30015 for Royal | VF30015 | $33.26Read more |
| 3 | Not Available | SCREW | VF30017 | Not Available |
| 4 | Not Available | COVER HOOK | VF30014 | Not Available |
| 5 | Not Available | CORD HOOK | VF30013 | Not Available |
| 6 | Not Available | LOCK NUT M-8 X 5.7 | VF13503 | Not Available |
| 7 | Not Available | SCREW M-5 X 55 | VF14114 | Not Available |
| 8 | Not Available | PLAIN WASHER | VF13517 | Not Available |
| 9 | Not Available | LOCK NUT M-10 | VF13504 | Not Available |
| 10 | Not Available | FRONT HANDLE COVER | AS312208 | Not Available |
| 11 | Not Available | HANDLE GRIP | VF48310 | Not Available |
| 12 | Not Available | LEFT LEVER SWITCH | AS312210 | Not Available |
| 13 | Not Available | RIGHT LEVER SWTICH | AS312211 | Not Available |
| 14 | Not Available | SCREW M-4 X 12 | V V13661 | Not Available |
| 15 | Not Available | CLAMP BLOCK | VF48309 | Not Available |
| 16 | Not Available | SCREW M-5 X 30 | GT13009 | Not Available |
| 17 | Not Available | REAR HANDLE COVER | AS312209 | Not Available |
| 18 | Not Available | CIRCUIT BREAKER 12 amp | VF99012 | Not Available |
| 18 | Not Available | CIRCUIT BREAKER 17 AMP | VF99010C | Not Available |
| 19 | Not Available | SWITCH ASSEMBLY | VF99023 | Not Available |
| 20 | Not Available | PLUG | AS312203 | Not Available |
| 21 | Not Available | ORANGE CORD ORDER VF45119 YELLOW | VF45126 | Not Available |
| 21 | Not Available | YELLOW CORD | VF45119 | Not Available |
| 22 | Not Available | STRAIN RELIEF | AS22009 | Not Available |
| 23 | Not Available | VALVE ASSEMBLY KIT | VF40200 | Not Available |
| 24 | Not Available | TANK SEAL KIT | VF40001 | Not Available |
| 25 | Not Available | OUTLET POPPET | VF40132 | Not Available |
| 26 | Not Available | TANK MOUNTING KIT | VF40000 | Not Available |
| 27 | Not Available | SOLUTION TANK | MC020 | Not Available |
| 28 | Not Available | GROMMET | VF50120 | Not Available |
| 29 | Not Available | MALE PLUG PROTECTOR - SMALL | AS41901 | Not Available |
| 30 | Not Available | WASHER | VF30018 | Not Available |
| 31 | Not Available | SOLUTION TRIGGER / LEVER | AS312212 | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | SCREW M-5 X 16 | VA13474 | Not Available |
| 2 | Not Available | HANDLE BRACKET RIGHT | VF30019 | Not Available |
| 3 | Not Available | HANDLE BRACKET LEFT | VF30020 | Not Available |
| 4 | Not Available | PLAIN WASHER | V V20274 | Not Available |
| 5 | Not Available | SMALL LOCK WASHER | VF13520 | Not Available |
| 6 | Not Available | LARGE LOCK WASHER | VF50119 | Not Available |
| 7 | Not Available | WHEEL AXLE | VF30026 | Not Available |
| 8 | Not Available | WHEEL - 5" | VF48202 | Not Available |
| 9 | Not Available | HANDLE PLATE GUIDE | AS312201 | Not Available |
| 10 | Not Available | CLAMP BLOCK - AXLE | GV40235 | Not Available |
| 11 | Not Available | SELF TAPPING SCREW 5 X 20 | V V13621 | Not Available |
| 12 | Not Available | PAD HOLDER - 17" | MFVF002 | Not Available |
| 12 | Not Available | PAD HOLDER - 20" ORDER MFVF022 | MFVF015 | Not Available |
| 12 | Not Available | PAD HOLDER - 19" | MFVF022 | Not Available |
| 13 | Not Available | COUPLING | VF99021 | Not Available |
| 14 | Not Available | SLEEVE | MT01102 | Not Available |
| 15 | Not Available | LOCK WASHER | V V13601 | Not Available |
| 16 | Not Available | SCREW M-5 X 30 | V V13636 | Not Available |
| 17 | Not Available | STATIONARY SWITCH | YCQ10300B | Not Available |
| 18 | Not Available | RUNNING CAPACITOR | VF999854 | Not Available |
| 19 | Not Available | START UP CAPACITOR | VF999805 | Not Available |
| 20 | Not Available | CENTRIFUGAL SWITCH | YCQ10300A | Not Available |
